Вакуумная сушилка для фруктов бананы ягод
- Категория: Vacuum Drying Equipment >>>
- Поставщик: Jiangyin,Brightsail,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 10829.55 $* | 11370.4 $* |
| Aug-17-2025 | 10738.17 $* | 11275.4 $* |
| Jul-17-2025 | 9009.64 $* | 9459.47 $* |
| Jun-17-2025 | 10556.43 $* | 11084.43 $* |
| May-17-2025 | 9191.62 $* | 9651.85 $* |
| Apr-17-2025 | 10374.2 $* | 10893.25 $* |
| Mar-17-2025 | 10283.40 $* | 10797.82 $* |
| Feb-17-2025 | 10192.58 $* | 10702.87 $* |
| Jan-17-2025 | 10101.61 $* | 10606.44 $* |
Характеристики
Food grade banana berry pineapple fig lab vacuum dehydrator fruit drying oven
Product Description
BSVD drying oven is suitable for drying heat sensitive raw materials which often decompose, polymerize or metamorphose under high temperature.It is widely used in the final of pharmaceutical, chemical, foodstuff and electronic industry.Such as vegetables, fruits, condiments, aquatic products, biological products, medicine, etc.
For BSVD fruit drying oven,material will be dried under vacuum condition. Under the vacuum condition, the boiling point of material solution will reduce. It will increase impetus for heat and mass exchange. Therefore for certain heat exchange amount, it can save heat exchange area of evaporator.
For BSVD fruit drying oven,material will be dried under vacuum condition. Under the vacuum condition, the boiling point of material solution will reduce. It will increase impetus for heat and mass exchange. Therefore for certain heat exchange amount, it can save heat exchange area of evaporator.
Specification
Working method:
Pure water has the maximum vaporization rate when it is boiling. Under normal pressure, pure water starts to boil at about 100°C. Under vacuum conditions, because the partial pressure of water vapor in the system is much lower than the partial pressure of water vapor on the surface of the material, the boiling point of water is lower than 100°C. For example: when the surface drops to -0.07Mpa, the water starts to boil at 70°C. General rule: the higher the vacuum, the lower the boiling point of water. In the vacuum dryer, the vaporized water can be quickly removed with the vacuum generation, so even at a lower operating temperature, the dryer still has a greater drying capacity.
Pure water has the maximum vaporization rate when it is boiling. Under normal pressure, pure water starts to boil at about 100°C. Under vacuum conditions, because the partial pressure of water vapor in the system is much lower than the partial pressure of water vapor on the surface of the material, the boiling point of water is lower than 100°C. For example: when the surface drops to -0.07Mpa, the water starts to boil at 70°C. General rule: the higher the vacuum, the lower the boiling point of water. In the vacuum dryer, the vaporized water can be quickly removed with the vacuum generation, so even at a lower operating temperature, the dryer still has a greater drying capacity.
Main features:
1. When the equipment is running, the material is in a static state. It is helpful to maintain the original shape of the material
2. Intermittent operation, can adjust the process conditions at any time, this equipment is manual loading and unloading.
3. The square series dryer, with an arched structure on the top, can effectively overcome the problem of condensed water dripping back and further improve the drying efficiency. The exclusive design adopts a four-point vacuum structure to ensure the uniformity of material drying. .
4. This equipment can be used for low temperature drying and solvent recovery.
5. Especially suitable for materials that are afraid of oxidation and easy to decompose during the drying process.
1. When the equipment is running, the material is in a static state. It is helpful to maintain the original shape of the material
2. Intermittent operation, can adjust the process conditions at any time, this equipment is manual loading and unloading.
3. The square series dryer, with an arched structure on the top, can effectively overcome the problem of condensed water dripping back and further improve the drying efficiency. The exclusive design adopts a four-point vacuum structure to ensure the uniformity of material drying. .
4. This equipment can be used for low temperature drying and solvent recovery.
5. Especially suitable for materials that are afraid of oxidation and easy to decompose during the drying process.
Company Profile
Our company-Brightsaill Machinery Co., Ltd is focus on the research of powder equipment, such as drying oven, lab vacuum drying oven, chemical powder mixer machine, spice powder making machine... etc. Our products can be applied in food, medicine, chemical and other industries and had won a good reputation.
After 15 year's development and accumulation, our company has been one of the most influential equipment manufacturers in the industry. And we wish to grow up and develop together with all new and old customers.
After 15 year's development and accumulation, our company has been one of the most influential equipment manufacturers in the industry. And we wish to grow up and develop together with all new and old customers.
Buyer feedback
Our Services
Packing & Delivery
*Usually small machine(BSVD drying oven) will be packed in the wooden case, and we can also pack it according to customers special request.
*If machine is big(BSVD drying oven), we will fix the machine inside container with steel wires and nails. Machine won't move inside the container.
*If machine is big(BSVD drying oven), we will fix the machine inside container with steel wires and nails. Machine won't move inside the container.
