AWS-PE(022) Speediest response Washing Line
Product Description
With years of technology modification and process experience precipitation, ACERETECH has a variety of different solutions for recycling PP PE scraps (LDPE/LLDPE film, PP woven bags, PP non-woven, PE bags, milk bottles, cosmetic containers, vegetable and fruit boxes). With advanced modular design, ACERETECH can freely combine each standard module to provide to customers specialized solutions.
Product Name : AWS- HDPE/PP/PS/ABS/PC/PET Plastic Washing Recycling Machine
In the field of HDPE/PP/PS/ABS/PC/PET recycling projects. Most of the materials come from urban and industrial collection sites,their sizes vary, and the composition of raw materials is different from country to country, even though the composition of HDPE/PP/PS/ABS/PC/PET in the same country is totally different.
ACERETECH team integrated the cleaning line technology in Europe and China and continuously optimized it. Finally, it developed a series of modular equipment that can adapt to the different characteristics of HDPE/PP/PS/ABS/PC/PET materials. Aiming at blow molding packaging bottle/box/cup/barrel/bucket and injection waste recycling. It can realize a cleaning and recycling line and handle hard materials at the same time. And flexible plastic.
Including sorting, size reduction, metal removing, cold and hot washing, high efficiency friction washing and drying modular.
Which can remove ferrous and nonferrous metals, sand, oil, glue, paper and many other different contaminants efficiency.
Product Name : AWS- HDPE/PP/PS/ABS/PC/PET Plastic Washing Recycling Machine
In the field of HDPE/PP/PS/ABS/PC/PET recycling projects. Most of the materials come from urban and industrial collection sites,their sizes vary, and the composition of raw materials is different from country to country, even though the composition of HDPE/PP/PS/ABS/PC/PET in the same country is totally different.
ACERETECH team integrated the cleaning line technology in Europe and China and continuously optimized it. Finally, it developed a series of modular equipment that can adapt to the different characteristics of HDPE/PP/PS/ABS/PC/PET materials. Aiming at blow molding packaging bottle/box/cup/barrel/bucket and injection waste recycling. It can realize a cleaning and recycling line and handle hard materials at the same time. And flexible plastic.
Including sorting, size reduction, metal removing, cold and hot washing, high efficiency friction washing and drying modular.
Which can remove ferrous and nonferrous metals, sand, oil, glue, paper and many other different contaminants efficiency.
Aceretech Recyclable Plastics Include:
* LLDPE/LDPE/HDPE/PE/EPE film, crushed material, lithium battery film, foamed pearl cotton
* PP/OPP/BOPP/CPP film, woven bag,
non-woven fabric (melt blown)
* PA66 fishing net, silk, factory trim, carpet
* PET/BOPET bottle flakes, film, silk, waste cloth, foam,optical film
* PTT wire
* EPS/XPS crushed material, cold briquetting foam, hot melt foam, insulation board
* HIPS/PC/ABS home appliance housing, electronic waste, factory plastic
* PVB crushed material, flakes
* PU
Product Paramenters
Device parameters | ||||||||
Size | Capacity | Motor Power | Equipment footprint | |||||
AWS PE 05 | 500kg/h | 150KW | 120m 2 | |||||
AWS PE 10 | 1000kg/h | 190KW | 260m 2 | |||||
AWS PE 20 | 2000kg/h | 290KW | 380m 2 | |||||
Unit energy consumption | ||||||||
Content | Average energy consumption per ton of bottle | |||||||
Electricity | 180-250KW | |||||||
Water | 1.5-3T | |||||||
Compressed air | 0.5-1m 3 | |||||||
Steam (optional) | 0-100KG | |||||||
Detergent (optional) | 0-5KG | |||||||
Suitable Products
Product Detail
Main components of PE film washing line:
1. Shredder/Crusher
2. Pre-washing machine
3. Friction washer
4. Flotation/floating separation tank
5. Friction washer
6. Drying unit (Centrifugal/Squeezer, warm air pipe dryer)
7. Storage silo
8. Electrical control cabinet
1. Shredder/Crusher
2. Pre-washing machine
3. Friction washer
4. Flotation/floating separation tank
5. Friction washer
6. Drying unit (Centrifugal/Squeezer, warm air pipe dryer)
7. Storage silo
8. Electrical control cabinet
Belt conveyor
Conveying raw materials into next parts.
