Высокоэффективные солнечные панели Lovsun 210 мм 132 650 Вт 655 660
- Категория: Solar Energy Products >>>
- Поставщик: Lovsun,Solar,Energy,Group,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.15 $* | 0.94 $* |
| Aug-16-2025 | 0.37 $* | 0.97 $* |
| Jul-16-2025 | 0.82 $* | 0.79 $* |
| Jun-16-2025 | 0.39 $* | 0.89 $* |
| May-16-2025 | 0.75 $* | 0.60 $* |
| Apr-16-2025 | 0.2 $* | 0.94 $* |
| Mar-16-2025 | 0.38 $* | 0.85 $* |
| Feb-16-2025 | 0.96 $* | 0.74 $* |
| Jan-16-2025 | 0.45 $* | 0.15 $* |
Характеристики
Product Description
Electrical Datasheet At STC | ||||||||
Power | 650W | 655W | 660W | 665W | ||||
Open circuit voltage | 45.58V | 45.78V | 45.98V | 46.18V | ||||
Short circuit voltage | 18.16A | 18.21A | 18.26A | 18.31A | ||||
Maximum power voltage | 37.61V | 37.81V | 38.01V | 38.21V | ||||
Maximum power current | 17.28A | 17.32A | 17.36A | 17.40A | ||||
Module efficiency | 20.92% | 21.09% | 21.25% | 21.41% | ||||
Temperature Ratings ( STC )
Temperature Coefficient of Isc\u2029 +0.05%/C
Temperature Coefficient of Voc -0.28%/C
\u2029Temperature Coefficient of Pmax \u2029-0.36%/C
Mechanical Loading
Front Side Maximum Static Loading 5400Pa
Rear Side Maximum Static Loading 2400Pa
Hailstone Test 25mm Hailstone at the speed of 23m/s
Rear Side Maximum Static Loading 2400Pa
Hailstone Test 25mm Hailstone at the speed of 23m/s
Mechanical Specifications | ||
External Dimensions | 2384x 1303 x 35 mm | |
Weight | 34kg | |
Solar Cells | PERC Mono 210 x 105mm | |
Front Glass | 3.2 mm AR coating tempered glass, low iron | |
Frame | Anodized aluminium alloy | |
Junction Box | IP68,3 diodes | |
Output Cables | 4.0 mm2,Portrait:280mm(+)/280mm(-);Landscape:1500mm | |
Mechanical Load | Front side 5400Pa/ Rear side 2400Pa | |
Details Images
EVA Sealed Film
*Top quality EVA sealed film in China
*Resistance in both high and low temperatures
*Resistance in both high and low temperatures
*Sealed adhesive durability more than 30 years
Laser Half Cut Cell
*Solid PID resistance ensured by solar cell
*process optimization and careful module BOM selection
*Laser accurately cut
* Both 6BB&9BB available
*Standard photovoltaic cable, dedicated photovoltaic MC4 connector
*Waterproof grade IP68
*Good heat dissipation performance, low loss, long service life
Aluminum frame
Heavy thickness anodized aluminum alloy, passed the salt spay test, for long-term outside use.
Product Line
Quality Control
RAW MATERIAL MANAGEMENT
Stringent supplier management
Automatic material filtration and sorting
Manual standard sampling inspection by batch
Constant temperature and humidity storage environment
Supplier Quality Engineering
Incoming-material quality assurance
Automatic material filtration and sorting
Manual standard sampling inspection by batch
Constant temperature and humidity storage environment
Supplier Quality Engineering
Incoming-material quality assurance
Quality monitoring of the whole production line
Multiple EL tests
Mobile sampling inspection
Multiple EL tests
Mobile sampling inspection
Test results are entered into the database in real time
Simulating open-box testing
Spot check every feedstock batch
Simulating open-box testing
Spot check every feedstock batch
Pack&shipping
PACKING CONFIGURATION | ||||||||
Modules/Pallet | 31Pieces | |||||||
Modules/40HQ Container | 558Pieces | |||||||
Packing Description | 18Pallets,total=(31+31)x9=558pieces | |||||||
Residential&Commercial Projects
