Order Code	Voltage (V)	Peak     Wavelength (nm)	Radiant   Power (mW)	Radiant Intensity (mw/sr)	Current (mA)	Half Width (nm)	Angle (0)	Electric power (W)
HYQ35G42N700AB-D1	2.0-2.4	690-710	300-400	250	700	22	120	3
HYQ35E42N720AB-D1	1.8-2.2	720-730	800-1000	600	1000	22	120	3
HYQ35E42N730AB-D1	1.8-2.2	730-740	800-1000	600	1000	22	120	3
HYQ35L42N760AB-D1	1.6-2.0	760-780	500-700	390	700	24	120	3
HYQ35L42N780AB-D1	1.6-2.0	780-800	500-700	430	700	25	120	3
HYQ35L42N800AB-D1	1.4-1.8	800-820	500-700	450	700	32	120	3
HYQ35G42N820AB-D1	1.6-2.0	820-830	500-600	400	700	35	120	3
HYQ35E42N850AB-D1	1.4-1.8	840-860	850-1200	420	1000	35	120	3
HYQ35L42N880AB-D1	1.4-1.8	870-890	600-800	360	700	39	120	3
HYQ35L42N910AB-D1	1.4-1.8	900-920	800-1000	360	700	39	120	3
HYQ35G42N925AB-D1	1.4-1.6	920-930	600-800	330	700	39	120	3
HYQ35E42N940AB-D1	1.2-1.6	930-950	900-1100	380	1000	45	120	3
HYQ35L42N980AB-D1	1.2-1.6	960-980	700-900	340	700	52	120	3
HYQ35L42N1050AB-D1	1.0-1.4	1000-1100	600-700	200	1000	50	120	3
HYQ35L14P1350AB-D1	1.0-1.2	1300-1400	10-15	/	100	85	120	0.2
HYQ35L14P1450AB-D1	1.0-1.2	1400-1500	10-15	/	100	85	120	0.2
HYQ35L42P1450AB-D1	1.0-1.2	1400-1500	130-150	/	700	85	120	3
HYQ35L32N940AB-D1	1.2-1.4	930-950	400-500	/	700	35	120	3



Warm Tip:The above parameters are for reference. Wavelength Angle, PCB can be customized according to requirements





SWIR is known as wavelength which can detect various materials, such as water, glucose, alcohol and so on.



SWIR LED can open up the possibility for various applications, such as wearable devices, agriculturalanalyzer, food analysis, drug discovery and healthcare.
