Заводская Продажа солнечный инвертор 3 фазы 192 в 240 38 автономный 10 кВт 20 35 50 70 100 для солнечной
- Категория: Солнечные инверторы >>>
- Поставщик: Foshan,Top,One,Power,Technology,Co.,Ltd.Foshan,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 268174.55 $* | 281583.75 $* |
| Aug-17-2025 | 265920.12 $* | 279216.93 $* |
| Jul-17-2025 | 223102.40 $* | 234257.17 $* |
| Jun-17-2025 | 261413.36 $* | 274484.10 $* |
| May-17-2025 | 227610.56 $* | 238991.82 $* |
| Apr-17-2025 | 256906.84 $* | 269751.81 $* |
| Mar-17-2025 | 254652.3 $* | 267385.36 $* |
| Feb-17-2025 | 252399.70 $* | 265019.18 $* |
| Jan-17-2025 | 250145.81 $* | 262652.10 $* |
Характеристики
Factory sell solar inverter 3 phase 192v 240v 38v off grid 10KW 20KW 35KW 50KW 70KW 100KW solar inverter for solar energy system
Product advantage :
1. The efficiency is upto 90%.
2. 64-bits DSP Intelligent control chip.
3. Result fetched from effective value, not average value.
4. Photoele ctricity isolation circuitry technology.
5. Switching power is supplied by the independent system.
6. True over temperature protection.
7. The full bridge rectifier and mainboard structure are highly optimized. Input and output circuits are isolated.
8. Strong loading capacity with a true onetime soft start.
9. New and original electronic components.
10. Internal circuit lines and signal lines are based on plug-pull blocks, not welding.
11.Equipped with RS485 port, can connect to the external screen, and WiFi connector, check the receipt at any time.
12.Unattended mode: The inverter will automatically start and provide AC output ，when the battery voltage is restored.
1. The efficiency is upto 90%.
2. 64-bits DSP Intelligent control chip.
3. Result fetched from effective value, not average value.
4. Photoele ctricity isolation circuitry technology.
5. Switching power is supplied by the independent system.
6. True over temperature protection.
7. The full bridge rectifier and mainboard structure are highly optimized. Input and output circuits are isolated.
8. Strong loading capacity with a true onetime soft start.
9. New and original electronic components.
10. Internal circuit lines and signal lines are based on plug-pull blocks, not welding.
11.Equipped with RS485 port, can connect to the external screen, and WiFi connector, check the receipt at any time.
12.Unattended mode: The inverter will automatically start and provide AC output ，when the battery voltage is restored.
Model | DB-10K | DB-30K | DB-40K | DB-50K | DB-60K | DB-80K | DB-100K | DB-150K | DB-200K | |||||||||
Rated Power | 10KVA | 30KVA | 40KVA | 50KVA | 60KVA | 80KVA | 100KVA | 150KVA | 200KVA | |||||||||
Peak Power | 30KVA | 90KVA | 80KVA | 150KVA | 180KVA | 240KVA | 300KVA | 450KVA | 600KVA | |||||||||
Input | ||||||||||||||||||
Voltage | 380VAC±20% | |||||||||||||||||
Frequency Range | 50/60hz±10% | |||||||||||||||||
Output | ||||||||||||||||||
AC Voltage Regulation (Batt.Mode） | （DC Batt.Mode） 380VAC±1% | |||||||||||||||||
Tansfer time | 0ms | |||||||||||||||||
wave form | Pure Sine Wave | |||||||||||||||||
Battery | ||||||||||||||||||
Battery Voltage | 192V/384VDC | 384VDC | ||||||||||||||||
Floating Charge Voltage | 220V/440VDC | 408VDC | ||||||||||||||||
AC Charger | ||||||||||||||||||
Maximum AC charge current | 10-30A（Adjustable） | |||||||||||||||||
Other | ||||||||||||||||||
Display | LCD Display | |||||||||||||||||
Physical | ||||||||||||||||||
Dimension，D*W*H(mm) | 730*456*1165mm | 1000*660*1460mm | 1100*897*1478mm | 820*1170*1670mm | ||||||||||||||
G.W(KGS) | 175 | 275 | 290 | 480 | 510 | 570 | 720 | 850 | 910 | |||||||||
Envionment | ||||||||||||||||||
Humidity | 5%-95%（No condesnsation) | |||||||||||||||||
Operating temperature | 0-40℃ | |||||||||||||||||
Storage temperature | 0-60℃ | |||||||||||||||||
*Product specifications are subject to change without further notice | ||||||||||||||||||
