ЧПУ автоматический стальной стержень арматурный гибочный
- Категория: Rebar Cutting Machine >>>
- Поставщик: Xingtai,Judu,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.34 $* | 0.33 $* |
| Aug-18-2025 | 0.20 $* | 0.72 $* |
| Jul-18-2025 | 0.65 $* | 0.70 $* |
| Jun-18-2025 | 0.11 $* | 0.98 $* |
| May-18-2025 | 0.16 $* | 0.34 $* |
| Apr-18-2025 | 0.38 $* | 0.33 $* |
| Mar-18-2025 | 0.68 $* | 0.76 $* |
| Feb-18-2025 | 0.13 $* | 0.19 $* |
| Jan-18-2025 | 0.45 $* | 0.19 $* |
Характеристики
CNC Automatic Steel Bar Rebar Bender Stirrup Bending Machine
Product Description
Introduction of Steel Bar Bending Machine :
1. Frictional progressive feeding mechanism with high accuracy and no harm to steel bar rib.
2. The benders apply double line feeding system, which can greatly increase the productivity and reduce the labor intensity.
3. With the function of quick back and forth bending, the double vane bending die has improved its bending performance.
4. Powerful hydraulic shearing mechanism with good reliability.
5. The powerful memory database provides hundreds of shapes for using.
6. Quick-adjusting system has the function of machine diameter diameter.
7. Bending scope of coiled steel bar ranges from 5mm to 12mm
8. Synchronous belt drive with high accuracy and low cost of maintenance.
9. Hydraulic Controlling system.
Features of Steel Bar Bending Machine
:
1. Steel Bar Bending Machine
adopt servo controlling system;
:
1. Steel Bar Bending Machine
adopt servo controlling system;
2.Automatically accomplish the functions of rebar's feeding, straighten, bending and cutting etc.
3. Steel Bar Bending Machine machine BIGGEST bending diameter of rebar is 14mm;
4.Continuously bend various stirrup of plane figure;
5.Widely used in construction industry and rebar manufacturing enterprise;
6.High efficiency and accurate processing precision.
Parameters of Steel Bar Bending Machine :
Model | R6 |
Single bar diameter (mm) | 5-10 |
Double bar diameter (mm) | 5-8 |
biggestbending angle ( °) | 180 |
biggesttowing speed (m / min) | 60 |
biggestbending speed ( °/ sec ) | 800 |
Length accuracy (mm) | 1 |
Angular accuracy ( °) | 1 |
Number of processing | 2 |
Power (kw) | 21 |
Shape processing (kinds) | 150 |
Working temperature (°C) | -5 -- 40 |
Weight (kg) | 1980 |
Dimensiion (mm) | 3300*1000*1980 |
Average power(kw / h) | 5 |
More picture of Steel Bar Bending Machine :
Faceback
Packaging & Shipping
Packing: In standard export wooden case for Steel Bar Bending Machine
Delivery time:within 15 days after receiveing your advanced payment.
Payment terms:. 30%T/T in advanced payment,the left payment should be paid after we finish our production.( we will take machine and packing photoes for your checking )
We have our own farwarder. We can check the delivery information timely. You can also use forwarder by yours. We will contact with him ASAP.
Related Products
for bending 5-10 mm rebar
for bending 5-12 mm rebar
For bending 5-14 mm rebar
2d wire bending machine with butt welder
3d wire bending machine
2d wire bending machine
Company Information
Founded in 2021, Xingtai JUDU Technology Co.,LTD research and development ,product and sell machine ;
There is a research and development team;
Machine quality assurance and ability to provide OEM, personalized service.
Many model machine have CE certifacate and patent certificate;
We have our own freight agent and deliver the goods on time .
Rebar bending machine and wire bending machine are our advandage products .
Welcome you to negotiate business!
Export Percentage: 91% - 100%
Export Mode: Have Own Export License
Language Spoken:
English,French,Spanish,Arabic...
No. of Employees in Trade Department: 30- 50 People
FAQ
1. What is the voltage/phase for this Steel Bar Bending Machine?
380V 50Hz/three phase , also can made as the clients’ need
2. Can you make the logo or company name on the products or package?
Sure. customer's logo or company name can be printed on products by stamping, printing, embossing, coating or sticker.
3. Do you have the products in stock?
Yes , We have some model products can supply to you.
4. Can we use English or other languages on the display screen?
Yes, can. The system can achieve many languages, such as English, French, Russian, Spanish, and other languages
5. How to choose a model?
First you could check with parameters list, or advise the requirement directly, then we would help you to choose a model accordingly.
6. How about After-sales service?
We freely send technicians to your country and 24 hours on-line service
