Машина для холодной формовки желобов машина
- Категория: Rolling Mill >>>
- Поставщик: Botou,Huayang,Roll,Forming,Machine,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 35700.86 $* | 37485.85 $* |
| Aug-19-2025 | 35400.16 $* | 37170.32 $* |
| Jul-19-2025 | 29700.5 $* | 31185.63 $* |
| Jun-19-2025 | 34800.42 $* | 36540.12 $* |
| May-19-2025 | 30300.87 $* | 31815.1 $* |
| Apr-19-2025 | 34200.13 $* | 35910.6 $* |
| Mar-19-2025 | 33900.17 $* | 35595.98 $* |
| Feb-19-2025 | 33600.70 $* | 35280.74 $* |
| Jan-19-2025 | 33300.66 $* | 34965.95 $* |
Характеристики
The gutter machine fully automatically produces half round gutters and rectangular gutters in different lengths and sizes.
Alongside the standard gutter profiles, custom shapes can also be produced depending on the roll set. A visualized touchscreen display allows for easy operation of the machine. The entered parameters can be saved separately for each gutter profile, enabling quick retooling. Selected from the display, all sheet metal side guides and roll sets are set to the correct positions according to the standard gutter size (5K 6K 7K 8K). Since all materials behave differently in the manufacturing process,material-specific values can also be saved in the program.
Alongside the standard gutter profiles, custom shapes can also be produced depending on the roll set. A visualized touchscreen display allows for easy operation of the machine. The entered parameters can be saved separately for each gutter profile, enabling quick retooling. Selected from the display, all sheet metal side guides and roll sets are set to the correct positions according to the standard gutter size (5K 6K 7K 8K). Since all materials behave differently in the manufacturing process,material-specific values can also be saved in the program.
PRODUCT DISPLAY
Gutter Profile
Product Details
Forming speed | About 15-20m/min | |||
Hydraulic cutting | Controlled by PLC | |||
PLC | DELTA, TAIWAN / Mitsubishi, Japan | |||
Material of cutting blade | Cr12Mov, quenching 58-62℃ |
Key benefits
* High flexibility through quick, easy retooling. (the machine can be converted from nominal size 333 to 250 in approx. 5 min).
* During production of 2 m gutters, 2 strips can be manufactured at the same time.
* Roll sets can also be added later at minimal cost to further extend your range of products.
* Large production volumes and extremely short retooling times.
* Negligible to no stock keeping of finished gutters.
* Minimal labor costs through simple one-man operation.
* Remote maintenance for quick and easy troubleshooting.
* Modern recipe management by use of a touchscreen display.
* Equipped with all safety devices incl. safety guards, light curtains, etc.
These materials can be processed: Aluminium, steel, titanium zinc, zinc, pre-weathered titanium zinc, Uginox, Ugitop, copper,coated steel
* High flexibility through quick, easy retooling. (the machine can be converted from nominal size 333 to 250 in approx. 5 min).
* During production of 2 m gutters, 2 strips can be manufactured at the same time.
* Roll sets can also be added later at minimal cost to further extend your range of products.
* Large production volumes and extremely short retooling times.
* Negligible to no stock keeping of finished gutters.
* Minimal labor costs through simple one-man operation.
* Remote maintenance for quick and easy troubleshooting.
* Modern recipe management by use of a touchscreen display.
* Equipped with all safety devices incl. safety guards, light curtains, etc.
These materials can be processed: Aluminium, steel, titanium zinc, zinc, pre-weathered titanium zinc, Uginox, Ugitop, copper,coated steel
