Factory Wholesale brass Wire Mesh 100/200 Shielding Decor Brass Copper

metal fabrics are produced using stainless steel, brass, copper and aluminum yarns resulting in materials providing the haptic feedback and the appeal of fabrics, yet featuring the properties of metals.

Mesh interlayers are ideal for use in architectural canopies, ceiling tiles, balustrade, elevator interiors, public art, interior
partitions, signage, stair treads, flooring panels, storefronts and wall cladding.

Features & Benefits
1.Laminated glass has additional strength and acoustical control.
2.Often used for safety or security glass and in applications which require sound control.
3.Create special effects not possible with panels.
4.Laminated glass can be used in interior and exterior applications.

Zinc plays an important role in brass wire mesh, it increases the wear resistance and higher tensile strength of brass wire mesh. It also hardens the mesh, compared to its softer copper woven wire mesh counterpart. For these reasons, brass wire mesh is commonly used in filtration and separation applications. In most cases, industrial-grade brass woven wire mesh has a golden yellow color to it, and this unique color makes it appealing for use in architectural, decorative and even artistic applications. Like virtually all wire mesh and wire cloth, brass wire mesh is used in architectural, decorative and industrial applications.

Product  Specification

Material	Brass wire
Weave Type	Plain weave
Width	0.5-5.0m
Length	Usually30m/roll
Application	Shielding of electromagnetic interference,gas-liquid filtration
brass wire--purity--Cu	65% , Zn:35%
red copper wire--purity--Cu	99.8%
phoshpor bronze wire--purity--Cu	85%-90% , Sn:5%-15%

Mesh Count(inch)	Wire Diameter(SWG)	Aperture(mm)
8	24	2.616
10	24	1.98
12	26	1.66
14	26	1.357
16	30	1.27
18	30	1.096
20	32	0.88
30	34	0.613
...	...	...
90	43	0.191
100	43	0.164
120	45	0.140
160	46	0.087
