Характеристики
Products Show
Pulse K1 Series 220V, 0.4KW Servo Controller,AC Motor for Lathe
Product Parameter
K1AS02** | K1AS04** | K1AS08** | K1AS15** | K1AS22** | K1AS30** | K1AS50** | ||||||||
Input Power | ||||||||||||||
Control Mode | Three-phase PWM converter sine wave drive | |||||||||||||
Main Power | 220V: Single-phase/three phase 220V AC（-15~+10%，50~60Hz） | |||||||||||||
380V: Three-phase 380V AC（-15~+10%，50~60Hz） | ||||||||||||||
Control power | 220V: Single-phase 220V AC（-15~+10%，50~60Hz） | |||||||||||||
Rated current | 220V：0.2KW/2A,0.4kW/2.8A,0.75kW/5.5A,1.5kW/10A, 2.2kW/12A,3kW/16A,5kW/25A | |||||||||||||
Encoder feedback | ABZ incremen encoder / absolute encoder | |||||||||||||
Environment | ||||||||||||||
Working temperature | 0～45°C | |||||||||||||
Storage temperature | -20～65°C | |||||||||||||
Functions | ||||||||||||||
IO Input | 4-channel (DC24V optocoupler isolation) Input function can be selected according to parameters below: | |||||||||||||
IO Output | 3-channel optocoupler isolated output; the following output function can be selected according to | |||||||||||||
Pulse input | Differential input: 500K; open collector: 200K | |||||||||||||
Pulse output | Phase A, phase B: differential output. Phase Z: differential output or open collector output | |||||||||||||
Recommend Products
Universal bus K1 series
Power Supply Voltage: 220V/380V
Control Mode: Three-phase PWM converter sine wave drive.
Output Power: K1 220V series 100w-5KW
K1 380V series 1.5KW-7.5KW
Encoder: 2500LineIncremental/provincial encoders
Control Mode: Three-phase PWM converter sine wave drive.
Output Power: K1 220V series 100w-5KW
K1 380V series 1.5KW-7.5KW
Encoder: 2500LineIncremental/provincial encoders
17Bit/20bit/23bit absolute encoders
Digital IO signal: 4 channels input 3channels output can be set.
Communication Mode: RS232, Standard MODBUS Protocol, CANopen Bus.
Digital IO signal: 4 channels input 3channels output can be set.
Communication Mode: RS232, Standard MODBUS Protocol, CANopen Bus.
