Taili 220v 380v 0.2kw ~ 550kw AC инвертор

Application: is widely used for speed regulation and  to drive 3phase electric motor of conveyor machine,printing machine,package machine,transmission machine,food machine,tea machine, cementing machine,fan,water pump,CNC lathe, engraving machine and others

1)US Series AC frequency Inverter

Low price, Small size, Easy installation, Simple Parameter, Easy debug,

Customized for 220v 3phase electric motor below 0.75kw,

The panel button will lock automatically after 5 minutes to prevent misoperation,Forced air cooling

Adopt new generation IPM intelligent module,perfect protection function

The panel carry speed regulating potentiometer, can also have outside speed regulating potentiometer wiring.

Has the function of electronic thermal relay, to replace other motor protection devices

Built-in multi-stage control, the frequency can be set freely

Use "shift" key, can view the working parameters in real time

Input frequency:50Hz,60Hz optional

Output frequency:0~99Hz

Input voltage:1phase 200v~240v AC

Output voltage:3phase 0~240v AC

Power available:0.4kw,0.75kw

2)UH Series AC frequency Inverter

Adopt ARM dual chip control system,anti-interference ability is strong

Support rail type installation

Excellent performance in fast start and fast stop

The input signal is isolated by optocoupler, safe and reliable.

Adopt new generation IPM intelligent module,perfect protection function

Motor overload value can be set arbitrarily according to motor power

Built-in multi-stage control, the frequency can be set freely

Can realize three wire control mode

Power on terminals protection function, to prevent misoperation.

Input frequency:50Hz,60Hz optional

Output frequency:0~600Hz

Input voltage:1phase 200v~240v AC

Output voltage:3phase 0~240v AC

Power available:0.75kw,1.5kw

3)M Series AC Frequency Inverter

Economic type inverter

Adopt DSP control system,high efficiency V/F control mode

Separate IGBT single tube design,easy to maintain

Input frequency width 47Hz~63Hz

High performance V/F control mode, low frequency high torque

Built-in modbus communication function

Built-in brake unit,save money

Built-in PID mode,realize constant pressure water supply sleep shutdown

Multiple frequency band setting, freely combination

Input frequency:50Hz,60Hz optional (allowable 47Hz~63Hz)

Output frequency:0~400Hz

Input voltage:1phase 200v~240v AC

Output voltage:3phase 0~240v AC

Power available:0.2kw,0.4kw,0.75kw,1.5kw,2.2kw

Input voltage:3phase 350v~420v AC

Output voltage:3phase 0~420v AC

Power available:0.75kw,1.5kw,2.2kw

4)G Series AC Frequency Inverter

General use type inverter

Using 32-bit ARM chip,quickly and accurately respond to dynamic signals

Has three kinds V/F control mode, intelligent carrier control,multiple input and output modes

Fast start and stop,diversified control, all-round protection for motor

Adopt IGBT module design,high stability and good consistency

Adopt high protection IP52 fan

Multiple V/F control modes, can realize low frequency high torque

0.75kw~18.5kw built-in brake unit, reduce external cost

Built-in PLC simple control logic,operation time set freely

Built-in PID mode, two sleep shutdown wake-up modes

Multiple frequency band setting, freely combination

DC bus operates at low voltage, transient fluctuation of power grid without shutdown

Input frequency:50Hz,60Hz optional

Output frequency:0~400Hz

Input voltage:1phase 200v~240v AC

Output voltage:3phase 0~380v AC

Power available:0.75kw~18.5kw

Input voltage:3phase 350v~420v AC

Output voltage:3phase 0~420v AC

Power available:0.75kw~400kw

5)S18 Series High Performance Vector Inverter

Adopt 32-bt DSP control system,through the decoupling control of motor flux current and torque current,realize the fast response and precise control of motor,high speed control precision,fast torque response,low frequency high torque

Adopt IGBT module design,high stability and good consistency

Three kinds speed control:V/F control,without PG open loop vector control SVC, with PG close loop vector control FVC

Open loop vector at low speed 0.5Hz can reach torque 150%

With PG Close loop speed control precision can reach  +/- 0.1,supply 1:1000 speed control range

Speed tracking restart function, to realize no impact on the motor and smooth tracking start.

Rich expansion card options:485 communication card,IO expansion card,PG card and etc.

Rich fieldbus support:Modbus,CANopen , two kinds of bus

16 segment speed,simple PLC,PID control and swing frequency control

The panel adopts encoder for speed regulation,precision speed regulation,Support differential encoder,open collector encoder,rotary encoder ,UVW encoder

Input frequency:50Hz,60Hz optional

Output frequency: vector control 0~320Hz, v/f control 0~3200Hz

Input voltage:1phase 200v~240v AC

Output voltage:3phase 0~380v AC

Power available:0.75kw~18.5kw

Input voltage:3phase 200~240v AC

Output voltage:3phase 0~240v AC

Power available:0.75kw~75kw

Input voltage:3phase 320v~490v AC

Output voltage:3phase 0~490v AC

Power available:0.75kw~400kw

6)S20 Series Vector Inverter

Small size, easy installation,can realize open loop vector control and V/F control

Adopt 32-bit DSP control system,realize open loop vector control, support rail type installation

Separate IGBT single tube design,easy to maintain

Speed control type: V/F control, open loop vector control

Open loop vector at low speed 0.5Hz can reach torque 150%

Speed tracking restart function, to realize no impact on the motor and smooth tracking start.

16 segment speed,simple PLC,PID control and swing frequency control

Built-in modbus communication function

Input frequency:50Hz,60Hz optional

Output frequency:0~320Hz

Input voltage:1phase 200v~240v AC

Output voltage:3phase 0~240v AC

Power available:0.4kw~5.5kw

Input voltage:3phase 380v AC

Output voltage:3phase 0~380v AC

Power available:0.75kw~11kw

7)S30 Series Vector Inverter, support single digital tube display,dual digital tube display and LCD display

Totally new design conception, vector control and V/F control freely switch, support LCD Chinese display

The panel is removable

Adopt the 4th generation IGBT module, less motor noise

Speed control type: V/F control, open loop vector control

Open loop vector at low speed 0.5Hz can reach torque 150%

16 segment speed,simple PLC,PID control and swing frequency control

Built-in modbus communication function

Unique algorithm,fast start and stop

Input frequency:50Hz,60Hz optional

Output frequency: low frequency mode 0~300Hz,high frequency mode:0~3000Hz

Input voltage:1phase 200v~240v AC

Output voltage:3phase 0~240v AC

Power available:0.75kw,1.5kw,2.2kw

Input voltage:3phase 380v AC

Output voltage:3phase 0~380v AC

Power available:0.75kw~22kw

Welcome to contact and consult me, it is my greatest honor to serve you.
