Wireless gamepad ps4 controller pcb board making and pcb assembly





Welcome To Moko


 1


Founded in the year 2006,located in Shenzhen, as a professional EMS/OEM Manufacturer, MOKO TECHNOLOGY LTD could provide one-stop pcb assembly service,we also could offer:





- Contract Manufacturing


- Engineering Services


- PCB Assembly


- Component Procurement & Material Management


- Product Design


- Fast Track Prototyping


- Cable and Wire Assemblies


- Plastics and Molds


- Function Testing Service





As the Professional PCB Assembly and PCB Manufacturer in China, we pride ourselves on our Excellent Customer Service and Reliability! MOKO Technology Ltd also offers Exclusive Services to Help Our Customers with their PCB Projects.





443322












Our Services









Our PCB Sevices:


1. PCB fabrication.


2. Turnkey PCBA: PCB+components+SMT and through-hole assembly+enclosure molding&housing.





Our Advantage:


1. Free programming and free functional test, free package.


2. High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% funtional test.


3. Professional service. ISO SMT and through hole assembly, over 10 years experience.


4. Certification for electronics: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001:2008, ISO14001


5. Warranty period for PCBA: 2 years.





PCBA PROCESSING CAPABILITY :















































































Turnkey PCBAPCB+components sourcing+assembly+package
Assembly detailsSMT and Thru-hole, ISO SMT and DIP lines
Lead TimePrototype: 15 work days. Mass order: 20~25 work days
Testing on productsFlying Probe Test, X-ray Inspection, AOI Test, Functional test
QuantityMin quantity: 1pcs. Prototype, small order, mass order, all OK
Files neededPCB: Gerber files(CAM, PCB, PCBDOC)
Components: Bill of Materials(BOM list)
Assembly: Pick-N-Place file
PCB Panel SizeMin size: 0.25*0.25 inches(6*6mm)
Max size: 20*20 inches(500*500mm)
PCB Solder TypeWater Soluble Solder Paste, RoHS lead free
Components detailsPassive Down to 0201 size
BGA and VFBGA
Leadless Chip Carriers/CSP
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
Component packageCut Tape,Tube,Reels,Loose Parts
PCB assembly
process
Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing







PCB PROCESSING CAPABILITY :
































































































































1LayersSingle Sided,2 to 18 Layer
 2Board material type

FR4,CEM-1,CEM-3,ceramic substrate board,


aluminum based board, high-Tg, Rogers and more


 3Compound material lamination4 to 6 layers
 4Maximum dimension610 x 1,100mm
 5Dimension tolerance±0.13mm
 6Board thickness coverage0.2 to 6.00mm
 7Board thickness tolerance±10%
 8DK thickness0.076 to 6.00mm
 9Minimum line width0.10mm
10Minimum line space0.10mm
11Outer layer copper thickness8.75 to 175µm
12Inner layer copper thickness17.5 to 175µm
13Drilling hole diameter (mechanical drill)0.25 to 6.00mm
14Finished hole diameter (mechanical drill)0.20 to 6.00mm
15Hole diameter tolerance (mechanical drill)0.05mm
16Hole position tolerance (mechanical drill)0.075mm
17Laser drill hole size0.10mm
18Board thickness and hole diameter ratio10:1
19Solder mask typeGreen, Yellow, Black, Purple, Blue, White and Red
20Minimum solder maskØ0.10mm
21Minimum size of solder mask separation ring0.05mm
22Solder mask oil plug hole diameter0.25 to 0.60mm
23Impedance control tolerance±10%
24Surface finishHot air level, ENIG, immersion silver, gold plating, immersion tin and gold finger







PCB LEAD TIME









































Layer Details


Sample(Normal)


Sample(Fast)


Mass Production


Single/Double


2-3days


24hours


5-7days


Four Layer


7-10days


3days


7-10days


Six-Eight Layer


7-10days


5days


13-15days


Over Eight Layer


15-20days


7days


15-20days










Our Clients Markets







clients market






Components Partners












WHY US







why moko






Exhibition







exhibition








team









Company Information







MOKO OFFICECompany3-1 (1).jpgfactoryCompany3-2 (1).jpg



FAQ







Q: What files do you use in PCBA fabrication?


A: Gerber or Eagle, BOM listing, PNP and Components Position





Q:Is it possible you could offer sample?


A: Yes, we can custom you sample to test before mass production





Q: When will I get the quotation after sent Gerber, BOM and test procedure?


A:  Within 6 hours for PCB quotation and around 24 hours for PCBA quotation.





Q: How can I know the process of my PCBA production?


A: 7-10 days for PCB production and components purchasing, and 10 days for PCB assembly and Testing





Q: How can I make sure the quality of my PCBAs?


A: We ensure that each piece of PCBA products work well before shipping. We'll test all of them according to your test procedure. Also if there are any defect items during the shipping, we also can be free to repair  for you.
