6kw complete Solar Battery Backup solar energy storage
- Категория: Solar Energy Products >>>
- Поставщик: Shenzhen,Taico,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 238.95 $* | 250.70 $* |
| Aug-19-2025 | 236.84 $* | 248.55 $* |
| Jul-19-2025 | 198.99 $* | 208.43 $* |
| Jun-19-2025 | 232.54 $* | 244.31 $* |
| May-19-2025 | 202.36 $* | 212.44 $* |
| Apr-19-2025 | 228.39 $* | 239.17 $* |
| Mar-19-2025 | 226.22 $* | 237.13 $* |
| Feb-19-2025 | 224.46 $* | 235.78 $* |
| Jan-19-2025 | 222.57 $* | 233.0 $* |
Характеристики
Note: IN STOCK, YOU CAN MAKE ORDER DIRECTLY OR SEND INQUIRY TO US!
1. This is 48V Powerwall Battery, with Grade A+ quality LiFePO4 Battery;
2. One battery can be equipped with one set of connection cables. If needs, pls contact us online. Thank you!
3. If buy 4pcs, we can match with 4pcs Battery with 4 set cabels for parallel connections.
4. Before delivery, we will test all Batteries in TAICO factory and ensure for high qulity to you!
Basic specification will be mark on the Battery before shipping!
1. This is 48V Powerwall Battery, with Grade A+ quality LiFePO4 Battery;
2. One battery can be equipped with one set of connection cables. If needs, pls contact us online. Thank you!
3. If buy 4pcs, we can match with 4pcs Battery with 4 set cabels for parallel connections.
4. Before delivery, we will test all Batteries in TAICO factory and ensure for high qulity to you!
Basic specification will be mark on the Battery before shipping!
Customized Capacity and Voltage
model | capacity | size | weight |
TKPW2000 | 24V100AH | 400*110*520MM | 24KG |
TKPW2400 | 48V50AH | 400*110*520MM | 24KG |
TKPW5000 | 48V100AH | 360*175*520MM | 45KG |
TKPW10000 | 48V200AH | 540*200*950MM | 120KG |
Function Parameter | ||||||
Norminal Battery Energy | 5120wh | |||||
Norminal Capacity | 100Ah | |||||
Norminal Voltage | 48V | |||||
Internal Resistance | ≤22mΩ | |||||
Cycle Life | >6000 | |||||
Months Self Discharge | <3% | |||||
Charge Data | ||||||
DC Normal Charge Voltage | 54.75±1Vdc | |||||
Charge Mode | 0.2C to 54.75V, then 54.75V,charge current to 0.02C (CC/CV) | |||||
Recommended Charger Current | ≤50A | |||||
Allowed Max. Charge Current | 50Adc | |||||
Charge Cut-off Voltage | 54.75±1Vdc | |||||
Discharge Data | ||||||
Continuous Discharge Current | 50A | |||||
Allowed Max. discharge current | 100A (option:200Adc) | |||||
Rang of DC discharge voltage | 37.5V-54.75Vdc | |||||
Working Condition | ||||||
Charge Temperature | 0℃ to 45℃ (32℉ to 113℉) @60±25% Relative Humidity | |||||
Discharge Temperature | -20℃ to 60℃ (-4℉ to 140℉) @60±25% Relative Humidity | |||||
Storage Temperature | 0℃ to 40℃ (32℉ to 104℉) @60±25% Relative Humidity | |||||
Enclosure Protection Level | IP20 | |||||
Mechanical Data | ||||||
Cell & Method | 3.2V100Ah, Prismatic | |||||
Shell material | Iron | |||||
Product Description.
◆ High capacity new lifepo4 lithium battery. ◆ Longer cycle life.
◆ Smart BMS system ensures safe and stable.
◆Support up to 16 units in parallel.
◆ Wall-mounted design, easy installation.
◆ Smart BMS system ensures safe and stable.
◆Support up to 16 units in parallel.
◆ Wall-mounted design, easy installation.
Key Features :
♦Longer Cycle Life : Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery ,
helping to minimize replacement cost and reduce total cost of ownership
♦Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries
♦Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity
♦Wider Temperature Range : -20℃~60℃
♦Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging
or short circuit situation
helping to minimize replacement cost and reduce total cost of ownership
♦Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries
♦Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity
♦Wider Temperature Range : -20℃~60℃
♦Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging
or short circuit situation
Battery Application
Product Description
Feature
1. Under normal conditions, using lithium iron phosphate battery technology, with excellent safety, thousands of cycles, 100% DOD.
2. Built-in automatic protection function to prevent overcharging, overdischarging, overcurrent and overheating.
3. Maintenance free.
4. Internal battery balance.
5. Light weight: about 40%~50% of the weight of lead-acid batteries.
6. Can be charged using most standard lead acid charge (set).
7. Wide temperature range: -20 ° C ~ 60 ° C.
8. Support for series application extensions (up to 512V)
Packing & Delivery
2. Built-in automatic protection function to prevent overcharging, overdischarging, overcurrent and overheating.
3. Maintenance free.
4. Internal battery balance.
5. Light weight: about 40%~50% of the weight of lead-acid batteries.
6. Can be charged using most standard lead acid charge (set).
7. Wide temperature range: -20 ° C ~ 60 ° C.
8. Support for series application extensions (up to 512V)
Packing & Delivery
Packing & Delivery
Company Exhibition
Certifications
