Коммерческая Вакуумная сушилка для замораживания фруктов овощей
- Категория: Vacuum Drying Equipment >>>
- Поставщик: Zhucheng,Yamei,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.88 $* | 0.88 $* |
| Aug-19-2025 | 0.54 $* | 0.53 $* |
| Jul-19-2025 | 0.73 $* | 0.29 $* |
| Jun-19-2025 | 0.59 $* | 0.59 $* |
| May-19-2025 | 0.31 $* | 0.11 $* |
| Apr-19-2025 | 0.10 $* | 0.85 $* |
| Mar-19-2025 | 0.90 $* | 0.11 $* |
| Feb-19-2025 | 0.53 $* | 0.15 $* |
| Jan-19-2025 | 0.9 $* | 0.96 $* |
Характеристики
Product Description
The vacuum freeze drying machine is an advanced method for the material for the material de-watering. It freezes the moisture material in the low temperature and makes the water inside sublimate directly in the vacuum condition. Then it collects the sublimated vapor by means of the condensing way so as to dewater and dry the material. The processed material can be recovered quickly if being watered again.
It is the most advanced technology for food dehydration processing at present. Compared with the common drying method, the freeze-dried food produced with this technology features long period of quality assurance, good re-hydration nature, good-looking color, good flavor, taste, shape and high content of nutritious components. The dried food basically remains unchanged in its volume and shape, it looks like sponge and has no shrinking. This kind drying technology can be widely used in process of vegetables, fruits, condiments, aquatic products, biological products, medicine, beverage and etc.
333
Specification
Model | Y-FD0.5 | Y-FD 1 | Y-FD 5 | Y-FD 10 | Y-FD 20 | Y-FD 30 | Y-FD 50 | Y-FD100 | Y-FD200 | ||||||||
Drying Area m³ | 0.5m³ | 1m³ | 5m³ | 10m³ | 20m³ | 30m³ | 50m³ | 100m³ | 200 m³ | ||||||||
Material chamber | Food grade stainless steel 304 or 316 Option | ||||||||||||||||
Quantity of tray | 2 | 4 | 7 | 13 | 30 | 42 | 68 | 108 | 216 | ||||||||
Trays dimension | 300*400*25 | 630*390*35 | 1200*600*35 | 1280*600*35 | 1550*865*30 | customized | customized | customized | customized | ||||||||
Type Material | stainless steel 304 or other for option | ||||||||||||||||
Type of tray | Dish or mesh | ||||||||||||||||
Control system | Siemens Electrical , PLC , Touch screen panel | ||||||||||||||||
Working method | Freezing , vacuuming , Drying | ||||||||||||||||
Condense Temperature (Min) | ≤ - 45 ℃ | ||||||||||||||||
Heating Temperature | 100 ℃ Adjustable | ||||||||||||||||
Ultimate vacuum | ≤ 10 Pa | ||||||||||||||||
Defrost method | Circulation hot water for spraying | ||||||||||||||||
Power supply | 220v， 380v, 415v， 440v or according to user's voltage | ||||||||||||||||
Dimension | 1300*700*1500 | 1980*900*1600 | 2500*1360*1700 | 3700*1360*1900 | 4000*1700*1900 | customized | customized | customized | customized | ||||||||
Detailed Description
Freezing system,vacuum system
Automatic Touch screen control panel
SUS304.watching windows
Chicken,fruits drying with big capacity models
Dried strawberry ,blueberry
yogurt , milk , strawberry powder
Application
Before the large scale production, small sized pilot freeze dryer is used to get the data curve of freeze drying process. All the data about temperature, pressure inside the chamber and the weight of the drying material is saved in computer, which is the guidance of real mass production, and it’s also suitable for universities, institutes and other organizations for samples and crafts research or process testing, especially suitable for small production with high value-added.
LCD display makes it more clear to monitor the whole process, the pre-set curve can be revised in order to achieve the optimization of process options.
LCD display makes it more clear to monitor the whole process, the pre-set curve can be revised in order to achieve the optimization of process options.
Advantages of Freeze Dried Food
1. The drying speed is fast and the time is shortened by 3 times 10 times.
2 Because freeze-drying is carried out at low temperature,Proteins, microbes, etc., do not mutate or lose biological activity, and oxidizing substances are fully protected.
3. The volume is almost the same, the original structure is maintained, there will be no concentration, and the loss of some volatile components in the substance is very small.
2 Because freeze-drying is carried out at low temperature,Proteins, microbes, etc., do not mutate or lose biological activity, and oxidizing substances are fully protected.
3. The volume is almost the same, the original structure is maintained, there will be no concentration, and the loss of some volatile components in the substance is very small.
4. Taste fresh. Freeze-dried foods, like frozen, retain virtually all their fresh-food taste and nutritional content. Freeze-drying removes the water, not the flavor.
