Hot selling hydraulic single cylinder thermoplastic hot melt paint melter kettle

The hydraulic double-cylinder hot-melt kettle is used for hot-melt coatings in the hot-melt marking construction. The principle is to use a diesel engine as a power source. The hydraulic motor drives the stirring blade to stir through the hydraulic device. It can stir in both positive and negative directions to ensure uniform mixing.

 Since the price of raw materials will fluctuate in different periods, the online price is a reference price, not the final price. But we can guarantee the same quality and the lowest price among the peers.
If you are interested in our products, please feel free to contact us, we will give you a real-time quotation as soon as possible

Product features hot melt kettle

(1) Independent research and development in the integrated hybrid power of steam and electricity, electric drive technology, hot melt kettle, low emission, low energy consumption and energy saving.

(2) Advanced intelligent ignition, detection and temperature control technology.

(3) Unique design of oil jacket hot melt kettle.

(4) Design of thermal cycle heating system.

(5) Design of discharging system.

(6) The whole machine has a low center of gravity design.

(7) Electric stirring.

(8) Anti-clogging design of hot melt kettle

Main technical parameters of hot melt kettle

Engine: 15PS electric start evaporative water-cooled diesel engine

Hydraulic drive system: multi-channel hydraulic control valve, forward and reverse mixing, no speed change

The internal structure of the kettle body: the double-layer pot wall is used to control the fire path (for the B kettle: special stainless steel bottom and wall, and the special stainless steel pot wall is used to control the fire path)

Hydraulic motor: BM 500 type

Hydraulic oil tank volume: 70 liters

Structure: frame structure, double-layer insulation material is installed between the inner bladder and the outer wall of the kettle

Heating system: liquefied petroleum gas (50kg tank is recommended), direct injection stove

Melting tank: can hold 600kg x 2 (800 kettle: 400kg x 2)

Shape structure: high-strength, high-temperature resistant, gasification resistant stainless steel steel plate structure design

Device: specially designed overload overflow device to prevent misoperation

Size and reset: 1900*1660*1630mm 900kg
