13 м гидравлический шнек для перевозки корма
- Категория: Грузовые прицепы >>>
- Поставщик: Xinbaiqin,Special,Vehicle,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 50863.96 $* | 53406.44 $* |
| Aug-18-2025 | 50436.4 $* | 52958.50 $* |
| Jul-18-2025 | 42315.30 $* | 44431.66 $* |
| Jun-18-2025 | 49581.54 $* | 52060.89 $* |
| May-18-2025 | 43169.1 $* | 45327.88 $* |
| Apr-18-2025 | 48726.66 $* | 51162.97 $* |
| Mar-18-2025 | 48298.21 $* | 50713.72 $* |
| Feb-18-2025 | 47871.99 $* | 50265.99 $* |
| Jan-18-2025 | 47444.58 $* | 49816.1 $* |
Характеристики
Product Select
Specification
Vehicle Parameters | Overall Dimensions （L*W*H)(mm) | 12955×2550×3980 | Tank Dimension （L*W*H）(mm) | 12220×2540×2270 | ||
Total Mass（kg） | 34850 | Curb Weight（kg） | 12350 | |||
Bulletin loading（kg） | 22500 | Theoretical loading（kg） | 27000 | |||
Appearance color | White/ optional | Certification | ISO9001, 3C | |||
Chassis Parameters | Parking brake type | Manual valve control spring brake cylinder | ||||
Driving brake system | Independent double circuit, air pressure, drum brake belt ABS | |||||
Tire specifications | 11R22.5 16PR | |||||
Trailer traction pin height from the ground(mm) | 1228 | |||||
Trailer radius of gyration(mm) | 1600 | |||||
Trailer gap radius | 2300 | |||||
Wheelbase（mm) | 7050+1310+1310 | |||||
Tank gross volume (m3) | 56 | Space quantity | 6 | |||
Conveying height（m） | 10.2 | Max conveying distance（m） | 8.8 | |||
Discharge speed（Kg/min） | 550-650 | Residual rate（%） | ≤0.22 | |||
Discharge by | Hydraulic auger | |||||
Tank drive form | The feed is conveyed by the lifting auger to the manual and wireless remote-control mode to realize long-distance transport and improve the level of epidemic prevention. And the external power is available. | |||||
Electrical configuration | Complete set of Schneider Electric control system; conveyor motor ABB, with 20m external power cable, external power supply 380V | |||||
Hydraulic auger | Use the patent of intermediate support structure、Graphite bearing；Lifting auger steering with wireless remote control | |||||
Painting | Professional anti-corrosion paint，Process: sandblasting、polishing, painting | |||||
Tank | Made of high quality carbon steel sheet；The proof is sloping, which increase the fullness and safety factor；and Strict welding process guarantees quality. | |||||
Factory Display
Company Profile
Why Choose Us
Professional R&D team: dedicated to the design, development and production of bulk feed trucks, bulk feed tanks, livestock and poultry transport vehicles.
Shipping And Packaging
FAQ
Q1: What’s your MOQ?
A: One unit or one sets.
Q2: What are your trade terms?
A: EXW/FOB/CIF/others.
Q3: What’s your payment terms?
A: 30% deposit, 70% balance before shipment by T/T
Q4: What is the delivery time?
A: Usually it takes 20 working days after 30% advance received, but some models will take longer time.
Q5: What certificates do you have?
A: All our products have CCC certificates and ISO certificates, SGS and BV identification.
Q6: What’s the warranty for our products?
A: Technical support by phone or email for life once you purchase our products.
Prompt solution for any quality problem (not man-made damage).
Spare parts support with competitive price if you have necessary.
A: One unit or one sets.
Q2: What are your trade terms?
A: EXW/FOB/CIF/others.
Q3: What’s your payment terms?
A: 30% deposit, 70% balance before shipment by T/T
Q4: What is the delivery time?
A: Usually it takes 20 working days after 30% advance received, but some models will take longer time.
Q5: What certificates do you have?
A: All our products have CCC certificates and ISO certificates, SGS and BV identification.
Q6: What’s the warranty for our products?
A: Technical support by phone or email for life once you purchase our products.
Prompt solution for any quality problem (not man-made damage).
Spare parts support with competitive price if you have necessary.
