Лазерный резак и маркер лазерный источник макс. 1000 Вт 1500 2000 3000 4000 6000 волоконный
- Категория: Laser Equipment Parts >>>
- Поставщик: Shandong,Zhongshun,Laser,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.20 $* | 0.1 $* |
| Aug-15-2025 | 0.51 $* | 0.7 $* |
| Jul-15-2025 | 0.98 $* | 0.92 $* |
| Jun-15-2025 | 0.95 $* | 0.41 $* |
| May-15-2025 | 0.15 $* | 0.50 $* |
| Apr-15-2025 | 0.22 $* | 0.79 $* |
| Mar-15-2025 | 0.1 $* | 0.79 $* |
| Feb-15-2025 | 0.80 $* | 0.0 $* |
| Jan-15-2025 | 0.22 $* | 0.98 $* |
Характеристики
Product Parameters
Optical Characteristic Parameter Table | ||||||||||
Characteristic | Test Conditions | Minimum | Typical value | Max | Unit | |||||
Operating mode | Continuous pulse | |||||||||
Polarization | Random | |||||||||
Output power MFSC-2000W | 100% continuous | 2000 | W | |||||||
Power adjustment range | 10 | 100 | % | |||||||
Center wavelength | 100% continuous | 1070 | 1080 | 1090 | nm | |||||
Spectral bandwidth (3DB) | 100% continuous | 3 | 5 | nm | ||||||
Short-term power stability | 100% continuous ＞1H | ±1 | ±3 | % | ||||||
Long-term power stability | 100% continuous ＞2H | ±2 | ±5 | % | ||||||
Beam quality (BPP) | 00% continuous (35U-QBH) | 2.5 | mm*mard | |||||||
Laser opening time | 10% → 90% output | 50 | 100 | μs | ||||||
Laser off time | 90% → 10% output | 50 | 100 | μs | ||||||
Modulation frequency | 100% output | 20 | khz | |||||||
Indicating red light power | 100% output | 150 | μw | |||||||
Fiber optic cable length | 15 | m | ||||||||
Output fiber core diameter | 50 (30, 100 optional) | μm | ||||||||
Optical fiber cable bending radius | 200 | |||||||||
Output method | Standard QBH (LOC) | |||||||||
General Characteristic Parameter Table | ||||||||||
Characteristic | Test Conditions | Minimum | Typical value | Max | Unit | |||||
Operating Voltage | 180 | 220 | 240 | VAC | ||||||
Rated power consumption MFSC-2000W | 100% output | 7 | KW | |||||||
Working temperature | 10 | 40 | ℃ | |||||||
Relative humidity of working environment | 10 | 85 | % | |||||||
Cooling method | Water cooling | |||||||||
Storage temperature | -10 | 60 | ℃ | |||||||
Overall size | 950*482.6*193.2 | mm | ||||||||
Total Weight | 68±3 | Kg | ||||||||
Product Details
Related Products
Company Profile
Pack and ship
FAQ
Q1. How to get the most suitable machine and best price？
As we may know,the different type of CNC machine apply to the different material,and the different model apply to the different material.Thus,Please tell us what's material you want to cutting or engraving ?And what's MAX size of carved material ?Then we wil recommand the most suitable model and the best price for you.
Q2. Quality Control？
The whole production procedure will be under regular inspection and strict quality control. The complete machine will be tested to make sure they can work very well before being out of factory.
Our machine passed CE Certificate, meet European and American standard, were exported to more than 100 Countries.
The whole production procedure will be under regular inspection and strict quality control. The complete machine will be tested to make sure they can work very well before being out of factory.
Our machine passed CE Certificate, meet European and American standard, were exported to more than 100 Countries.
Q3: How is the shipping method?
As per your actual address, we can effect shipment by sea, by air, by truck or railway. Also we can send the machine to your office as per your requirement .
As per your actual address, we can effect shipment by sea, by air, by truck or railway. Also we can send the machine to your office as per your requirement .
Q4: This model is not suitable for me, do you have more models available?
Yes, we can supply many models, such as portable fiber laser marking machine, table fiber laser marking machine, enclosed fiber laser marking machine, CO2 laser marking machine, UV laser marking machine and so on. Replacement of some part based on your need. The above are most popular. If it can not meet your requirement, then tell us. We have the ability to make specially according your requirement!
Yes, we can supply many models, such as portable fiber laser marking machine, table fiber laser marking machine, enclosed fiber laser marking machine, CO2 laser marking machine, UV laser marking machine and so on. Replacement of some part based on your need. The above are most popular. If it can not meet your requirement, then tell us. We have the ability to make specially according your requirement!
