333 тип металлического сайдинга формовочная машина для стоячего шва прокатная мельница крыши 199 китайский продукт бесшовная сталь алюминиевый профиль
- Категория: Building Material Machinery >>>
- Поставщик: Tianjin,Yufada,Industry,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 10115.32 $* | 10621.4 $* |
| Aug-19-2025 | 10030.44 $* | 10532.51 $* |
| Jul-19-2025 | 8415.20 $* | 8836.71 $* |
| Jun-19-2025 | 9860.51 $* | 10353.79 $* |
| May-19-2025 | 8585.81 $* | 9014.19 $* |
| Apr-19-2025 | 9690.47 $* | 10175.48 $* |
| Mar-19-2025 | 9605.72 $* | 10085.36 $* |
| Feb-19-2025 | 9520.72 $* | 9996.32 $* |
| Jan-19-2025 | 9435.77 $* | 9907.48 $* |
Характеристики
YUFADA
Welcome to YUFADA,we are your manufacturer of Glazed Tile galvanized corrugated sheets maintain expert.
Home Products categories Company profile Contacts
Product Description
Work flow
Manual uncoiler-- roll forming machine-- PLC control box-- hydraulic system-pre cut-- output table
| Article No. | Item Name | Specification |
| 1 | Width of feeding material | As customer' drawing |
| 2 | Thickness of feeding material | 0.3-0.8 mm coil sheet |
| 3 | Roller station | 12 stations |
| 4 | Shaft Diameter | 60 mm |
| 5 | Productivity | 5-15 m/min |
| 6 | Rollers' material | 45# steel with 0.05mm chrome |
| 7 | Shaft material | 45# steel with 0.05mm chrome |
| 8 | Weight | 1.5 ton |
| 9 | length | 4.5 m |
| 10 | Voltage | 380V 50Hz 3phases |
| 11 | Control | PLC |
| 12 | Decoiler | 3 Tons |
| 13 | Motor | 5.5 kw |
| 14 | Driving way | Chain transmission |
| 15 | Chain size | 1.5 inch |
| 16 | Cutting system | Hydraulic cutter |
Working video
If u want to see the machine working video, please contact with Miaomiao with any way below.
Company Information
YuFaDa industrial CO.,Ltd is a professional manufacturer designing and producing roll forming machines established in June 1996. We have four factories working in Beijing, Tianjin and Hebei province. More than 400 workers provide service for u.
Products mainly include trapezoidal steel roof/wall panel machine, C&Z shape purline machine, high-way guardrail machine, sandwich panel production line, deck forming machine, C U L light keel machine, shutter slat door forming machine, cutting machine, downpipe machine, gutter machine, etc.
FAQ
1. Q: How to visit our company:
A: Fly to Beijing Airport: By fast train From Beijing South station to Cangzhou west station
(1hour), then we can pick up you to factory(40min).
Fly to Shanghai Airport: By fast train From Shanghai Hongqiao station to Cangzhou west
station(4.5 hours), then we can pick up you to factory(40min).
2. Q: What should I provide if I want to customized machine?
A: U need provide profile drawing, material, thickness, voltage and your special requirements.
3. Q: What is the Warranty?
A: Within 12 mounts, all technicals are ready to serve you at any time.
4. Q: What can you do if the machine broken?
A: Our machine's warranty period is 12 months, if the broken parts can't repair, we will send
new parts replace the broken parts free, but you need pay the express cost if after warranty period. we can negotiate to solve the problem, and we supply the technical support for whole life of equipment.
5. Q: If need technician to workshop to debug and teach, how to do?
A: We sent technician to your country to fix the machine. Buyer should bear cost including: visa, round trip ticket and suitable accommodation, also buyer should pay the salary 100 USD/day.
Our Services
1. Free technical support and free accessories supply.
2. Engineer available to service machinery overseas.
3. One year warranty is provided.
4. Long life technical guidance for free.
5. We always offer technical support, quick response, all your inquire will be replied in 24 hours.
