WGZY-2.5 99.5% медицинский генератор кислорода высокой чистоты промышленный для
- Категория: Gas Generation Equipment >>>
- Поставщик: Weigao,Medical,International,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.29 $* | 0.51 $* |
| Aug-17-2025 | 0.18 $* | 0.77 $* |
| Jul-17-2025 | 0.18 $* | 0.77 $* |
| Jun-17-2025 | 0.99 $* | 0.57 $* |
| May-17-2025 | 0.63 $* | 0.93 $* |
| Apr-17-2025 | 0.34 $* | 0.11 $* |
| Mar-17-2025 | 0.70 $* | 0.48 $* |
| Feb-17-2025 | 0.1 $* | 0.15 $* |
| Jan-17-2025 | 0.53 $* | 0.16 $* |
Характеристики
Product Description
It is especial designed and developed for the oxygen requirement of small and medium-size medical institutions with highly integration and intelligence.
It consists of one single-mode group which contains several independent running oxygen generation modules.
It consists of one single-mode group which contains several independent running oxygen generation modules.
Specification
Medium Modular Oxygen Generator | ||||||||
Model | WGZY-2.5-N/Y | WGZY-3.0-N/Y | WGZY-5.0-N/Y | WGZY-6.0-N/Y | ||||
Oxygen flow rate | 2.5Nm3/h | 3.0 Nm3/h | 5.0 Nm3/h | 6.0 Nm3/h | ||||
Power | 3.0 KW | 3.6 KW | 6.0 KW | 7.2 KW | ||||
Oxygen generation models | 4 units | 5 units | 8 units | 10 units | ||||
Booster | 1 unit | 1 unit | 1 unit | 1 unit | ||||
Oxygen storage vessel | 1.0 m3 | 1.5 m3 | 2.0 m3 | 2.0 m3 | ||||
Dimension (L×W×H) mm | 815×580×1440 | 815×580×1440 | 1060×580×2130 | 1060×580×2130 | ||||
Net weight | 185 | 207 | 351 | 400 | ||||
System Parameter | ||||||||
Oxygen concentration | ≥93%±3% | Oxygen concentration monitoring | Built-in | |||||
Oxygen pressure | 0.4 Mpa-0.7 Mpa adjustable | Pressure monitoring | Standard configutation | |||||
Power supply | AC220V(≤3.0m³/h) AC380V(＞3.0m³/h)50Hz | Flow monitoring | Standard configutationYes | |||||
Control system | PLC control | Oxygen tank | External | |||||
Human interface | 9 inch touch screem | Remote monitoring system | Optional configutation | |||||
