4 кВт 5 6 8 9 инвертор для солнечной системы трехфазный 380
- Категория: Солнечные инверторы >>>
- Поставщик: Jiangsu,Solarman,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 702.91 $* | 716.44 $* |
| Jul-17-2025 | 570.36 $* | 581.36 $* |
| Jun-17-2025 | 691.90 $* | 705.94 $* |
| May-17-2025 | 686.55 $* | 700.85 $* |
| Apr-17-2025 | 547.39 $* | 558.0 $* |
| Mar-17-2025 | 675.51 $* | 689.21 $* |
| Feb-17-2025 | 669.23 $* | 682.3 $* |
| Jan-17-2025 | 664.8 $* | 677.17 $* |
Характеристики
Product Description
Datasheet
Datasheet | ||||||||
Model Name | MOD 3000TL3-X | MOD 4000TL3-X | MOD 5000TL3-X | MOD 6000TL3-X | ||||
Input AC | ||||||||
Recommended max. PV power | 4.5KW | 6kW | 7.5kW | 9kW | ||||
Max. input voltage | 1100V | |||||||
Rated voltage | 580V | |||||||
Start-up voltage | 200V | |||||||
MPPT voltage range | 140V-1000V | |||||||
Max. input current | 13A | 37.5A/37.5A/37.5A | 50A/37.5A/37.5A | 50A/50A/50A | ||||
Max. short circuit current | 16A | 44A | 55A | 55A | ||||
MPPT number/Max. input strings number | 2 | 3/3/3 | 4/3/3 | 4/4/4 | ||||
Output AC | ||||||||
Rated output power | 30kW | 40kW | 50kW | 60kW | ||||
Max. apparent output power | 3.3kVA | 4.4kVA | 5.5kVA | 6.6kVA | ||||
Max. output power | 3.3kW | 4.4kW | 5.5kW | 6.6kW | ||||
Rated grid voltage | 230V/400V (340-440V) | |||||||
Rated grid frequency | 50/60Hz | |||||||
Max. output current | 5.0A | 6.7A | 8.3A | 10.0A | ||||
Power Factor | 0.8leading 0.8lagging | |||||||
THDi | <3% | |||||||
Efficiency | ||||||||
Max. efficiency | 98.7% | |||||||
EU efficiency | 98.5% | |||||||
Protection | ||||||||
DC reverse-polarity protection | Yes | |||||||
Short circuit protection | Yes | |||||||
Output over current protection | Yes | |||||||
Surge protection | Yes | |||||||
Grid monitoring | Yes | |||||||
Anti-islanding protection | Yes | |||||||
Temperature protection | Yes | |||||||
Integrated AFCI (DC arc-fault circuit protection) | Yes | |||||||
Integrated DC switch | Optional | |||||||
General Data | ||||||||
Dimensions (W*H*D) | 680/508/281mm | |||||||
Weight | 13.5kg | |||||||
Topology | Transformerless | |||||||
Self consumption | <1W (night) | |||||||
Operating ambient temperature range | -25 ~ +60°C | |||||||
Relative humidity | 0-100% | |||||||
Ingress protection | IP65 | |||||||
Cooling concept | Natural convection | |||||||
Max. operation altitude | 4000m | |||||||
Safety/EMC standard | IEC 62109-1/-2, IEC 62116, EN 61000-6-1/-2/-3/-4 | |||||||
Features | ||||||||
DC connection | H4/MC4(Optional) | |||||||
AC connection | Cable gland+OT terminal | |||||||
Display | OLED+LED/WIFI+APP | |||||||
Company Profile
Growatt was founded in 2010 and is a worldwide leader of smart energy solutions.
Growatt is the No.1 residential solar inverter supplier and is also one of the top 3 PV inverter suppliers for distributed
generation solar energy since 2018 and ranks among global top 10 PV inverter suppliers. The World's Manufacturer provides of residential, commercial and utility photovoltaic inverters, energy storage, microgrid systems and smart energy management solutions.
generation solar energy since 2018 and ranks among global top 10 PV inverter suppliers. The World's Manufacturer provides of residential, commercial and utility photovoltaic inverters, energy storage, microgrid systems and smart energy management solutions.
Construction case
Product packaging
Introduction to authorized Company
JIANGSU SOLARMAN TECHNOLOGY CO., LTD.
SOLAMAN is dedicated to the production of efficient solar modules, providing solar panels and systems to partners worldwide. With perfect quality control system, cost-effective products and all-round considerate service, Solarman has won the trust and support of global customers.
Exhibition
Certificate
PACKAGING LOGISTICS
FAQ
1. Who are we?
We are a professional manufacturer on Solar Panel with many years experience. Our factory and business office located in Wuxi City, Jiangsu Province.
2. What can we provide?
We can provide solar panel,solar inverter,solar energy system.
3. Why choose us?
A.Higher power generation
B.Competitive price
C.High quality standard
D.Customized service
4. What services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,FAS,CIP,FCA,DDP,DDU；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash.
We are a professional manufacturer on Solar Panel with many years experience. Our factory and business office located in Wuxi City, Jiangsu Province.
2. What can we provide?
We can provide solar panel,solar inverter,solar energy system.
3. Why choose us?
A.Higher power generation
B.Competitive price
C.High quality standard
D.Customized service
4. What services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,FAS,CIP,FCA,DDP,DDU；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash.
