Емкость может быть изменена для высококачественного распределения мощности trafo

Transformer capacity (kVA)

Pressure regulation method

high pressure (kV)

High voltage tapping range

Low pressure (kV)

Link group label

No load

loss (kW)

No load

Current (A)

Load loss (kW)

Short circuit impedance (%)

30

No excitation

6

6.3

10

10.5

11

±5

±2×2.5%

0.4

Dyn11Yyn0

0.08

2.3

0.63/0.6

4.0

50

0.1

2.0

0.91/0.87

63

0.11

1.9

1.09/1.04

80

0.13

1.9

1.31/1.25

100

0.15

1.8

1.58/1.5

125

0.17

1.7

1.89/1.8

160

0.2

1.6

2.31/2.2

200

0.24

1.5

2.73/2.6

250

0.29

1.4

3.2/3.05

315

0.34

1.4

3.83/3.65

400

0.41

1.3

4.52/4.3

500

0.48

1.2

5.41/5.15

630

0.57

1.1

6.2

4.5

800

0.7

1.0

7.5

1000

0.83

1.0

10.3

1250

0.97

0.9

12

1600

1.17

0.8

14.5

2000

1.55

0.8

18.3

5

2500

1.83

0.8

21.2
