Станок для лазерной маркировки с
- Категория: Аппарат для лазерной гравировки >>>
- Поставщик: Liaocheng,Dongchangfu,Ketai,Laser,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.81 $* | 0.45 $* |
| Aug-16-2025 | 0.91 $* | 0.82 $* |
| Jul-16-2025 | 0.42 $* | 0.64 $* |
| Jun-16-2025 | 0.66 $* | 0.61 $* |
| May-16-2025 | 0.32 $* | 0.15 $* |
| Apr-16-2025 | 0.72 $* | 0.3 $* |
| Mar-16-2025 | 0.30 $* | 0.52 $* |
| Feb-16-2025 | 0.13 $* | 0.84 $* |
| Jan-16-2025 | 0.43 $* | 0.88 $* |
Характеристики
CNC fiber bird ring laser marking machine
Detailed Images
Laser source
Product Parameters
| Model: | FM | ||
| Laser type: | JPT / MAX / Raycus | ||
| Laser power: | 20W | ||
| Software | Ezcad | ||
| Supports graphical format: | PLT, BMP, JPG, PNG, TIP, PCX, TGA, ICO, DXF ect.Files which Coreldraw AutoCAD and Photoshop can identify | ||
| Beam quality: | <1.8 | ||
| Power stability: | (8h) <± 1% rms | ||
| Pulse repetition frequency: | 20-100KHz | ||
| Power consumed: | <800W | ||
| Minimum line width: | 50μm | ||
| Minimum character: | 1*1mm | ||
| Working speed: | 7000mm/s | ||
| Laser Wavelength: | 1064nm | ||
| Engraving depth: | ≤2mm | ||
| Galvanometer Size: | 160mm*160mm(110*110,200*200mm/300*300mm(optional) | ||
| Min line width | 0.01mm | ||
| Repetitive precision | ±0.001mm | ||
| Cooling way: | Air cooling | ||
| Operating voltage: | 110/220V ± 10% /50/60HZ | ||
| Ambient operating temperature: | 15 ° C - 35 ° C | ||
| Gross Weight: | 100KG | ||
| Dimensions: | 116*90*80cm | ||
| Packing: | International plywood packing | ||
| Warranty | 3 years. | ||
Sample Photos
Videos on Youku
https://i.youku.com/i/UNjEzNDgyMjQ0/videos?spm=a2hzp.8244740.0.0
Packing
Wrapping film + Plywood case with pallet
