Характеристики

Products Description

This series is full inverter designed for fast heating/cooling for above ground pool 25m3,which greatly saves energy and enables you to enjoy swimming without waiting for long time.

Features:

1.INVERTER Version (Two-side Discharge)
2.Heating and Cooling
3.COP as High as 9.6
4.Mini Size & Portable
5.Frosted Silver Sheet Metal Casing & Anti-corrosion
6.R32 Gas Environmentally-friendly & Energy-saving
7.Simple Control Panel
8.APP Control with WIFI Function Standard
9.Silent Operation
10.Quick Installation, Plug & Play
11.Intelligent Defrosting
12.Min Working Temperature -5℃
13.Max Output Water Temperature 45℃
14.Patent Design

Our Advantages

PATENT DESIGN

Patented unigue design: Square structure design with arc style corner.
The air inlet and outlet are symmetrically design.

SUPER SILENT

Thanks to the patented silent design, it makes a quieter swimming environment and a friendly neighborhood for you. The sound level is only 45dB.

SIMPLE INSTALLATION & OPERATION

Easy plug & play and press & heat controller bring more comfortable and convenient experience to end user.

INTELLIGENT DEFROSTING

Equipped with four-way valve,the unit can automatically defrost efficiently and quickly when ambient temperature is low,perfectly adapting to the needs of different temperature and areas. This also ensures the wide application range from 5 to 43℃.

Product Paramenters

F Series——Inverter Mini Pool Heat Pump
Model	PW08-CY-DCF	PW15-CY-DCF
Advised pool volume (m3)	10~20	15~25
Operating air temp. (℃)	-5~43℃
Performance Condition: Air 27°C, Water 26°C, Humidity 80%
Heating capacity (kW)	4.0~1.0	5.5~1.4
Heating capacity(Btu)	13600~3400	18700~4760
Consumed power (kW)	0.8~0.11	1.1~0.15
COP	5.0~9.5	5.0~9.6
Performance Condition: Air 15°C, Water 26°C, Humidity 70%
Heating capacity (kW)	2.5~0.65	3.7~0.8
Heating capacity(Btu)	8500~2210	12580~2720
Consumed power (kW)	0.6~0.1	0.9~0.13
COP	4.0~6.1	4.0~6.0

Performance Condition: Air 35℃,Water 28℃, Humidity 80%
Cooling capacity (kW)	2.0	3.3
Sound pressure at 1m dB(A)	46	48
Sound pressure at 10m dB(A)	30	32

Heat exchanger	Spiral titanium tube in PVC
Casing	Metal Casing
Power supply	220 ~240V/1Ph/50Hz~60Hz
Water connection (mm)	Φ32
Rated input current at air 15℃(A)	2.6~0.4	3.9~0.57
Water flow volume(m³/h)	1.5-2.0	2.0-2.5
Water pressure drop (max) kPa	2	4
Net weight/Gross weight(kg)	26/28	34/37
Net size(mm)	394444435	498499500
Package size(mm)(carton)	420510485	555576542
Package size(mm)(Polywood)	437510475	572576545
Loading QTY (20GP/40GP/40HQ)	208/416/520	144/288/288
Refrigerant consumption(g)	180	To be pending
Refrigerant	R32
Compressor type/QTY	Rotary type/1
Defrosting	By four-way valve
Throttle device	Electronic expansion valve
Operating water temp. (℃) heating	9 ~43
Operating water temp. (℃) cooling	9 ~35
