Product Description


High Quality 100 - 600 Meters Water Well Drilling Rig Machine On Sale
Water well drilling rig machine is our hot sale products and has a very good reputation in our customers, the theory designed drilling depth is 100 - 600 meters.




Specification


1. KW180 water well drilling rig machine


Model
KW180
Drilling depth
180m
Diameter of hole
φ140-254mm
Advance Length one time
3m
Working pressure
1.7-2.5MPa
Air consumption
15-27m³/min
Length of rod
1.5m,2m,3m
Dia. Of rod
φ76, φ89,φ102
Lifting power
12 T
Rotation torque
3200-4600N.m
Rotation Speed
45-65r/min
Diesel Engine
Quanchai
Engine Power
55Kw/2200rpm
Travelling speed
0-2.5 Km/h
Climb capacity
30°
Weight
4500kgs
Dimension
3800x1500x2200mm
Application
Complicated geological conditions: Rock, Mud, Sand etc.
Drilling Way
Top drive hydraulic rotary and propulsion, Dth Drilling or Mud Pump Drilling
Dth Hammer
4",5",6",8" Drill hammer or CIR110, 130, 150,170




2. KW200 water well drilling rig machine


Drilling depth
200m
Dia.hole
φ140-204 mm
Advance Length one time
3.3m
Working pressure
1.7-3.0MPa
Air consumption
17-30m³/min
Length of rod
1.5m,2m,3m
Dia. Of rod
φ76, φ89,φ102
Lifting power
13T
Rotation torque
3300-4700N.m
Rotation Speed
45-70r/min
Diesel Engine
Quanchai
Engine Power
65Kw/2200rpm
Travelling speed
0-2.5 Km/h
Climb capacity
30°
Weight
5000kgs
Dimension
3950x1700x2300mm
Application
Complicated geological conditions: Rock, Mud, Sand etc.
Drilling Way
Top drive hydraulic rotary and propulsion, Dth Drilling or Mud Pump Drilling
Dth Hammer
4",5",6",8" Drill hammer or CIR110, 130, 150,170




3. KW280 water well drilling rig machine


Drilling depth
280m
Dia.hole
φ140-305mm
Advance Length one time
6.6m
Working pressure
1.7-3.0MPa
Air consumption
17-30m³/min
Length of rod
1.5m,2m,3m, 6m
Dia. Of rod
φ76, φ89
Lifting power
17T
Rotation torque
3700-5000N.m
Rotation Speed
55-70-130r/min
Diesel Engine
Yuchai
Engine Power
75Kw / 2200 rpm
Travelling speed
0-2.5 Km/h
Climb capacity
30°
Weight
7500kgs
Dimension
5900x1750x2450mm
Application
Complicated geological conditions: Rock, Mud, Sand etc.
Drilling Way
Top drive hydraulic rotary and propulsion, Dth Drilling or Mud Pump Drilling
Dth Hammer
4",5",6",8" Drill hammer or CIR110, 130, 150




4. KW300 water well drilling rig machine


Drilling depth
300m
Dia.hole
φ140-325mm
Advance Length one time
3.3 m
Working pressure
1.7-3.3MPa
Air consumption
17-35m³/min
Length of rod
1.5m,2m,3m
Dia. Of rod
Φ76, φ89,φ102
Lifting power
18T
Rotation torque
5700-75000N.m
Rotation Speed
40-70 rpm
Diesel Engine
Yuchai
Engine Power
85Kw/2200rpm
Travelling speed
0-2.5 Km/h
Climb capacity
30°
Weight
7000kgs
Dimension
4100x1950x2600mm
Application
Complicated geological conditions: Rock, Mud, Sand etc.
Drilling Way
Top drive hydraulic rotary and propulsion, Dth Drilling or Mud Pump Driling
DTH Hammer
4",5",6",8",10" Drill hammer or CIR110, 130, 150,170
Remark: It is installed with steel track , winch, electric welding machine.




