Скоростная горизонтальная машина для упаковки тортов и
- Категория: Упаковочная линия >>>
- Поставщик: Foshan,Chuanglibao,Packing,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 19516.2 $* | 20492.75 $* |
| Aug-20-2025 | 19352.6 $* | 20320.79 $* |
| Jul-20-2025 | 16236.52 $* | 17048.47 $* |
| Jun-20-2025 | 19024.12 $* | 19975.97 $* |
| May-20-2025 | 16564.34 $* | 17392.68 $* |
| Apr-20-2025 | 18696.76 $* | 19631.20 $* |
| Mar-20-2025 | 18532.73 $* | 19459.90 $* |
| Feb-20-2025 | 18368.9 $* | 19286.93 $* |
| Jan-20-2025 | 18204.73 $* | 19114.54 $* |
Характеристики
| Horizontal Packing Machines Parameters | ||||||
| Model | CB-300XS | CB-350XS | CB-450XS | CB-450WXS | CB-500XS | CB-680XWS |
| Width of film | ≤300mm | ≤300mm | ≤450mm | ≤450mm | ≤500mm | ≤680mm |
| Thickness of film bobbin | 30-75um | 30-75um | 30-75um | 30-75um | 30-75um | 30-75um |
| Dimension of film roll | outer diameter≤300mm, inner diameter≤75mm | outer diameter≤300mm, inner diameter≤75mm | outer diameter≤300mm, inner diameter≤75mm | outer diameter≤300mm, inner diameter≤75mm | outer diameter≤300mm, inner diameter≤75mm | outer diameter≤300mm, inner diameter≤75mm |
| Single blade bag size | (70-6000)* (50-140)* (3-60)mm(L*W*H) | (70-6000)* (50-140)* (3-60)mm(L*W*H) | (100-6000)* (80-215)* (10-65)mm(L*W*H) | (100-6000)* (80-215)* (10-90)mm(L*W*H) | (100-6000)*(80-240)*(10-80)mm(L*W*H) | (80-6000)*(50-320)*(3-140)mm(L*W*H) |
| Single blade packing speed | 10-100bags/min | 10-100bags/min | 10-80bags/min | 10-80bags/min | 10-100bags/min | 10-40bags/min |
| Double blade bag size | (60-6000)*(50-140)*(3-55)mm(L*W*H) | (60-6000)*(50-140)*(3-60)mm(L*W*H) | NA | NA | NA | NA |
| Double blade packing speed | 20-200bags/min | 20-200bags/min | 20-200bags/min | NA | NA | NA |
| Power requirement | 220V,50HZ,3.8KW | 220V,50HZ,3.8KW | 220V,50HZ,4.6KW | 220V,50HZ,5.5KW | 220V,50HZ,4.6KW | 220V,50HZ,5.7KW |
| Machine size | 3900*850 *1500mm | 3900*850 *1500mm | 4100*1050 *1580mm | 4100*1050 *1580mm | 4100*1050 *1600mm | 5000*1200 *1650mm |
| Machine Weight | 600kg | 600kg | 900kg | 960kg | 810kg | 920kg |
| Motor configuration | servo | servo | servo | servo | servo | servo |
| Film running way | from top | from top | from top | from top | from top | from top |
| Cuting ways | rotary cut | rotary cut | rotary cut | rotary/reciprocation | rotary | rotary/reciprocation |
| Sealing | back seal | back seal | back seal | back seal | back seal | back seal |
More details on the machine
