HNHF Henan hengfu design full automatic 10 ton compound feed making plant


Description for chicken food making machine

















Capacity 1-20t/h
Production line classificationManual production line,   automatic production line
Main equipmentFeed hammer mill, feed mixer, Counter flow Cooler, pellet press







_01_02_03_04


a. For pig, the pellet diameter is usually ø3.5-6.5mm.
b. For cattle, the pellet diameter is usually ø4.5-8mm.
c. For chicken, pellet diameter is usually ø3.2mm.
d. For fish, pellet diameter is usuallyø2.0, ø2.5, ø3.0mm.
e. For shrimps, pellet diameter is usually ø1.0-ø3.5mm.


Pellet length is customized.


_05


1,Raw material receiving and cleaning process
The raw materials are transported to the factory, and after weighing and weighing in the ground, the materials are manually unloaded to the corresponding storage space of the raw material warehouse for stacking.
2,the crushing process:
At the time of production, the material to be pulverized is manually transported to the raw material feeding port, the material is weighed, and the pulverizer and corresponding equipment are started. The material enters the pulverizer through the air transportation pipe, and the pulverized material directly falls into the mixing chamber of the mixer for mixing.
3, the mixing process:
The material enters the mixer and begins to mix. After mixing, the material flows through the discharge port to the screw hopper feed hopper, and enters the granulation bin through the spiral hoist.
4,granulation, cooling process:
The mixed material enters the feeder and the modulator through the granulating bin, enters the granulator for granulation, and after granulation, the winder enters the cooler to start cooling, and the cooled material is sieved to the finished material through the vibrating sieve. Directly into the bag for packaging.


If you don't enough budget ,cooling system  is optional , you can put finished feed under sun for cool and dry.Above is completely animal feed pellet production line ,use ring die pellet machine.


_06_07_08_09




Packaging & Shipping


-





HNHF Henan hengfu design full automatic 10 ton compound feed making plant


Specialized design of wooden box packing, ensure that the goods are not damaged,; Container transport.





-





Our Services


HNHF Henan hengfu design full automatic 10 ton compound feed making plant


Pre-sale service:


1.Provide our client with investment guide for free.


2.Provide our client with evaluation investment scheme for free


3.Free visit to our factory.


4.Design of production line scheme is provided for free.


In-sale service:


1. Experienced workers are sent to provide track service when equipment is transported.
2. Experienced technicians or engineers will be sent for on-site installation, adjustment and technical devices according to clients' engineering requirement.
3. "Operating instruction manual", equipment assembly drawings and wearing parts list in duplicate will be provided for free.


Post-sale service:


1. On the premise that equipment is operated correctly and in warranty period, we accept repair, exchange, and return items.
2. We provide permanent favorable spare parts for our clients.


3. We provide permanent technology support and related help.






² Professional engineering design





² Earliest delivery ,high quality with best price





² Safe and efficient transport services





² Efficient installation guide can send video installation and operation





² One year guarantee for whole machine, except the wearing parts .





² We can provide engineers available to service machinery overseas.





² 24 hours technical support by E-mail or telephone.








Company Information



With More than 25 Years in Production of Animal Feed Machines


HNHF 10 ton pellet feed production line cattle sheep ruminant feed mill


Xinxiang Hengfu Electronic Machinery Co. Ltd, founded in 1993, is currently one of the best key enterprises specialized in the research and development of feed machinery, pellet machines, animal feed mixers and grinders in the machinery manufacturing industry, which have passed the certification of CE due to our ISO 9001:2008-certified operations. Our feed complete equipment have been exported to North and South America, Africa, Asia, Europe, and more than 20 countries worldwide. We also have strict and complete QC system.


Good quality, competitive price and excellent after-sale service are highly praised by customers. So far, product sales have covered more than 25 provinces and cities in China and also exported to Ghana, Botswana, Benin, Ivory Coast, Venezuela, Mozambique, Indonesia, Malaysia, Korea and over more than 20 countries.


2





FAQ


To give you the accurate price, there are some details to confirm as follows:
HNHF Henan hengfu design full automatic 10 ton compound feed making plant
1. What's your raw material?
2. what kind of animal do you feed?
3. The output per hour?
4. Do you also need automatic packing machine?
5. The basic processing technology: Grinding, mixing, pelleting, cooling, crumbling, screeening, packing. Any special requirement, let me know directly.
6. Our normal voltage is 380V, 50HZ,3phase, if yours is different, tell me yours.









1.Are you manufacturer,yes or not?
Answer:Yes. We have been feed machine manufacturer for 23 years and it will be longer.Now we are capable of producing not only feed machines but also biomass machines and mineral stone processing machines.



2.Can you accept the customized plan? Can you simplify my plan for reducing costs?
Answer:Of course,our brilliant engineers are waiting for it all the time.

3.What's your MOQ?
Answer:Generally speaking,one is okay,but larger quantity ,lower price.

4.What i need know to build a feed processing plant?
Answer:You just need figue out the following questions:

(1)What animal you want to feed? the animal amount?This is used for confirming the production capacity and feed type.
(2)What raw materials you have?material size?material moisture?
(3)Any speical demand?Wait for your contact anytime.


HNHF Henan hengfu design full automatic 10 ton compound feed making plant
