Good Quality 3 Axles 52600 LPG Petroleum Gas Pressure Vessel Tanker Trailer for

Цена:35 500,00 $ - 36 800,00 $*

Количество:

Good Quality 3 Axles 52600 LPG Petroleum Gas Pressure Vessel Tanker Trailer for Sale

Product Description

Product Display

SPECIFICATIONS FOR TANK TRAILER
DIMENSIONS
Tare weight	10500kg
Overall Size	11900mm2500mm3900mm
Volume	42000 liters
SPECIFICATION
Tank body	Q235/4mm steel
End plate	Q235/6mm steel sheet
Axle	3 axle 13TFuwa Brand
Suspension	Mechanical Suspension
Leaf spring	Standard
Manhole cover	500mm manhole cover .2 sets
Tire	12R22.5 12pcs
Discharge valve	4''disc valve
Dischage pipe	4''seamless steel tube
Kingpin	2'' bolt-in king pin
Bottom valve	One piece
Compartment	Three
Braking system	RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
Painting	Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint
Accessories	One standard tool box.fire extinguisher 2 pcs
Main beams	Opting for high tensile steel Q345B welded by automatic submerged-arc processes
Remark	Wax spray
Delivery time	15 workdays after confirming order and receiving your deposit
Delivery way	Transfer to Tianjin/Shanghai/Qingdao Port, and carry by ro-ro ship, the freight cost depends on the volume