5. KW350 water well drilling rig machine


Model
KW350
Drilling depth
350m
Dia.hole
φ140-325mm
Advance Length one time
6.6m
Working pressure
1.7-3.3MPa
Air consumption
17-35m³/min
Length of rod
1.5m,2m,3m, 6m
Dia. Of rod
φ89,φ102,φ114
Lifting power
24T
Rotation torque
6200-85000N.m
Rotation Speed
55-115r/min
Diesel Engine
Yuchai
Engine Power
92Kw/2200rpm
Travelling speed
0-2.5 Km/h
Climb capacity
30°
Weight
9000kgs
Dimension
5900x2000x2850mm
Application
Complicated geological conditions: Rock, Mud, Sand etc.
Drilling Way
Top drive hydraulic rotary and propulsion, Dth Drilling or Mud Pump Driling
DTH Hammer
4",5",6",8",10" Drill hammer or CIR110, 130, 150,170
Remark: It is installed with steel track , winch, electric welding machine.




6. KW400 water well drilling rig machine


Drilling depth
400m
Dia.hole
φ140-350mm
Advance Length one time
6.6m
Working pressure
1.7-3.5MPa
Air consumption
17-35m³/min
Length of rod
1.5m,2m,3m, (6m can be choosed)
Dia. Of rod
φ89,φ102,φ114
Lifting power
25T
Rotation torque
6500-9000N.m
Rotation Speed
45-115r/min
Diesel Engine
Yuchai
Engine Power
92Kw/2200rpm
Travelling speed
0-2.5 Km/h
Climb capacity
30°
Weight
10000kgs
Dimension
5900x2100x2850mm
Application
Complicated geological conditions: Rock, Mud, Sand etc.
Drilling Way
Top drive hydraulic rotary and propulsion, Dth Drilling or Mud Pump Drilling
DTH Hammer
4",5",6",8",10" Drill hammer or CIR110, 130, 150,170
Remark: It is installed with steel track , winch, electric welding machine, foam pump and ladder.




7. KW600 water well drilling rig machine


Drilling depth
600m
Dia.hole
φ140-350mm
Advance Length one time
6.6m
Working pressure
1.7-3.5MPa
Air consumption
17-42m³/min
Length of rod
1.5m,2m,3m,6m
Dia. Of rod
φ76, φ89,φ102,φ114
Lifting power
30T
Rotation torque
8500-11000N.m
Rotation Speed
45-115r/min
Diesel Engine
Cummins Brand
Engine Power
6BTA5.9-C180-II, 132Kw/2200rpm
Travelling speed
0-2.5 Km/h
Climb capacity
30°
Weight
12000kgs
Dimension
6000x2200x2950mm
Application
Complicated geological conditions: Rock, Mud, Sand etc.
Drilling Way
Top drive hydraulic rotary and propulsion, Dth Drilling or Mud Pump Drilling
Dth Hammer
4",5",6",8",10" Drill hammer or CIR110, 130, 150,170




Works with air compressor
Works with mud pump


Packing & Delivery




To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.


Exhibition




Company Profie




About Us.
Our company are specialized in this filed for over 25 years with high quality and competitive price. The main products we supply are drilling rigs, air compressors and rock drill tools and so on.
главные Рынки North America,Eastern Europe,Central America,Eastern Asia,South America,Africa,Southeast Asia,Mid East
основная продукция Machinery,Air compressor,Water well drilling rigs,Drilling rigs,Rock drill





FAQ


Q1: Are you a manufacturer?

A: Yes, we are a professional down the hole drill rig and top hammer drill rig manufacturer.

Q2: What does your company produce?

A: The main products of our company include blasting drilling rig,water well drilling rig and all kinds of air
compressors.

Q3: How about your delivery time?

A: Normally the delivery time is about 7-15 days. For some special case, we can make it within 2 weeks, it depends
on different products.

Q4: What methods of payment do you accept?

A: We accept T/T, L/C.

Q5: Do you offer any deals or discounts?

A: Yes, price depends on different quantity, different quantity will give you different price.


Contact Us


If you need more information about our products, please send us inquiry at your freely and we will be at service for you at any time. Then will send your more details about the machine.