1. PVC/Rubber belt
2. Metal detector as an option
3. With inverter to adjust speed
1. PVC/Rubber belt
2. Metal detector as an option
3. With inverter to adjust speed
Shredder
1. Bigger rotary knives, very tough.
2. Bigger rotor, more powerful.
2. Bigger rotor, more powerful.
3. Automatic oil supplement system.
4. Various screen sizes.
5. Thick and tough shredder body.
4. Various screen sizes.
5. Thick and tough shredder body.
Crusher
1. Crushing with water flushing in.
2. 3/5/7 rotor design.
3. Knife adjustment outside chamber.
4. Low noise.
5. Bearings outside.
2. 3/5/7 rotor design.
3. Knife adjustment outside chamber.
4. Low noise.
5. Bearings outside.
L type belt conveyor
1. For conveying flakes out from shredder.
2. PVC belt.
3. With inverter for speed adjustment
2. PVC belt.
3. With inverter for speed adjustment
Pre-washer
1. To remove heavy contaminates such as mud, stones, metals, thus to protect blades of crusher.
2. Plays a role as Sink-float tank and friction washer as well.
2. Plays a role as Sink-float tank and friction washer as well.
3. Water and energy saving design.
Friction Washer
1. Tough washing unit, removes most of contaminates.
2. Reinforced, mild steel and high speed rotor.
3. Bearings mounted outside.
4. Easy cleaning and maintenance.
5. Stainless steel SUS304 body.
2. Reinforced, mild steel and high speed rotor.
3. Bearings mounted outside.
4. Easy cleaning and maintenance.
5. Stainless steel SUS304 body.
Floating washer
1. With screw-IN and screw-OUT.
2. Special design of inner paddles to guarantee sufficient sediment of heavy impurities.
3. German SEW reducers.
4. Stainless steel SUS304 body.
6. With pneumatic water in-feed-valve, automatic level control via electronic feeler.
2. Special design of inner paddles to guarantee sufficient sediment of heavy impurities.
3. German SEW reducers.
4. Stainless steel SUS304 body.
6. With pneumatic water in-feed-valve, automatic level control via electronic feeler.
Squeezer
1. PLC control
2. Low consumption, high capacity
3. Inverter control
4. European design
2. Low consumption, high capacity
3. Inverter control
4. European design
Storage silo
1. To guarantee non-stop work and stable feeding for downstream extrusion pelletizing line.
2. Non-blockage of film.
3. Cyclone for dust removing.
4. Lower operating costs for maintenance.
5. Different functions of screws.
2. Non-blockage of film.
3. Cyclone for dust removing.
4. Lower operating costs for maintenance.
5. Different functions of screws.
Electrical control cabinet with PLC Control
Intelligent control system.
With CE/CSA/TUV/SGS/ISO standard, all parameters can be set on the touch screen.
1. Electric control component: (Schneider), e.g. Circuit-breaker, AC contact, press button, pilot lamp.
2. For electrical controlling of the entire system.
3. Safety interlock principle.
4. All electrical units: LS, Schneider, ABB.
With CE/CSA/TUV/SGS/ISO standard, all parameters can be set on the touch screen.
1. Electric control component: (Schneider), e.g. Circuit-breaker, AC contact, press button, pilot lamp.
2. For electrical controlling of the entire system.
3. Safety interlock principle.
4. All electrical units: LS, Schneider, ABB.
Cleaned Film
Cleaned film
