Sale of mining ore vibrating feeder coal vibrating hopper feeder
US $4000-$10000
Высококачественное китайское горное оборудование электрическое минеральное Вибрирующая
- Категория: Mining Feeder >>>
- Поставщик: Ganzhou,Eastman,Technology,Co.,Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 7140.44 $* | 7497.2 $* |
| Aug-15-2025 | 7080.31 $* | 7434.18 $* |
| Jul-15-2025 | 5940.22 $* | 6237.87 $* |
| Jun-15-2025 | 6960.50 $* | 7308.0 $* |
| May-15-2025 | 6060.59 $* | 6363.93 $* |
| Apr-15-2025 | 6840.54 $* | 7182.84 $* |
| Mar-15-2025 | 6780.39 $* | 7119.11 $* |
| Feb-15-2025 | 6720.67 $* | 7056.47 $* |
| Jan-15-2025 | 6660.24 $* | 6993.40 $* |
Характеристики
Product Description
Introduction of vibrating grizzly feeder
Our company's feeder series is a kind of linear direction vibration feeder. it makes a feature of smooth vibrating, reliable in operation, long service life and suitable for feeding, material into the crusher while screening away soil contained in the raw bmaterial. They are widely used in mining, building-material, silicate and chemical industry in the crushing and screening plants.
Our company's feeder series is a kind of linear direction vibration feeder. it makes a feature of smooth vibrating, reliable in operation, long service life and suitable for feeding, material into the crusher while screening away soil contained in the raw bmaterial. They are widely used in mining, building-material, silicate and chemical industry in the crushing and screening plants.
Application
Quarry, crawler sand,dry mortar, mechanism sand, power plant desulfurization, quartz sand, etc.mining feeder Advantages:
1.Use inertial vibrator as the vibration source, and there are no moving part and few wearing parts
2.High efficiency and feeding capacity
3.Use enclosed structure of body to prevent dust pollution
4.Have low noise and can help to improve working environment
5.Little power consumption
6.Stable amplitude, reliable operation, and strong adaptability to a variety of materials
1.Use inertial vibrator as the vibration source, and there are no moving part and few wearing parts
2.High efficiency and feeding capacity
3.Use enclosed structure of body to prevent dust pollution
4.Have low noise and can help to improve working environment
5.Little power consumption
6.Stable amplitude, reliable operation, and strong adaptability to a variety of materials
Principle of Operation:
Vibrating feeder is composed of a feeding trough, vibrator, spring support, driving device, etc. Body vibration feeder vibration source is the vibration exciter, which is composed of two eccentric shaft (main, passive) and gear pair. Motor drives the driving shaft through the belt, and the driving shaft gear driven shaft rotation. The driving shaft and the driven shaft reverse rotation at the same time, the body vibration, so that the material continuous flow, achieve the purpose of conveying material.
Vibrating feeder is composed of a feeding trough, vibrator, spring support, driving device, etc. Body vibration feeder vibration source is the vibration exciter, which is composed of two eccentric shaft (main, passive) and gear pair. Motor drives the driving shaft through the belt, and the driving shaft gear driven shaft rotation. The driving shaft and the driven shaft reverse rotation at the same time, the body vibration, so that the material continuous flow, achieve the purpose of conveying material.
Parameters
Model | Size of Funnel(mm) | Max Feed Size(mm) | Capacity (t/h) | Motor Power (L*W*H) (kw) | Weight (kg) | Overall Dimensions (mm) |
DN-380*95 | 3800*950 | 500 | 96-160 | 11 | 4082 | 3882*2224* 2121 |
DN-490*95 | 4900*950 | 500 | 120-240 | 15 | 5004 | 4957*2277* 2150 |
DN-490*110 | 4900*1100 | 800 | 120-280 | 15 | 5320 | 4957*2400* 2150 |
DN-590*110 | 5900*1100 | 820 | 200-350 | 22 | 6130 | 6000*2500* 2150 |
DN-600*130 | 6000*1300 | 900 | 400-560 | 22 | 7800 | 6082*2580* 2083 |
DN-600*150 | 6000*1500 | 1000 | 800 | 30 | 12110 | 6627*2350* 3068 |
DN-600*200 | 6000*2000 | 1000 | 1200 | 37 | 18650 | 6436*3853* 3014 |
Model | Max Feed Size(mm) | Capacity (t/h) | Motor Power(kw) | Installation Slope(°) | Double Amplitude (mm) | Weight (kg) | Overall Dimensions(mm) |
GDN-0724 | 450 | 30-80 | 2*1.5 | 10 | 4-6 | 2422 | 2481*1130*990 |
GDN-0932 | 560 | 80-150 | 2*2.4 | 10 | 4-8 | 3203 | 3298*1512*1195 |
GDN-0940 | 560 | 80-180 | 2*3.7 | 10 | 4-8 | 3700 | 4100*1818*1134 |
GDN-1148 | 600 | 150-300 | 2*5.5 | 10 | 4-8 | 5060 | 4926*1676*1475 |
GDN-1256 | 800 | 180-400 | 2*7.5 | 10 | 4-8 | 6385 | 5704*1840*1492 |
GDN-1560 | 1000 | 400-600 | 2*13 | 10 | 4-8 | 8900 | 6110*2440*1560 |
