Оптовая продажа портативный высокоэффективный металлонагревательный индукционный трубный нагреватель Индукционное
- Категория: Other Welding Equipment >>>
- Поставщик: Zhengzhou,Daqing,Automation,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 4939.13 $* | 5186.63 $* |
| Aug-19-2025 | 4897.73 $* | 5142.22 $* |
| Jul-19-2025 | 4109.88 $* | 4314.74 $* |
| Jun-19-2025 | 4814.63 $* | 5055.47 $* |
| May-19-2025 | 4192.30 $* | 4402.90 $* |
| Apr-19-2025 | 4731.14 $* | 4968.52 $* |
| Mar-19-2025 | 4690.28 $* | 4925.63 $* |
| Feb-19-2025 | 4648.7 $* | 4880.63 $* |
| Jan-19-2025 | 4607.67 $* | 4837.87 $* |
Характеристики
FD-M series induction heating machine
ultrahigh frequency induction brazing equipment for shunt:
1. Small volume, light weigh and energy saving (saving 70% than the glass ceramic tube high frequency machine).
2. It can heat and weld minimum 0.1 mm work piece. The welding points are beautiful and delicate, the surface pattern will not be damaged, the internal crystal structure of the metal won’t be changed.
3. Working frequency 20-50 Khz, Power 10-25 kw. Other frequency and power can be customized.
Adopt DSP full digital control system:
1. Accurate control in constant current mode, current fluctuation does not exceed 0.5A, high repeat accuracy, basically no deviation.
2. It can realize continuous segmented heating and can be applied to various complex environments.
3. Color screen display, convenient and easy to operate, can be used after simple training.
4. Complete protection functions, undervoltage, water shortage, overcurrent, overheat protection of the core components of the equipment.
5. Rich interface forms to facilitate communication with PLC and computer.
6. Program control, easy to achieve system upgrade.
1. Accurate control in constant current mode, current fluctuation does not exceed 0.5A, high repeat accuracy, basically no deviation.
2. It can realize continuous segmented heating and can be applied to various complex environments.
3. Color screen display, convenient and easy to operate, can be used after simple training.
4. Complete protection functions, undervoltage, water shortage, overcurrent, overheat protection of the core components of the equipment.
5. Rich interface forms to facilitate communication with PLC and computer.
6. Program control, easy to achieve system upgrade.
Specifications and technical parameters | ||||||||||
Model | FD-M25 | FD-M40 | FD-M50 | FD-M60 | ||||||
Input power | Input voltage（50HZ） | 360-420V | 360-420V | 360-420V | 360-420V | |||||
Continuous input current | 15A | 24A | 30A | 36A | ||||||
Intermittent input current | 25A | 40A | 50A | 60A | ||||||
Power output | Continuous output power | 10 KW | 15 KW | 20 KW | 25 KW | |||||
Max output power | 15 KW | 25 KW | 32 KW | 40 KW | ||||||
Output frequency | 20-50KHZ | 20-50KHZ | 20-50KHZ | 20-50KHZ | ||||||
Cooling water flow | 2 L/min | 4 L/min | 6 L/min | 7 L/min | ||||||
Cooling water pressure | 4-8bar | 4-8bar | 4-8bar | 4-8bar | ||||||
Max inlet water temperature | 32℃ | 32℃ | 32℃ | 32℃ | ||||||
Cooling water quality requirements | Scale free purified water | Scale free purified water | Scale free purified water | Scale free purified water | ||||||
Generator parameters | Generator size | 600*306*328mm | 600*306*328mm | 600*306*328mm | 600*306*328mm | |||||
Generator weight | 30 kg | 32 kg | 38 kg | 40 kg | ||||||
Coaxial transformer parameters | Transformer size | φ50*160mm | φ50*160mm | φ50*160mm | φ80*160mm | |||||
Transformer weight | 2.5kg | 2.6kg | 2.8kg | 4.5kg | ||||||
Flexible cable length | 2-10m | 2-10m | 2-10m | 2-10m | ||||||
Pipe brazing
Copper pipe brazing
Portable induction brazing
