Product Description
ICAO LED Obstruction Lighting Day/Night Marking White Flashing L-865 Aviation Obstruction Light
CM-15 is a white LED medium intensity obstruction light, generally used on unpainted tall structures more than 45 meters.
CM-15 flashes at 20,000cd at daytime and twilight and will automatically reduce intensity to 2,000cd at nighttime.
CM-15 white medium intensity LED obstruction light can either work with power converter box and controller for monitoring and functions as a system, or CM-15 self-controlled configuration can work independently as an economical solution.
Item Name | ICAO LED Obstruction Lighting |
Model | CM-15 |
Operating Voltage | AC90-260V |
Power consumption | ≤30W |
Flashing frequency | 20-60 times/min |
Light intensity | 2.000 cd night-mode |
20.000 cd day-mode | |
Life span | ＞100,000 hours |
Emitting color | White |
Beam angle | 360° horizontal,more than 3° vertical beam spread |
Overall size | ∅268mm×206mm |
Installation size | Φ166-4*M10 |
Ingress protection | IP65 |
Operating temperature | -40℃～55℃ |
Net weight | 7KG |
Wind load | 80m/sec. |
Specification
1. Cover of the light adopts PC with anti-UV which is high efficiency light transmission up to 90%, quite
high impact resistance and fits the bad environment very well.
2. House of the light is made of aluminum alloy and painted by spraying plastics, the structure is high
strength, resistance to corrosion.
3. Use the special optical reflector design, the visual range further, angle more accurate, no light
pollution.
4. Light source adopts import high quality LED, lifespan up to 100,000 hours, low power consumption,
energy efficiency and environmental protection.
5. Based on the single chip computer control, automatic identification sync signal, do not distinguish
the main light and auxiliary light, and also could be controlled by the controller.
6. Same power supply voltage with synchronous signal, integrate in power supply cable, eliminate the
damage by error installation caused.
7. Used the photosensitive probe fit for the natural light spectrum curve, automatic control light
intensity level.
8. The circuit of the light has surge protection, so that the light is suitable for a harsh environment.
9. Integral structure, protection level of Ip65.
10. GPS synchronizing function is available.
