304 316 Болтовой резервуар для воды из нержавеющей стали дренажные резервуары Gesoleerde прямоугольный квадратный
- Категория: Chemical Storage Equipment >>>
- Поставщик: Dezhou,Huili,Water,Tank,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 83.35 $* | 87.14 $* |
| Aug-16-2025 | 83.46 $* | 87.89 $* |
| Jul-16-2025 | 69.32 $* | 72.99 $* |
| Jun-16-2025 | 81.8 $* | 85.82 $* |
| May-16-2025 | 71.64 $* | 75.32 $* |
| Apr-16-2025 | 80.80 $* | 84.81 $* |
| Mar-16-2025 | 79.97 $* | 83.41 $* |
| Feb-16-2025 | 78.74 $* | 82.26 $* |
| Jan-16-2025 | 78.44 $* | 82.52 $* |
Характеристики
Stainless Steel Water Tank
Stainless steel water tank is the best material of water reserve. It has two connection types: argon arc welding & bolted. The appearance and structure of bolted type is same with hot dipped galvanized water tank. Raw material can be SS304/2B and SS316L.
Advantages
Product Structure
Accessories show
ACCESSORY NAME | OPTIONAL MATERIAL | ||||
Bolts & Nuts | Hot dipped galvanized | Stainless steel 304/316 | |||
Skid Base | Hot dipped galvanized | Painting | |||
Internal Structure | Hot dipped galvanized | Stainless steel 304/316 | |||
Water Indicator | Glass with brass valve | Float type | |||
Sealing Rubber | Food grade white color EPDM | Silicon | |||
Flanges | Hot dipped galvanized | Stainless steel 304/316 | PVC | ||
Product Paramenters
Physical properties | Standard requirement | Result |
Tensile strength | ≥515 MPa | 695 MPa |
Yield strength | ≥205 MPa | 309 MPa |
Elongation | ≥40% | 54% |
Hardness | ≤92HRBS | 85HRBS |
Tank Height(mm) | Thickness of each panel | ||||||||||||
Bottom | 1st layer | 2nd layer | 3rd layer | 4th layer | 5th layer | Roof | |||||||
1000 | 3mm | 2.5mm | / | / | / | / | 2mm | ||||||
1500 | 3mm | 2.5mm | 2.5mm | / | / | / | |||||||
2000 | 3mm | 3mm | 2.5mm | / | / | / | |||||||
2500 | 3mm | 3mm | 3mm | 2.5mm | / | / | |||||||
3000 | 3mm | 3mm | 3mm | 2.5mm | / | / | |||||||
3500 | 4mm | 4mm | 3mm | 2.5mm | 2.5mm | / | |||||||
4000 | 4mm | 4mm | 3mm | 3mm | 2.5mm | / | |||||||
4500 | 5mm | 4mm | 3mm | 3mm | 2.5mm | 2.5mm | |||||||
5000 | 5mm | 4mm | 3mm | 3mm | 2.5mm | 2.5mm | |||||||
The standard tolerance of thickness is 0.25mm. For example, the actual thickness of 3mm is 2.75mm.
Why Choose Us
Packing & Delivery
FAQ
Q: Are you trading company or manufacture?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. Or it is 10-15 days if the goods are not in stock, it is according to the
quantity.
quantity.
Q: Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment?
A: Payment <= 1000USD, 100% in advance. Payment >= 1000USD, 30% T/T in advance, balance before shippment. If you have other questions, pls feel free to contact us as below:
