Автоматическая высокоточная рулонная бумага 4 цвета флексографская печатная машина pp Нетканая пластиковая для принтера
- Категория: Flexographic Printers >>>
- Поставщик: Ruian,Xuanhai,Machine,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.83 $* | 0.69 $* |
| Aug-18-2025 | 0.10 $* | 0.6 $* |
| Jul-18-2025 | 0.2 $* | 0.58 $* |
| Jun-18-2025 | 0.48 $* | 0.82 $* |
| May-18-2025 | 0.61 $* | 0.84 $* |
| Apr-18-2025 | 0.51 $* | 0.79 $* |
| Mar-18-2025 | 0.65 $* | 0.50 $* |
| Feb-18-2025 | 0.59 $* | 0.95 $* |
| Jan-18-2025 | 0.33 $* | 0.5 $* |
Характеристики
Product Description
Usage:
this machine can print non woven fabric for face mask,shoe cover,doctor cap ect.
1. Low speed and full load startup; stable running by tension control when increasing and
decreasing speed, noise is decreased
2. High dots presentation rate under high speed; clear and vivid stratification of screen printing;
strong stereo effect and accurate registering
3. Aluminum roller adopts the Japan semi-sealing small bearing; flinty oxidation, static and
dynamic balancing treatments are conducted; low resistance and small flop.
4. The special made modulus angular gears adopted printing size and full printing specifications
(5mm is spec)
5. With the air exhaust, blowing and heating settings; the heating system adopts the central
thermostatic control system and group management, also with the cold air forming devices
6. Printing rolls should keep moving while machine halted
7. Material holder use air shaft
8. Auto tension control
9. Unwind with auto deviation correction system (EPC)
10. EDGE position control
11. Reversible printing 4 color press for 4+0,1+3,2+2,
12.1 set of printing cylinder, size 15 inches
* The outline is made of cast iron which thickness is 75mm
Model No. | GYT-4600 | GYT-4800 | GYT-41000 |
Max.Web Width | 600mm | 800mm | 1000m |
Max.Effective Printing Width | 560mm | 760mm | 960mm |
Range of Repeat Printing Length | 191~914mm | 191~914mm | 191~914mm |
Max.Diameter of Material Roll | 450mm | 450mm | 450mm |
Printing Speed | 5-80m/min | 5-80m/min | 5-80m/min |
Plate Thickness(Both side adhesive tape included) | 2.38mm | 2.38mm | 2.38mm |
Total Power | 11.5Kw | 15Kw | 18.5Kw |
Weight of Machine | 3000kg | 3500kg | 4000kg |
Machine Dimension(mm) | 4300×1600×2500 | 4300×1800×2500 | 4300×2000×2500 |
product details
More Products
Company Profile
Our Team
Packing & Delivery
FAQ
Q1:Where is your factory located? How can I visit there?
A1: Our factory is established from 1988,located in Rui an,Wenzhou City, Zhejiang Province, China, about 1 hour by air and 3-4 hours by train from Shanghai.
Q2: How does your factory do regarding quality control?
A2: All machines are doing 24 hours running test to ensure quality.
Q3: How about the payment term?
A3: 30% downpayment and pay the balance before shipment after testing the machine in our factory.
Q4:What about warranty and do the engineers available to overseas?
A4: one year for mechnical parts,half year for electrical parts. if you need our enginner to go to your factory,you need to bear his all costs. such as visa,hotels,eating and lodging at your side. salary USD100/day.
Q5:What about the service after sale?
A5: we can provide video online service or send enginner to go to your factory to do the trainning if you need.and we have english,spanish speaker.
Q6: Do you need agent for overseas?
A6: yes,we need you to be our agent. welcome to contact us.
A1: Our factory is established from 1988,located in Rui an,Wenzhou City, Zhejiang Province, China, about 1 hour by air and 3-4 hours by train from Shanghai.
Q2: How does your factory do regarding quality control?
A2: All machines are doing 24 hours running test to ensure quality.
Q3: How about the payment term?
A3: 30% downpayment and pay the balance before shipment after testing the machine in our factory.
Q4:What about warranty and do the engineers available to overseas?
A4: one year for mechnical parts,half year for electrical parts. if you need our enginner to go to your factory,you need to bear his all costs. such as visa,hotels,eating and lodging at your side. salary USD100/day.
Q5:What about the service after sale?
A5: we can provide video online service or send enginner to go to your factory to do the trainning if you need.and we have english,spanish speaker.
Q6: Do you need agent for overseas?
A6: yes,we need you to be our agent. welcome to contact us.
