150 м глубина KS150R гусеничная трековая установка для бурения
- Категория: Mine Drilling Rig >>>
- Поставщик: Zhengzhou,Kaishan,Mechanical,&,Electrical,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.73 $* | 0.26 $* |
| Aug-19-2025 | 0.39 $* | 0.29 $* |
| Jul-19-2025 | 0.2 $* | 0.23 $* |
| Jun-19-2025 | 0.75 $* | 0.16 $* |
| May-19-2025 | 0.63 $* | 0.45 $* |
| Apr-19-2025 | 0.37 $* | 0.51 $* |
| Mar-19-2025 | 0.56 $* | 0.53 $* |
| Feb-19-2025 | 0.46 $* | 0.73 $* |
| Jan-19-2025 | 0.77 $* | 0.71 $* |
Характеристики
Product Description
Water well drilling rig 150m 180m 200m 300m 400m 500m 600m depth borehole drill machine.
KS150 Multi-function Geothermal Water Well Drilling Rig is mainly used for drilling water well, geothermal pump well and well hole for other purposes. The drilling machine can be used for drilling work at different stratums. The diameter of drill hole is large, which can reach up to 450m at maximum. Unique deep-hole axis pressure regulating system is used to properly adjust the propulsion force, which reduces the slewing resistance when drill deep hole. The drilling machine is equipped with two-stage retractable
carriage. The 4.5m drill rod can be used to reduce the times of extension rod.
Product advantage:
1. Double-motors swing mechanism
Straight-tooth reducer mechanism driven by two international brands of hydraulic motors is adopted, with simple structure and reliable performance.
2. Combined positioner
For the combined positioner, the positioning plate can be adjusted and replaced according to different models of drill stem and impactor, so as to ensure that the positioning and centering are accurate and reliable.
3. Flexible and stable hydraulic leg
Swing-type front leg and retractable rear leg can provide reliable support after being unfolded. The transportation size can be reduced by retracting the shell.
4. Deep-hole axis pressure regulating system
Unique deep-hole axis pressure regulating system is used to properly adjust the propulsion force, which reduces the slewing resistance when drilldeep holeand improves efficiency of drilling.
5. Two-stage retractable carriage
Adopt two-stage retractable carriage and 4.5m drill stem also can be used under the circumstance of not increasing the length of carriage, which reduces the extension rod times and improves the working performance.
carriage. The 4.5m drill rod can be used to reduce the times of extension rod.
Product advantage:
1. Double-motors swing mechanism
Straight-tooth reducer mechanism driven by two international brands of hydraulic motors is adopted, with simple structure and reliable performance.
2. Combined positioner
For the combined positioner, the positioning plate can be adjusted and replaced according to different models of drill stem and impactor, so as to ensure that the positioning and centering are accurate and reliable.
3. Flexible and stable hydraulic leg
Swing-type front leg and retractable rear leg can provide reliable support after being unfolded. The transportation size can be reduced by retracting the shell.
4. Deep-hole axis pressure regulating system
Unique deep-hole axis pressure regulating system is used to properly adjust the propulsion force, which reduces the slewing resistance when drilldeep holeand improves efficiency of drilling.
5. Two-stage retractable carriage
Adopt two-stage retractable carriage and 4.5m drill stem also can be used under the circumstance of not increasing the length of carriage, which reduces the extension rod times and improves the working performance.
Specification
Model of drill rig | KS150R | ||
Feed stroke | 3m | ||
Supporting drilling rod | Φ76×3m或Φ89×3m/Φ76×3m or Φ89×3m | ||
Outer dimensions | 4600×1550×2150mm | ||
Drilling hardness | f=6-20 | ||
Drilling diameter | Φ115-202mm | ||
Maximum depth of drilling | 150m | ||
Weight of complete machine | 4000KG | ||
Ground clearance | 280mm | ||
Climbing capacity | 15° | ||
DTH hammer | K4、K5、K6 | ||
Air consumption | 19-30m3/min | ||
Travelling speed | 0-2km/h | ||
Rotary torque | 4200N·m | ||
Rotary speed | 0-100rpm | ||
Method of Feed | Oil cylinder-leaf chain | ||
Lifting force | 50KN | ||
Advancing speed of sliding plate | 15-51m/s | ||
/Lifting speed of sliding plate | 8-26m/s | ||
Volume of hydraulic oil tank | 200L | ||
Volume of diesel oil tank | 60L | ||
Drilling method | Down-the-hole hammer or mud, etc. | ||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profie
About Us.
Our company are specialized in this filed for over 25 years with high quality and competitive price. The main products we supply are drilling rigs, air compressors and rock drill tools and so on.
главные Рынки North America,Eastern Europe,Central America,Eastern Asia,South America,Africa,Southeast Asia,Mid East
основная продукция Machinery,Air compressor,Water well drilling rigs,Drilling rigs,Rock drill
основная продукция Machinery,Air compressor,Water well drilling rigs,Drilling rigs,Rock drill
Certifications
Customer Photos
FAQ
Q1: Are you a manufacturer?
A: Yes, we are a professional down the hole drill rig and top hammer drill rig manufacturer.
Q2: What does your company produce?
A: The main products of our company include blasting drilling rig,water well drilling rig and all kinds of air
compressors.
Q3: How about your delivery time?
A: Normally the delivery time is about 7-15 days. For some special case, we can make it within 2 weeks, it depends
on different products.
Q4: What methods of payment do you accept?
A: We accept T/T, L/C.
Q5: Do you offer any deals or discounts?
A: Yes, price depends on different quantity, different quantity will give you different price.
A: Yes, we are a professional down the hole drill rig and top hammer drill rig manufacturer.
Q2: What does your company produce?
A: The main products of our company include blasting drilling rig,water well drilling rig and all kinds of air
compressors.
Q3: How about your delivery time?
A: Normally the delivery time is about 7-15 days. For some special case, we can make it within 2 weeks, it depends
on different products.
Q4: What methods of payment do you accept?
A: We accept T/T, L/C.
Q5: Do you offer any deals or discounts?
A: Yes, price depends on different quantity, different quantity will give you different price.
