Environmental protection continuous type drum carbonization furnace is suitable for woodiness materials which containing carbon (volume below 15mm granular), such as coconut shell, apricot shell, hemp stalk, sawdust, rice husk, bamboo, eucalyptus, mushroom residue, furfural residue, coffee grounds, palm shell, peanut shell, walnut shell. It is the better machine for dry distillation and anaerobic carbonization under high temperature and the carbonization rate is high.
The advanced technology of recovering, purifying and circulating combustion of combustible gases such as carbon monoxide, methane and produce smoke lead the carbonization process is adopted reasonably. It not only solves the problem that the ordinary carbonization furnace produce smoke lead the environmental pollution, and also solves the problem of heat required, fully achieve the self-sufficient, improves the continuity and economy of the equipment, make full use of agricultural and forestry residues, make it treasure, and make more contributions for the greening of the environment.
Working Principle
First, the biomass material is ignited in the gasifier.The flue gas produced by burning after spraying, cooling, purification process, it produces the pure combustible gas (carbon monoxide, methane, ethane, etc.).As the early stage of the carbonization of heat source, through the early warming of the carbonized, to feed the material when the heat reaches the special temperature.The combustible gas that carbonation process of flue gas by spraying, cooling, purification process into the burned secondary. According to this method of circulation, sufficient to achieve self-sufficient, then achieve the effect of energy-saving.The flue gas through purification, to reach the environment production and flue gas emissions-free. Which is reached to the standards of waste gas emptying.
The temperature of carbonization reaches 600 ℃ to 900 ℃ in the process. According to the characteristics of the material, the temperature can be adjusted according to the requirements.
Application
Product Paramenters
Model
Yield (kg/h)
Power(kw)
Dimension(m)
Host Rpm
(revolutions per minute)(m)
THJ-1000
400-600
25
9*1.5*2.7
3-5
THJ-1200
800-1200
27
12*1.7*2.9
3-5
THJ-1500
1500-2000
32
12*2.0*3.2
3-5
THJ-1800
2500-3000
39
12*2.3*3.3
3-5
Biomass Drum Carbonation Machine Main Technical Parameter List
Company Introduction
FAQ
Q: What is your Business Model? Trading company or factory? A: We are a 15 years factory, all our machinery is manufactured by ourselves, factory direct sales, product quality, and after-sales service can be guaranteed.
Q: Can I visit your factory? A: Yes. Many domestic and international customers visit our factory every year. Our company is located in Zhengzhou Henan province, China, you can come here by air or train. The nearest airport is Zhengzhou Xinzheng International Airport, and the Airport Code is CGO.We will pick you up at the airport. Welcome to visit our factory.
Q: What is the Quality of your products? A: Zhengzhou Jiutian products come with the best quality, and our products passed CE certification, exported to lots countries around the world, such as Australia, Malaysia, India, Italy, Indonesia, Vietnam, Philippines, Korea, Brazil, Argentina, Russia,South Africa, etc. You can rest assured of the quality absolutely.
Q: How long is the Warranty of your equipment? A: Our warranty period is one year generally.
