LEJIANG YJ-125 круглая машина для резки ткани
US $10.00-$1000
Автоматический настольный маленький резак для ткани машина резки хлопковых лент рулонов бумаги на
- Категория: Cloth Cutting Machines >>>
- Поставщик: Suzhou,Flying,Man,Assembly,Automation,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.72 $* | 0.24 $* |
| Aug-15-2025 | 0.60 $* | 0.15 $* |
| Jul-15-2025 | 0.71 $* | 0.24 $* |
| Jun-15-2025 | 0.11 $* | 0.51 $* |
| May-15-2025 | 0.96 $* | 0.47 $* |
| Apr-15-2025 | 0.63 $* | 0.92 $* |
| Mar-15-2025 | 0.46 $* | 0.46 $* |
| Feb-15-2025 | 0.51 $* | 0.45 $* |
| Jan-15-2025 | 0.87 $* | 0.79 $* |
Характеристики
Video Description
This machine adopts microcomputer numerical control display device, cutting length/quantity, feeding speed is set freely, add adjustable roller feeding mechanism, both sides automatically adjust the pressure and rise, can quickly release material, and prevent material damage effectively with thimble type feeding mechanism.
This machine mainly suitable for high speed cold/hot full/half cut strip.
High precision, low loss, model design in line with the principle of ergonomics, simple operation and high automation, saving a lot of manpower and material resources.
Product Paramenters
Fully automatic micro-computer cutting machine | ||||||||||
Model | FMHZ-100 | FMHZ-160 | FMHZ-200 | FMHZ-260 | FMHZ-300 | |||||
Cutting length | 0.1 mm-9999.9 mm | |||||||||
Cutting Width | 0 - 85 mm | 0 - 150 mm | 0 - 185 mm | 0 - 240 mm | 0 - 280 mm | |||||
Feeding speed | Adjustable | |||||||||
Power | 0.3 kw | 0.55 kw | 0.6 kw | 0.65 kw | 0.75 kw | |||||
Voltage | 220 v /50 hz | |||||||||
Feeding motor | 86 Stepper motor | |||||||||
Cutting motor | AC gear motor | |||||||||
Feed roller | PUR | |||||||||
Cutter material | High speed steel or Art Knife | Imported SKD2 material blade | ||||||||
Machine Weight | 29 kgs | 40 kgs | 45 kgs | 50 kgs | 55 kgs | |||||
Machine size (mm) | 400 x 350 x 390 | 470 x 375 x 340 | 400 x 550 x 390 | 650 x 480 x 350 | 650 x 530 x 360 | |||||
Performance Feature
Special cutting tools
Special mechanical structure and special cutting tools, with professional software control to completely solve the problem of uneven incision and achieve the incision level/degree of accuracy.
Core technology
Independent development of the special cutting machine motion control system is the core technology, which is suitable for all industries equipment fixed-length cutting.
Timing, quantitative and fixed speed
The length and speed can be adjusted continuously to achieve high efficiency.
Cutter speed can be adjustable, high and low speed of cutting machine can be fully controlled.
Set up automatic group accumulator and total accumulator count.
Cutter speed can be adjustable, high and low speed of cutting machine can be fully controlled.
Set up automatic group accumulator and total accumulator count.
Numerical control display device
This machine adopts microcomputer numerical control display device, cutting length/quantity and feeding speed can be set freely, add adjustable roller feeding mechanism, both sides automatically adjust the pressure and rise and fall. With thimble type feeding mechanism, it can be fast feeding.
86 stepper motor
86 stepper motor ensure precise feeding, strong power, fast heat dissipation, speed, step length accurate control. And also ensure smooth/high precision cutting material with short time.
Save time and effort and materials.
Save time and effort and materials.
Advantages & Features
- Special mechanical structure and special cutting tools, with professional software control to completely solve the problem of uneven incision and achieve the incision level/degree of accuracy.
- Independent development of the special cutting machine motion control system is the core technology, which is suitable for all industries equipment fixed-length cutting.
- Large screen LCD display, easy to operate, simple and convenient.
- High speed feeding, under microcomputer program control, material's accuracy can be up to 0.1mm.
- The length and speed can be adjusted continuously to achieve high efficiency.
- Cutter speed can be adjustable, high and low speed of cutting machine can be fully controlled.
- Set up automatic group accumulator and total accumulator count.
- Batch pause and delay time can be set.
- Independent development of the special cutting machine motion control system is the core technology, which is suitable for all industries equipment fixed-length cutting.
- Large screen LCD display, easy to operate, simple and convenient.
- High speed feeding, under microcomputer program control, material's accuracy can be up to 0.1mm.
- The length and speed can be adjusted continuously to achieve high efficiency.
- Cutter speed can be adjustable, high and low speed of cutting machine can be fully controlled.
- Set up automatic group accumulator and total accumulator count.
- Batch pause and delay time can be set.
Imported white steel blade
High speed steel or Art knife (choose the right knife according to the material).
With professional software control to completely solve the problem of uneven incision, and achieve the level of incision.
LCD large screen display
Easy to operate, simple and convenient.
Cooling fans
Increase the heat dissipation effect to ensure the continuous operation of the equipment. Not only reduce the cutting time, but
also increase the work efficiency.
also increase the work efficiency.
86 stepper motor
With powerful power, high precision and fast speed, this machine can cut hard materials, such as wire rope, copper, aluminum foil, welding iron, wire, cable, and so on.
Underfeeding sensor
Automatic stop when the material underfeeding. Set up automatic group cumulative and total count. And batch pause and delay time
can be set.
can be set.
Product Application
This machine is suitable to cut heat shrinkable tube, glass fiber tubes, teflon pipe, yellow wax tube, Velcro, nickel belt, webbing, nylon ribbon, paper and so on (so also called: heat shrinkable tube cutting machine, glass fiber pipe cutting machine, teflon pipe cutting machine, yellow wax cutting machine, Velcro cutting machine, nickel belt cutting machine, computer cutting machine, automatic cutting machine, etc.)
With the small body, it doesn't take up space and can increase production.
It is widely used in electronics industry, automobile and motorcycle parts industry, clothing and leather industry, electrical appliances, motors, toys, transformers and other industries (different materials have different requirements).
It is widely used in electronics industry, automobile and motorcycle parts industry, clothing and leather industry, electrical appliances, motors, toys, transformers and other industries (different materials have different requirements).
Whole Service
Technical Service
- Free sample testing and video for your reference.
- Technical support: Professional engineers’ team to help you design a whole-set product line to get highest profit with lowest cost and offer you technical support any time.
Training service
Free training in our factory available before delivering machines.
Engineers available to service machinery overseas. Overseas service center in Vietnam available.
Engineers available to service machinery overseas. Overseas service center in Vietnam available.
After Sales Service
- Every customer can get one piece of English operation manual , a total working video for machines ,details on every button function ,normal notice when operation.
- One-year warranty, whole life technical support.
- One-year warranty, whole life technical support.
- 24 hours technical support, we will do our best to help our customers solve problems.
- We offer not only the products, but also the solutions. Plenty of cooperated professional supplier for mold or other necessary equipment make it possible for us to offer our customers big convenience to complete their production line in high quality with low cost in a short time.
