Автоматическое управление равномерный питательный двигатель Вибрационный

Автоматическое управление равномерный питательный двигатель Вибрационный

Категория: Mining Feeder >>>
Поставщик: Jining,Enwei,Intelligent,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	0.16 $*	0.69 $*
Aug-15-2025	0.86 $*	0.86 $*
Jul-15-2025	0.24 $*	0.51 $*
Jun-15-2025	0.75 $*	0.19 $*
May-15-2025	0.23 $*	0.50 $*
Apr-15-2025	0.61 $*	0.68 $*
Mar-15-2025	0.83 $*	0.0 $*
Feb-15-2025	0.0 $*	0.49 $*
Jan-15-2025	0.2 $*	0.90 $*

Характеристики

Product Description

GZG series of coal mine special discharge feed system is mainly used for coal mine belt corridor or product warehouse quantitative feeding, the coal of different nature is adaptable, the feed volume is large, the feed is uniform, stable, the equipment structure is simple, easy to install and repair, low energy consumption, high efficiency, low noise, also applicable to the power plant belt corridor feeding.

GZG series coal discharging and feeding system is mainly composed of chute, feeder body, VVB series vibration motor, vibration damping device, auxiliary hanger, electro-hydraulic flat gate (small specifications can be used rack and pinion manual gate) and so on.

Product Parameters

Model and Meaning:

GZG: equipment Model

240: width of feed groove

structural form:

model			GZG120	GZG150	GZG180	GZG200	GZG240	GZG290-400
capacity t/h			600	600-1000	1000-1500	1500-2000	2000-2500	2500-3600
material size			≦300
double-amplitude			5-7
vibration motor	model	VBB-45306-W	VBB-60376-W	VBB-60376-W	VBB-80556-W	VBB-135906-W	VBB-1601106-W
vibration motor		power kw	2*3.0	2*3.7	2*3.7	2*5.5	2*9.0	2*11
electric hydraulic pushing pole	driving mode	One stop two drives
		pushing force/ drawing force	30/25	50/33.75	50/33.75	50/33.75	120/100	120/100
		stroke	620	800	850	1000	1300	1700
		power kw	4	4	4	4	7.5	7.5
weight			3680	4440	5320	6830	12660	14480
structure size	L	1627	1610	2000	2283	2815	3300
		L1					700	700
		A1	1100	1100	1450	1515	1860	2060
		B	1200	1500	1800	2000	2400	2900
		B1	1600	1900	2200	2400	2960	3370
		B2	1000	1400	1600	1800	2200	2616
		B3	1120	1520	1708	1960	2366	2772
		α (°)	12	12	12	12	14	14
		a	400	400	400	400	280	280
		b	250	250	250	250	210	210
		b1					140	140
		b2	280	304	244	245	338	231
		d	270	27	27	27	33	33
		N1	8	8	8	8	12	12
		N2					4	4
		N3	16	20	28	32	28	48
		H	1738	1858	1945	2270	2679	2800
