Зарядное устройство 12 в 10

Категория: On Board Chargers >>>
Поставщик: Nanjing,Pengtu,Power,Supply,Co.,Ltd.

Цена:45,00 $ - 60,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Aug-17-2025	57.34 $*	58.94 $*
Jul-17-2025	46.27 $*	47.82 $*
Jun-17-2025	56.74 $*	57.11 $*
May-17-2025	56.79 $*	57.5 $*
Apr-17-2025	45.13 $*	46.65 $*
Mar-17-2025	55.81 $*	56.74 $*
Feb-17-2025	54.0 $*	55.48 $*
Jan-17-2025	54.72 $*	55.44 $*

Характеристики

Product Overview

300W High Frequency Digital Display Battery charger

This series chargers adopt LED digital display and MCU intelligent control mode. They are suitable for liquid-rich lead-acid
batteries, maintenance-free lead-acid battery, lithium batteries, nickel-metal hydride batteries, nickel-cadmium batteries, etc. Widely used in the cycling charge of battery packs in the E-sweeper, E- lifter, etc .

FEATURES AT A GLANCE

. Digital Display.

. MCU intelligent control

. Fully charge automatic shutdown

PRODUCT SPECIFICATIONS

No	Item	Data
1	Ac input voltage range	180-260VAC/90-130VAC （for option）; 45-65HZ
2	AC max input current	2A@220VAC
3	Noise	≤60dB
4	Net weight	1.0kg±0.3kg
5	Working temperature	-20°C~＋55°C
6	Storage temperature	-40°C~＋95°C

Mechanical Drawing

Model List

Item	Battery Rated Voltage	Max output current
UBC170-1210	12V	10A
UBC170-1212	12V	12A
UBC170-1215	12V	15A
UBC170-2408	24V	8A
UBC170-2410	24V	10A
UBC170-3605	36V	5A
UBC170-4805	48V	5A

Protective function

. Output overvoltage protection
. Output shortcircuit protection
. Output no-load protection
. Output reverse connection protection

. Input overcurrent protection

In order to confirm if our charger is suitable for your battery pack, please send the following infomations to us by email:
(1) battery type:
(2) number of cells in series:
(3) capacity of battery pack(AH):
(4) The maximum charge voltage:
(5) AC input volt:
(6) with CAN or enable:
(7) if with CAN, tell us the BMS brand
AC cable and DC cable: matching socket without AC/DC cable.

Certifications

Company Profile

Product packaging

Our services

Shipping:
We Ship to Worldwide, except APO/FPO.
Items are shipped from China using Airmail, reach most of the countries within 10 to 20 business days.
Delivery time depends on destination and other factors, it may takes up to 20 business days
Noted: Fedex Maybe charge handling charges at your country, we are not responsible for this charges.

Warranty and Guarantee:
24 months Warranty. Buy with confidence!
Under the terms of this warranty, if the product have a failure occurs under normal usage within warranty period, we will provide free new products or components based on the proof-documents.
If Failure or damage due to incorrect operation, wire connection, or anything other do not follow our instuction, we will provide paid.
If you are not satisfied when you receive your item, please return it within 14 days for a replacement or money back. Please contact me before you return it.

Other Policies:
We are not responsible for any custom duty or import tax.
We will leave POSITIVE FEEDBACK after receiving the payment. Please contact us if you are not satisfied with the item after receive it.
All emails will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your email and we will reply to you as soon as possible.

Serious Buyer Only! Please place bid only if you agree with all the terms.
