Лидер продаж с завода волоконная лазерная маркировочная машина 20 Вт 30 50 источник raycus JPT
- Категория: >>>
- Поставщик: Xiamen Peihong Machinery Co., Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 240447.44 $* | 252469.14 $* |
| Aug-17-2025 | 238426.73 $* | 250347.56 $* |
| Jul-17-2025 | 200035.23 $* | 210037.44 $* |
| Jun-17-2025 | 234385.41 $* | 246104.46 $* |
| May-17-2025 | 204077.80 $* | 214281.37 $* |
| Apr-17-2025 | 230344.82 $* | 241861.37 $* |
| Mar-17-2025 | 228323.27 $* | 239739.42 $* |
| Feb-17-2025 | 226303.49 $* | 237618.55 $* |
| Jan-17-2025 | 224282.73 $* | 235496.94 $* |
Характеристики
FACTORY SALE Best seller fiber laser marking machine 20w 30w 50W raycus JPT IPG source
| Name: China 20W 30W 50W Desktop metal and nonmetal CNC Fiber laser marking machine price for logo/QR code/bar code |
|
Flying Laser Marking Printer can be equipped with different kinds of laser sources (fiber, co2, or UV) and printer system. It can be widely used in food and beverage, pharmaceutical, tobacco, leather industry etc. This is the 30W fiber source flying laser marking printer, it could be used for metal and nonmetal flying marking combined with various kinds of the production line. There is another co2 laser source online laser marking printer available especially for nonmetal materials’ online marking. |
Product Description
Flying Fiber Laser Marking Machine Flying Marking, also called online laser marking;Advanced digital high-speed scanning galvanometer;Embedded laser operating software system.
Flying Fiber Laser Marking Printing Machine General Introduction: Flying Laser Marking Printing Machine 30W is laser marking printer especially matched for the automatic production line for flying printing & marking for the date codes or barcodes. Compared to the traditional inkjet printer, Flying Laser marking printer has zero consumption of any materials, no need ink, no pollution, no noise, energy saving and environmental protective.
Product Application
![sample co2 laser marker.jpg]()
![15]()
Application Industry:
Fiber Laser Online Marking Machine is widely used in the marking of packaging industry, such as anti-counterfeiting laser spraying code (drug monitoring code), anti-counterfeiting chain traceability system (bottle cap system), anti-counterfeiting marking of food and beverage, three-code marking of daily hygiene products, smart card information marking, anti-counterfeiting marking of tobacco, online marking of pipes etc.
Flying online laser marking printer for the automatic production line, compared to the traditional inkjet printer, Online Laser marking printer has zero consumption of any materials, no need ink, no pollution, no noise, energy conservation and environmental protection.
Flying Fiber Laser Marking Printing Machine Application:
The machine can be widely used in food and beverage,pharmaceutable, tobacco, leather, package, building materials, lighting, accessories, cosmetics, electronics,kitchen&bathroom hardware, shells of cell phone and watches, medical apparatus and instruments, tubular product, cable, plastic, cable and other industries.
Technical Parameters
| Industrial Laser Marker Machine Parameters | |
| Optional Model | LBF20/LBF30/LBF50 |
| Laser Power | 20W30W50W(optional) |
| Laser Source | China DAVI or CRD CO2 laser-Support customization |
| Laser Wavelength | 1064 nm |
| Beam Quality | M2 < 1.4 |
| Modulation Frequency | 20kHz~100kHz |
| Marking Range | 30mm x 30mm - 300mm x 300mm can be optional |
| Carving Speed | ≤7000 mm/s(Adjustable) |
| Carving Depth | 0.01~0.4mm(10W) ; ≤1.0mm(50W) according to material |
| Focusing Mode | Support for automation or manual |
| Marking Speed | 1500-2000characters/Min |
| Minimum Line Width | 0.001 mm |
| Minimum Characters | 0.15 mm |
| Repeatability Accuracy | ±0.002 mm |
| Cooling Method | Air Cooling |
| Use Environment | IP4 Clean, dustless or less dusty |
| Laser Type | Pulse or continuous |
| Control Software | NOAH marking control software |
| Graphic Format Supported | bmp, jpg, gif, tga, png,tif,ai,dxf,dst,plt,etc. |
| Laser Indicator | Double Red dot pointer |
| Operating System | Win98/Win2000/WinXP/win7 (64,32bit)win8/win10 |
| Working Temperature | 0-35 ℃,90% or humidity |
| Power Consumption | ≤ 550 W |
| Electricity Demand | AC110V-240V±10%,50 HZ/60HZ |
| This product contains computers. The following is the configuration list of the dedicated computers. | |
| Computer Configuration Parameters | |
| CPU | Intel G630X2/I3 540 |
| Memory | ADATA 4G/8G DDR3L 1600 |
| BIOS | AMI EFI BIOS |
| Super I/O | Winbond W83627DHG-P / HG41/HG55 |
| Ethernet | 1x LAN Intel I211(IO) |
| GPU | Intel HD Graphics |
| Display Interface | 1x HDMI:1920×1200@60Hz |
| Hard Disk | 60G/120G/500G |
| USB Interface | 4xUSB |
| Serial Port | 1x RS232,COM1,RS422,RS485 |
| Operating System | Windows 7 32bit;Can support/Windows 8/Windows 10/Linux |
| Working Temperature | 0℃~ 60℃ |
| Storage Temperature | -40℃~ 85℃ |
| Humidity | 5% ~ 95% Relative humidity, no condensation |
Product Details
Efficiency: compact structure, professional support can be easily installed on the assembly line, complex working conditions of the assembly line can also cope with free, easy to adapt to the needs of industrial mass production.
Low Cost: high electro-optic conversion rate, no consumables, saving processing costs
Long Service Life: professional industrial laser, to ensure faster marking speed and consistency of marking, to ensure 24-hour continuous and stable processing, maintenance-free time of 100,000 hours+
Easy to Operate: friendly man-machine dialogue interface, what you see is what you get, easy to operate, free from the trouble of frequent changes of workers.
Packaging & Shipping
| Packing List | |
|
It is composed of fiber laser, high-speed scanning mirror, control software, computer, switching power supply control chip set and precision Z-axis elevator.
Inside: Shockproof multilayer foam packaging high-end, safe, easy to carry and store; support customized packing. |
|
| Packaging size/weight(mm):900(L)*800(W)*1060(D) / 120KG | |
| Part Name | Quantity |
| Fiber laser | 1 set |
| High speed scanning galvanometer | 1 set |
| Focusing lens | 1 set |
| Marking software | 1 set |
| Indicator locator | 1 set |
| Power switch | 1 set |
| Laser frame | 1 set |
| Print foot | 1 set |
| Equipment switch | 1 set |
| Control computer(Include) | 1 set |
| Rotary Printing Table (Order) | 1 set |
| Instructions | 1 set |
