Высокое качество долгое время работы горизонтальный тестомеситель 10л
- Категория: Dough mixer >>>
- Поставщик: Henan,Kellen,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.78 $* | 0.34 $* |
| Aug-18-2025 | 0.94 $* | 0.51 $* |
| Jul-18-2025 | 0.28 $* | 0.59 $* |
| Jun-18-2025 | 0.87 $* | 0.95 $* |
| May-18-2025 | 0.96 $* | 0.32 $* |
| Apr-18-2025 | 0.64 $* | 0.0 $* |
| Mar-18-2025 | 0.27 $* | 0.58 $* |
| Feb-18-2025 | 0.38 $* | 0.37 $* |
| Jan-18-2025 | 0.39 $* | 0.93 $* |
Характеристики
Hot Sale Bakery Equipment Dough Mixer
Product Description
The machine is reasonable in design, convenient in operation, high in work efficiency and excellent in performance. The face bucket can be rotated freely at 90 degrees to facilitate the removal of the surface.The internal stainless steel is manufactured to meet the hygiene requirements.
Low efficiency?
Soul problems from entrepreneurial bosses?
With this kneading machine, say goodbye to your troubles!
Applications
Give me ten minutes and I'll give you a big dough
Imitate the various kneading methods of handwork, quickly produce the film and knead the dough evenly.
Dough mixer is the main equipment of pasta processing.
also suitable for business units, canteens, guest houses, large, medium and small restaurants, factories, schools, military units, etc. It is a good helper for your small business. It is an essential equipment for making staple bread, snacks, cakes, moon cakes, pastry, biscuits, etc.
TIPS
Working Principle
The machine is composed of mixing tank, stirring hook, transmission device, electrical box, base and other parts.The screw agitator is driven by the transmission device to rotate in the mixing tank, while the mixing tank is driven by the transmission device to rotate at a constant speed. The flour in the tank is continuously pushed, pulled, kneaded, pressed, fully stirred, and quickly mixed to make the dry flour obtain uniform hydration, expand the gluten, and become a dough with certain elasticity, flexibility and uniform flow.
Work Flow of Dough Mixer：
Stir: First pour the flour into the mixing barrel and add 50% water to stir. Stir for about 5 minutes and then make up. For example, when the dough turns with the auger, sprinkle some dry flour to remove.When the machine is working properly, auger steering should be in line with the arrow on the belt guard.
Surface taking: After the surface is well, disconnect the power supply, open the boot cover, pull out the bolt, turn the surface barrel to 90 degrees, insert the bolt to fix the surface barrel, and then take the surface taking.If the dough is too large, cut it into pieces with a knife.If the dough at the bottom of the barrel cannot be taken out, reverse the dough and remove it before taking the dough out.
Precautions for the Use of the Dough Mixer:
1. Add appropriate amount of lubricating oil to each oil hole or oil cup of the dough mixer and insist on 2-3 extra times per shift.
2. Turn on the power and check the direction of rotation. (The stirrer turns backward).
4. Re-check all the solid parts after 30 minutes of empty car operation before proceeding to work.
3. The operation should be stable and no abnormal noise.
5. All adopt gear reduction transmission structure, which has the advantages of simple structure, compactness, convenient operation, no complicated maintenance, and long service life.
6. The noodle hopper is made of stainless steel and special surface treatment. The professional noodle machine meets the sanitary standard. The installation and debugging of the noodle machine.
8. Check whether the fasteners are loose and whether the power cord switch is in good condition.
7. The four feet of the machine should be leveled, and the multi-function dough mixer should reduce vibration; connect the ground wire at the bottom of the frame (equal potential terminal) to prevent leakage of electricity.
9. Add proper amount of lubricating oil to the gear.As a large-scale food machine, the kneading machine will inevitably have some precautions during its use. As long as we can pay a little attention in the use process, we can achieve safe production and efficient production.
Manufacture Specification
Model | Power | Capacity | Flour Capacity | Dimension | Weight |
KLD-25 | 2.2KW,220V | 200KG/H | 25kg/batch | 1000*480*890mm | 200kg |
KLD-50 | 3.0KW/380V | 400KG/H | 50kg/batch | 1220*550*950mm | 400kg |
KLD-75 | 4.0KW/380V | 500KG/H | 75kg/batch | 1330*640*1030mm | 500kg |
KLD-100 | 4.0KW/380V | 600KG/H | 100kg/batch | 1530*620*1030mm | 600kg |
KLD-125 | 5.5KW/380V | 700KG/H | 125kg/batch | 1450*700*1150mm | 700kg |
KLD-150 | 5.5KW/380V | 800KG/H | 150kg/batch | 1550*700*1350mm | 800kg |
The machines are divided into different specifications, if you want higher efficiency, please choose the machine with higher output.
Detailed Images
Without reducer
Reducer is not required for 15kg/batch machine.
With reducer
Reducer is required for machines with power over 25kg/batch.
Because the machine itself can not speed, equipped with a reducer can make the machine run more smoothly.Extend the life of the generator.
Because the machine itself can not speed, equipped with a reducer can make the machine run more smoothly.Extend the life of the generator.
Thicken refined steel and flour drum
It's very smooth with the dough. Solid and durable without shaking.
Inverted switch
The precision-manufactured switch controls the direction of the mixing box, so that the mixing box can be rotated clockwise and counterclockwise to switch stirring.
Rotating screw
Assist the rod so that the flour is in full contact. The screw rotates evenly up to Assist the pole to make a good contact with flour.The screw rotates evenly to make the flour mix evenly and prevent the flour from splashing.
Products Pictures
Related Products
FAQ
Q1: what is MOQ?
A1: no matter which model 1set is our MOQ;
Q2: Where will the orders be shipped from?
A2: It will ship from the main ports China,Shanghai ,Qingdao,Tianjin.
Q3: what is payment Terms for making order?
A3: Our payment terms is T/T or use Alibaba Trade Assurance (50% deposit+50%balance)
Q4: Are you manufacturer?
A4. Yes,OEM,we are manufacturer with own workshop,welcome to visit our factory if u have time;
Q5: Can we make customized order?
A5: yes,we accept custom design;
Q6:Can you offer us the necessary paper to do the customs clearance?
A6:Yes, of course. We will send you the commercial invoice, sales contract, packing list, bill of lading(FOB or
CFR,CIFterms),insurance policy (if CIF terms), also CO if you need.
Q7: Can your meet our country's standards?
A7: we can do your order as your request to meet different standards
Q8: How about quality guarantee Terms?
A8: Quality guarantee term is for one year. Malfunctions which are caused by machine-self and quality will be responsible for ourmanufacturer.
