Параллельный Светодиодный УФ-проектор 405 нм для 3D-принтера с ЖК-дисплеем
US $250.00-$290.00
Forcate в Китае предлагает светодиодные УФ-системы революционно произведены для высокоскоростного
- Категория: >>>
- Поставщик: Forcate,Technology,Company,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.57 $* | 0.27 $* |
| Aug-15-2025 | 0.5 $* | 0.87 $* |
| Jul-15-2025 | 0.53 $* | 0.38 $* |
| Jun-15-2025 | 0.25 $* | 0.64 $* |
| May-15-2025 | 0.49 $* | 0.83 $* |
| Apr-15-2025 | 0.27 $* | 0.51 $* |
| Mar-15-2025 | 0.34 $* | 0.30 $* |
| Feb-15-2025 | 0.29 $* | 0.42 $* |
| Jan-15-2025 | 0.55 $* | 0.82 $* |
Характеристики
Forcate in China Offer LED UV Systems Revolutionize For High Speed Flexo
UV LED curing system already used in many kinds of area, the controller and water chiller is all in one design.
People can use it for testing UV LED ink, adhesive, coating, wood paint, printing machine,coating machine and so on.
Main Features
1) LG LED chip, best quality COB package, special structure design good heat dissipation, very strong light intensity
2) 0-10V auto control and manual control can be choosed, the light intensity can change according light intensity
3)UV LED bad warning and over temperature warning
4)RS485 communication and port is provides
| Product application | |||||
| Model | Light area(MM) | Wavelength(nm) | Light intensity(W/CM2) | Cooling Method | Electric Power |
| FWF260*20 | 260*20 | 395 | 30 | Water cooling | 2000W |
| FWF312*20 | 312*20 | 395 | 30 | Water cooling | 2400W |
| FWF364*20 | 364*20 | 395 | 30 | Water cooling | 2800W |
| FWF468*20 | 468*20 | 395 | 30 | Water cooling | 3600W |
| FWF520*20 | 520*20 | 395 | 30 | Water cooling | 4000W |
| FWF676*20 | 676*20 | 395 | 30 | Water cooling | 5200W |
| FWF884*20 | 884*20 | 395 | 30 | Water cooling | 6800W |
| FWF1092*20 | 1092*20 | 395 | 30 | Water cooling | 8400W |
| FWF1456*20 | 1456*20 | 395 | 30 | Water cooling | 11200W |
| FWF1508*20 | 1508*20 | 395 | 30 | Water cooling | 11600W |
Installation process
Forcate is a factory based in Shenzhen, China. After 10 years developing, we have full experience in printing industry, Adhesive and wood curing.
We offer Strong UV Light Curing System Online
At the beginning of Forcate, we insist two rules: one quality is first, never send bad quality products to customer, the other is never stop developing new products.
To meet the market requirement, we have very strong UV Light Curing System with an intensity 0-30W/CM2 for sheetfed offset printer, high speed flexo printer, gravure printer and web offset printer, all the system can controlled by PLC.
Applications
Company Information
FAQ
Q1: What's the whole UV LED curing system including?
A1: The whole UV LED curing system including UV LED lamp+ UV LED driver+ electric cabinet and control system+water chiller
Q2. Can I buy water chiller in my local market?
A2: Yes, I will suggest you the chiller capacity after confirm which model you want.
Q3. Can I use my own PLC and Electric cabinet?
A3: Yes, of coures. Our UV LED driver provide RS485 communication.
Q4. How do you ship the goods and how long does it take to arrive?
A4: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for UV LED curing system?
A5: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on UV LED curing system?
A6: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee and installation service for the products?
A7: Yes, we offer 20000HRS service and 1 year free warranty. The installation service can provided but should be payed according different country and different system.
Q8: How to deal with the faulty?
A8: Firstly, Our products are produced in strict quality control system and the defective rate will be lessthan 0.2%.
Secondly, during the guarantee period, we will send new parts with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution
including re-call according to real situation.
