Высокий ток 120A Heavy Duty Реле Автомобильные реле
- Категория: Auto Relays >>>
- Поставщик: Yueqing,Kuanghong,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 2.55 $* | 2.12 $* |
| Aug-17-2025 | 2.56 $* | 2.80 $* |
| Jul-17-2025 | 2.85 $* | 2.93 $* |
| Jun-17-2025 | 2.99 $* | 2.58 $* |
| May-17-2025 | 2.90 $* | 2.17 $* |
| Apr-17-2025 | 2.1 $* | 2.11 $* |
| Mar-17-2025 | 2.21 $* | 2.71 $* |
| Feb-17-2025 | 2.55 $* | 2.90 $* |
| Jan-17-2025 | 2.40 $* | 2.45 $* |
Характеристики
Product Description
Name | Automotive Relay |
Contact Material | Silver alloy |
Colour | Black |
Shape | Square |
Size | 45*45*62.8mm |
Characteristic | 12V 4.8W |
CONTACT DATA
Contact Material | AgSnO12 |
Contact Form | 1H(1A) |
Contact Ratings | NO:120A 14VDC |
Contact Resistance | 100mMax at6VDC 1A |
Max Switching Current | 120A |
Max Switching Voltage | 75VDC |
Max Switching Power | 1680W |
Life Expectancy Electrical | 100,000 Operations(at 30 Operations/minute) |
Life Expectancy Mechanical | 100,000 Operations |
COIL SPECIFICATION
Nominal Voltage（VDC） | 12 | ||
Coil Resistance（Ω） | 2.4W | 60 | |
Max Operate Voltage（VDC） | 6.0~8.0 | ||
Mix Release Voltage（VDC） | 1.2~3.6 | ||
Max Applicable Voltage(VDC) | 15 | ||
CHARACTERISTICS
Temperature Range | -30℃~+80℃ | ||
Vibration Resistance | 10~55Hz，1.5mm | ||
Shock Resistance | Operations Extremes | 10g | |
Damage Limits | 100g | ||
Humidity | 40%~85% | ||
Insulation Resistance | 100mΩ Min at 500VDC | ||
Safety Standard | CCEE | ||
Dielectric Strength Between Open Contacts | 500VAC（for one minute/sec） | ||
Between Contact And Coil | 750VAC(for one minute/sec) | ||
Operate Time | 7ms | ||
Release Time | 5ms | ||
Specification
Product Recommendation
Company Profile
Company Profile
Yueqing Kuanghong Electric Technology Co., Ltd. is located in Beibaixiang Town, Wenzhou City, the electric capital of China. Close to 104 National Highway, the traffic is very convenient. Since its establishment, the company has been focusing on the development, manufacturing and sales of automotive relays and high-power relays in an integrated model. After several years of hard work, the company has accumulated rich experience in manufacturing, design and research and development. The company's main business: automotive relays, plug-in wiring harnesses, high-power relays, automotive dual battery isolators. The company has always implemented the "customer satisfaction is our eternal pursuit" quality policy. The principle of "people-oriented, customer-centric" conveys sincerity. The company is an independent manufacturer and can provide customers with OEM.ODM services. High quality and low price, to provide customers with the best cost-effective products is our company's consistent aim. Warmly welcome new and old customers to visit and guide---we sincerely cooperate with us to create brilliance together!
company advantage
1. Can provide customers with OEM.ODM services
2. Affordable price
3. Strong professionalism
Production workshop
Logistics
FAQ
Q: how strong is the company
A: Since its establishment, the company has been focusing on the development, manufacturing and sales of automotive relays and high-power relays in an integrated model. After several years of hard work, the company has accumulated rich experience in manufacturing, design and R&D
Q: What is the main product
A: The company’s main business: automotive relays, plug-in wiring harnesses, high-power relays, automotive dual-battery isolators
Q: Whether to provide customized services
A: Our company is an independent manufacturer and can provide customers with OEM.ODM services
A: Since its establishment, the company has been focusing on the development, manufacturing and sales of automotive relays and high-power relays in an integrated model. After several years of hard work, the company has accumulated rich experience in manufacturing, design and R&D
Q: What is the main product
A: The company’s main business: automotive relays, plug-in wiring harnesses, high-power relays, automotive dual-battery isolators
Q: Whether to provide customized services
A: Our company is an independent manufacturer and can provide customers with OEM.ODM services
