Гель для многократного цикла глубокого заряда-разряда Солнечный аккумулятор с длительным сроком службы аккумуляторная батарея 12V 100ah белый AGM Медь терминал хранения системы солнечных

Гель для многократного цикла глубокого заряда-разряда Солнечный аккумулятор с длительным сроком службы аккумуляторная батарея 12V 100ah белый AGM Медь терминал хранения системы солнечных

Цена:80,00 $ - 90,00 $*

Количество:

Products Description Miêu tả

Product Paramenters Thông số kỹ thuật

GEL Battery Technology Data
model	LCPC100-12-GEL	LCPC150-12-GEL	LCPC200-12-GEL	LCPC250-12-GEL
Reted Voltage	12v	12V	12	12
Capacity(10hr,1.80v/cell)	100Ah	150Ah	200Ah	250Ah
Weight	31kg	45kg	57kg	72kg
Max Discharge Current	30I10A(3min)
Max Charge Current	<0.25C10				<0.25C10	<0.25C10
Self¬ Discharge (25 °C)	<3%/month				<3%/month
Recommended Using Temperature	15 °C 〜25 °C
Cover Material	ABS
Using Temperature	Discharge:-45 °C 〜50 °C Charge: -20°C~45°C Storage: -30°C〜40°C
Charge Voltage (25 °C)	Float Charge: 13.5V-13.8V Average Charge: 14.1V-14.4V
Charge Mode(25°C)	Float Charge:2.275±0.025V/Cell Temperature Compensation Coefficient :±3 mV/Cell °C Cycle Charge:2.45±0.05V/Cell Temperature Compensation Coefficient: ±5 mV/Cell °C
Cycle life	100%DOD 572times 50%DOD 1422 times 30%DOD 2218times
Capacity Affected by Temperature	105 % @40°C 85 % @0°C 60 % @ -20 °C

Different discharge time at different tenninal Voltage,discharge time(Amps,25)
Constant current discharge coefficient (25°C, A)
LCPC100-12-GEL
Terminal Voltage (v/Cell)	1H	3H	5H	10H	20H	50H	100H	120H	240H
1.7	53.10	24.14	16.13	10.41	5.38	2.26	1.23	1.09	0.57
1.75	52.04	23.89	15.85	10.26	5.25	2.17	1.15	1.01	0.53
1.8	51.00	23.67	15.60	10.00	5.13	2.10	1.10	0.95	0.51
1.85	48.96	23.53	15.30	9.59	4.88	2.01	1.03	0.89	0.46
1.9	47.01	23.33	15.07	9.36	4.79	1.95	0.99	0.85	0.43
1.95	44.94	22.86	14.76	8.87	4.46	1.81	0.94	0.81	0.41
LCPC150-12-GEL
Terminal Voltage (v/Ccll)	1H	3H	5H	10H	20H	50H	100H	120H	240H
1.7	79. 65	36.21	24. 20	15.61	8.06	3.39	1.84	1.63	0. 86
1. 75	78. 06	35. 84	23. 77	15. 39	7. 88	3. 26	1. 72	1.52	0. 80
1.8	76. 50	35. 50	23. 40	15. 00	7. 69	3. 15	1.65	1.42	0. 76
1.85	73. 44	35. 30	22. 95	14. 38	7. 31	3. 02	1.54	1. 33	0. 69
1. 9	70. 51	34. 99	22. 61	14. 08	7. 19	2. 93	1. 49	1.27	0. 65
1.95	67.41	34. 29	22. 14	13. 30	6.69	2. 72	1.41	1.21	0. 62

Terminal Voltage (v/Ccll)	1H	3H	5H	10H	20H	50H	100H	120H	240H
1.7
1. 75
1.8
1.85
1. 9
1.95 .

ABS Container

>corrosion resistance
>High pressure resistance
>high temperature resistance

Lead Plate

>Choose raw material No.1 lead
>Advanced die casting technology
>High hardness, with big current discharge, will not bend.

Copper Terminal

>Excellent electrical conductivity
>Provide connectors and copper medals
>Strong corrosion resistance

Tech Diagram Biểu đồ kỹ thuật

Product Packaging Đóng gói sản phẩm

Our factory Giới thiệu nhà máy

Certifications Chứng nhận chất lượng quốc tế
