Вертикальная машина для расширения конденсаторных
- Категория: Tube End Forming Machines >>>
- Поставщик: Jingda,Machine,(ningbo),Co.,Ltd.,(jdm)
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.59 $* | 0.19 $* |
| Aug-20-2025 | 0.21 $* | 0.47 $* |
| Jul-20-2025 | 0.24 $* | 0.77 $* |
| Jun-20-2025 | 0.52 $* | 0.84 $* |
| May-20-2025 | 0.76 $* | 0.69 $* |
| Apr-20-2025 | 0.92 $* | 0.87 $* |
| Mar-20-2025 | 0.97 $* | 0.36 $* |
| Feb-20-2025 | 0.22 $* | 0.21 $* |
| Jan-20-2025 | 0.98 $* | 0.46 $* |
Характеристики
Recommend Products
Products Description
Product model | YZL2000 |
Product name | Hydraulic Drive CNC Control Vertical Expander Machine |
Color | International grey |
workpiece length | 200-2000mm |
workpiece diameter | Φ5-Φ12.7mm |
Tube expansion speed | Forward: 0-6.71m/min Return: 0-9.81m/min |
Maximum expansion force | 25T |
Rated working pressure of hydraulic system | ≤7MPa |
Maximum working pressure of hydraulic system | 15Mpa |
Total Power | 15KW |
Air pressure | 0.6-0.8MPa |
Power supply | AC380V/50Hz |
Cooling system | Water cooling or Air cooling |
The JDM vertical expander is a professional HVAC equipment dedicated to expand heat exchanger coils reliably with little damage.The high productivity enables the machine to complete expanding, flaring and edge folding in a short cycle time. The high precision ensures that tubes are expanded uniformly and fins remain undamaged.
1. Full functionality – Integrated flaring and expansion
2. High Automation – Front and back plates auto storage, auto-rod pattern, supportive base auto adjusting
3. High accuracy and reliability – Servo controlled screw rod driven
4. Operator safety and ergonomics – Servo driven front plate flipping, equipped with safety guard
5. Customized options available
2. High Automation – Front and back plates auto storage, auto-rod pattern, supportive base auto adjusting
3. High accuracy and reliability – Servo controlled screw rod driven
4. Operator safety and ergonomics – Servo driven front plate flipping, equipped with safety guard
5. Customized options available
1. Hydraulic/servo motor drive
2. Coil load & eject system (Manual door/Turnover door/rotary table)
3. Auto-rod Pattern
4. Non-shrink configuration
5. Stepped coil applicable
2. Coil load & eject system (Manual door/Turnover door/rotary table)
3. Auto-rod Pattern
4. Non-shrink configuration
5. Stepped coil applicable
The JDM vertical expander is a professional HVAC equipment dedicated to expand heat exchanger coils reliably with little damage. The high productivity enables the machine to complete expanding, flaring and edge folding in a short cycle time. The high precision ensures that tubes are expanded uniformly and fins remain undamaged.
Company Profile
Established in 1990, JDM Jingda Machine (Ningbo) Co., Ltd. (hereafter referred to as JDM), a listed company (stock code 603088), is the largest supplier of equipment and machines to the HVACR industry and metal forming industry. The net capital of JDM has reached 500 million RMB. JDM owns 140,000m2 of workshops and labs.
Housing such manufacturing capability and dedicated team, JDM aim to provide our customers excellent press machines and heat exchanger equipments in manufacturing and automotive industry.
JDM is proud to be partner with Mahle Behr,Denso, Valeo, ,Calsonic, Visteon, Gree, Midea, Haier, Daikin, Carrier, Fujitsu, Hitachi and so on.
Our continuous strive for perfection is visible in our ISO 9001 rated facilities, heavy invest in machinery and personnel. We understand that an enthusiastic and dedicated team is the key to success. That iswhy JDM raised a strong R&D team with 100+ engineers and is recognized as the National Key High-Tech Enterprise.
Housing such manufacturing capability and dedicated team, JDM aim to provide our customers excellent press machines and heat exchanger equipments in manufacturing and automotive industry.
JDM is proud to be partner with Mahle Behr,Denso, Valeo, ,Calsonic, Visteon, Gree, Midea, Haier, Daikin, Carrier, Fujitsu, Hitachi and so on.
Our continuous strive for perfection is visible in our ISO 9001 rated facilities, heavy invest in machinery and personnel. We understand that an enthusiastic and dedicated team is the key to success. That iswhy JDM raised a strong R&D team with 100+ engineers and is recognized as the National Key High-Tech Enterprise.
Certifications
Customer Photos
Delivery
FAQ
1. Where can you ship your machines?
Anywhere globally. We have customers and service team worldwide.
Anywhere globally. We have customers and service team worldwide.
2. What is the general lead time?
Standard configuration machines take around 45 to 90 days to deliver. The lead time depends on the size, complexity and destination standards.
Standard configuration machines take around 45 to 90 days to deliver. The lead time depends on the size, complexity and destination standards.
3. What is the standard of your machine?
JDM provides CE standard products with CE marks. If required, we can make UL standard products as well.
4. How do I know you make good quality machines?
We have dedicated engineering team, quality team, precise machine tools and ISO9000 Quality system in the company. We provide WEBEX online inspection and onsite checking for customer to inspect the manufacturing.
5. What payment and delivery terms do you accept?
JDM accepts L/C, T/T, Western Union and Cash Payment. We accept EXW, FOB, CFI and other shipping terms.
