Product Description
What Is Bag Filter Housing?
Bag filter housing is an ideal housing for most demanding applications, easy filter bag change-outs, excellent sealing performance. Top inlet filter housing has a top inlet and bottom outlet, through which the fluid to be filtered flows from top to bottom during the filtration.When the head cover is closed, it directly compresses the sealing ring of the
filter bag, ensuring the better sealing performance and easier operation.
Features
> It reduces product loss and make the filter bag change-outs easier.
> It ensures that there is nearly no side leakage during the filtration.
> It ensures that the flow path is smooth with minimum resistance and there is no blind angle.
filter bag, ensuring the better sealing performance and easier operation.
Features
> It reduces product loss and make the filter bag change-outs easier.
> It ensures that there is nearly no side leakage during the filtration.
> It ensures that the flow path is smooth with minimum resistance and there is no blind angle.
Technical Parameters
Product Code | No. of Bags | Bag Size | Material | Inlet&Outlet | Max. Flow Rate (M3) | Max.Pressure (Bar) |
STPL-0101 | 1 | 01 | SS304 SS316 | DIN/ANSI BSP/NPT | 20 | 10 |
STPL-0102 | 1 | 02 | SS304 SS316 | DIN/ANSI BSP/NPT | 40 | 10 |
SSPL-0101 | 1 | 01 | SS304 SS316 | DIN/ANSI BSP/NPT | 20 | 10 |
SSPL-0102 | 1 | 02 | SS304 SS316 | DIN/ANSI BSP/NPT | 40 | 10 |
SSPL-0103 | 1 | 03 | SS304 SS316 | DIN/ANSI BSP/NPT | 6 | 6 |
SSPL-0104 | 1 | 04 | SS304 SS316 | DIN/ANSI BSP/NPT | 12 | 8 |
Details Images
Top Inlet
Fluid enters from the top, thereby minimizing turbulence and improving the filtration efficiency and service life of the filter bag.
Flange Connection
Flange connection with a wider range of applications, more flexible and convenient operation, and better sealing performance.
Adjustable Mounting Legs
Adjustable mounting legs make the installation simpler and easier
Parts&Accessories
Housing Size | Bag Material | Micron Rating | Ring Type | Bag Size | Construction |
#1 | PP PE | 1-200 | PP Plastic Collar PE Plastic Collar High Temp.Plastic Collar | #1 | Welded Sewn |
#2 | PP PE | 1-200 | PP Plastic Collar PE Plastic Collar High Temp.Plastic Collar | #2 | Welded Sewn |
#3 | PP PE | 1-200 | PP Plastic Collar PE Plastic Collar High Temp.Plastic Collar | #3 | Welded Sewn |
#4 | PP PE | 1-200 | PP Plastic Collar PE Plastic Collar High Temp.Plastic Collar | #4 | Welded Sewn |
Product Application
Bag filter housing can be widely used in various industries and fields, it can be widely used in various industries and fields.
Food and Beverage
Water
Beer
Paints
Automotive
Chemical Industry
Pharmaceuticals
Petrochemicals
Waste Water Treatment
Cetifications
Packing & Delivery
Authoritative Inspection
We provide free authoritative inspection for each container, double guarantee the interests of customers.
Make you buy more assured and safer!
Make you buy more assured and safer!
We are concerned about your consideration on the most favorable packing and the shipping way.
For this purpose, we provide two ways of packing and shipment.
Packing | ||||||||
Product Code | Order QTY | Recommended Packing | Order QTY | Recommended Packing | ||||
STPL-0101 | 1 | Pearl Cotton+Carton+Wrap Film | >1 | Pearl Cotton+Wooden Case | ||||
STPL-0102 | 1 | Pearl Cotton+Carton+Wrap Film | >1 | Pearl Cotton+Wooden Case | ||||
SSPL-0101 | 1 | Pearl Cotton+Carton+Wrap Film | >1 | Pearl Cotton+Wooden Case | ||||
SSPL-0102 | 1 | Pearl Cotton+Carton+Wrap Film | >1 | Pearl Cotton+Wooden Case | ||||
SSPL-0103 | 1 | Pearl Cotton+Carton+Wrap Film | >1 | Pearl Cotton+Wooden Case | ||||
SSPL-0104 | 1 | Pearl Cotton+Carton+Wrap Film | >1 | Pearl Cotton+Wooden Case | ||||
EMBF | >=1 | Pearl Cotton+Wood | ||||||
Please Contact Us To Calculate Shipping Costs | ||||||
CBM of Goods | Shipping Service | Our Partner | Other Options | |||
<1 cbm | Express Service | > DHL > UPS > Fedex | Customer's partners | |||
>1 cbm | Ocean Shipping | > Listed shipping company | Customer's partners | |||
FAQ
Question 1: Are you manufacturer? | ||||||||
Yes, we are manufacturer with 5 production lines, R&D and oversea market department. | ||||||||
Question 2: Can you provide OEM service? | ||||||||
Yes, we have more than 10 years of OEM experience and provide this service. | ||||||||
Question 3: Can you provide sample? Free or chargeable? | ||||||||
Yes, we can provide free sample for filter elements, all filter housings are chargeable. | ||||||||
Question 4: Does the product support customization？ | ||||||||
Products can be customized base on our current mould. | ||||||||
Question 5: What is the payment terms? | ||||||||
TT/LC, Via Alibaba, you can pay by credit card. | ||||||||
Question 6: How to choose the shipping way? | ||||||||
It depends on the order QTY, detailed information, please refer to our [packing&shipping]. | ||||||||