5. Look fresh. Freeze-dried foods maintain their original shape and texture, unlike dehydrated foods, which shrink and shrivel due to high-temperature processing. Freeze-drying removes water under low temperatures which keeps intact the moisture channels and food fibers. Just add water, and in minutes every fresh food detail returns.
6. Weigh less than fresh. Freeze-dried foods have 98% of their water removed. This reduces the food's weight by about 90%. Because of its light weight per volume of reconstituted food, freeze-dried products are popular and convenient for hikers. More dried food can be carried per the same weight of wet food, and remains in good condition for longer than wet food, which tends to spoil quickly. Hikers reconstitute the food with water available at point of use.
7. Stay fresh. Freeze-dried foods can be stored at room temperature, without deterioration or spoilage. This is because freeze-drying and packaging remove both water and oxygen - the two primary causes of food deterioration.
8. Regain freshness quickly. Freeze-dried products can be rehydrated (reconstituted) much more quickly and easily because the freeze drying process leaves microscopic pores. The pores are created by the ice crystals that sublimate, leaving gaps or pores in their place.
9. Long-Term Storage. The freeze dried product in sealed packaging can be stored and transported at room temperature for a long time. Freeze-drying increase the shelf life of product for years.
5. Look fresh. Freeze-dried foods maintain their original shape and texture, unlike dehydrated foods, which shrink and shrivel due to high-temperature processing. Freeze-drying removes water under low temperatures which keeps intact the moisture channels and food fibers. Just add water, and in minutes every fresh food detail returns.
6. Weigh less than fresh. Freeze-dried foods have 98% of their water removed. This reduces the food's weight by about 90%. Because of its light weight per volume of reconstituted food, freeze-dried products are popular and convenient for hikers. More dried food can be carried per the same weight of wet food, and remains in good condition for longer than wet food, which tends to spoil quickly. Hikers reconstitute the food with water available at point of use.
7. Stay fresh. Freeze-dried foods can be stored at room temperature, without deterioration or spoilage. This is because freeze-drying and packaging remove both water and oxygen - the two primary causes of food deterioration.
8. Regain freshness quickly. Freeze-dried products can be rehydrated (reconstituted) much more quickly and easily because the freeze drying process leaves microscopic pores. The pores are created by the ice crystals that sublimate, leaving gaps or pores in their place.
9. Long-Term Storage. The freeze dried product in sealed packaging can be stored and transported at room temperature for a long time. Freeze-drying increase the shelf life of product for years.
What's More
Related Products
Recommended by seller,Fruits , vegetables washing ,cleaning before drying
Packing & Delivery
Standard Fumigation-free wood packing or according to customer’s requirement 7~30 days after receiving clients full payment,We have long time working shipping forwarder. We can do our best to send machine to your port safe and quickly
Company Profile
We factory specializes in the R&D and promotion of the machines . We have good sales markets more than 150 countries.We have professional engineers and salesmen to serve all of our customers. Based on strong technical force, we are able to grow and develop well. We wholeheartedly welcome customers from both at home and abroad to visit us to discuss cooperation and seek common development. We believe our company is your most reliable partner and friend.
Manufacturing Technique
Cooperative partners and customers visits
Customers Feedback
Certifications
FAQ
How to Order
1. Customer send us an inquiry.
2. Confirm machine type, order quantity, price, lead time, payment term etc.
3.Our sales send the Proforma Invoice with company seal.
4. Customer make the payment for deposit and send us Bank receipt.
5. Inform the clients that we have got the payment,and will arrange the production according to your request,
inform the estimated time.
6. Production products photos will send to you for approval.
7. Clients make payment for balance and Ship the goods .
8. Order is finished when you receive the goods and satisfy with them .
9. Feedback to us bout Quality , Service, Market Feedback & Suggestion.
1. Customer send us an inquiry.
2. Confirm machine type, order quantity, price, lead time, payment term etc.
3.Our sales send the Proforma Invoice with company seal.
4. Customer make the payment for deposit and send us Bank receipt.
5. Inform the clients that we have got the payment,and will arrange the production according to your request,
inform the estimated time.
6. Production products photos will send to you for approval.
7. Clients make payment for balance and Ship the goods .
8. Order is finished when you receive the goods and satisfy with them .
9. Feedback to us bout Quality , Service, Market Feedback & Suggestion.
Our Service
About after sell service
Usually machine guarantee time is about 1 year . Within guarantee time . Machine breaking caused by machine
itself design defect , we are responsible for it .we can provided free charge breaking part, .If machine
breaking caused by humane factor , user need take responsibility for it , we will provided technical support .
we can do better
itself design defect , we are responsible for it .we can provided free charge breaking part, .If machine
breaking caused by humane factor , user need take responsibility for it , we will provided technical support .
we can do better
About our online Service
24 hours online to solve any problem .
our email will be reply within 12 hours .
Your satisfy is our pursuit .
sincerely hope our cooperation
24 hours online to solve any problem .
our email will be reply within 12 hours .
Your satisfy is our pursuit .
sincerely hope our cooperation
