Description:



The water circle split water heater adopts higher heating exchanger to provide you the most energy saving solution for sanitary hot water supply. With Built-in water pump inside the outdoor unit, it is easy installation, Just simply connect the water pipe and power, you can enjoy the constantly hot water supply for shower and bath. Suitable for villa , school ,hotel ,family, Spa and office.



Features:

Mitsubishi or Panasonic Rotary type compressor, low vibration, low noise and high reliability.

Polyurethane insulated water tank

Intelligent EE valve, excellent efficiency at different ambient temperature.

Built-in famous water pump

Innovative W-A-R(Water, Air, Refrigerant) technology, higher efficiency up to COP 4.5

Energy saving up to 80% than traditional electric heater

Automatically defrosting







Water circle split water heater
MODEL		SR-003SPCI	SR-005SPCI	SR-007SPCI
Ambient temp.range	℃	-15~+43℃	-15~+43℃	-15~+43℃
Rated heating capacity	kw	3.7	5	7.5
COP	W/W	4.25	4.35	4.38
Rated power input	kw	0.87	1.15	1.71
Max. Running current	A	5.5	8.5	13.1
Power supply	/	220V 1N~50Hz
IP code	/	IPX4
Safety function	/	High and low pressure protection, Overload protection, Temperature protection
Refrigerant type	/	R407C/R410/R22
Compressor QTY	Pcs	1
Compressor type	/	Scroll
Max. Temp. Outlet water	℃	60℃
Condenser type	/	High efficiency tank
Water pipe nozzle size	inch	G3/4” Internal thread	G3/4” Internal thread	G3/4” Internal thread
Circulating water quantity	M3/h	0.6	0.84	1.3
Air out type	/	Sideward
Fan motor QTY	pcs	1	1	1
Noise	Db/(A)	51	53	54
Machine dimension (WxDxH)	mm	750X264X505	930X282X550	1000X300X620
Packing dimension (WxDxH)	mm	785X355X550	1050X380X600	1120X390X660
Net weight	kg	41	57	65
Gross weight	kg	46	63	72
Water tank volume	L	150/200	150/250/300	300/400/500



Remarks:

1. Test conditions: dry bulb temperature 20℃/wet bulb temperature 15℃, initial water temperature 15℃/stop water temperature 55℃.

2. Models, parameters will be changed due to product improvements without notice. The specific parameters are base on the nameplate.
