8kva 10kva 10 кВт 10000 Вт 15 ква 20 кВА низкочастотный автономный источник бесперебойного питания и Солнечный
- Категория: Solar Inverter >>>
- Поставщик: Foshan,Panpower,Science&Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.87 $* | 0.22 $* |
| Aug-15-2025 | 0.16 $* | 0.39 $* |
| Jul-15-2025 | 0.50 $* | 0.55 $* |
| Jun-15-2025 | 0.18 $* | 0.81 $* |
| May-15-2025 | 0.3 $* | 0.13 $* |
| Apr-15-2025 | 0.71 $* | 0.73 $* |
| Mar-15-2025 | 0.16 $* | 0.71 $* |
| Feb-15-2025 | 0.91 $* | 0.72 $* |
| Jan-15-2025 | 0.51 $* | 0.99 $* |
Характеристики
Feature
1) With SPWM technology controlled by CPU, pure sine wave output, AVR output;
2) Automatic switch, realize unattended function;
3) AC priority or DC priority selectable;
4) 50HZ, 60HZ automatically detect output conversion;
5) Wide input range: 110V(75V-140V)/220V(145V-275V)
6) Applying to capacitive load, inductive load and nonlinear mixed load;
7) Communication function: USB interface/SNMP remote control/GSM SMS function;
8) Perfect protection function: input over/low voltage, overload, short circuit, low battery voltage, over temperature etc
Specification
Model | 5kva | 6kva | 7kva | 8kva | 9kva | 10kva | 12kva | 15kva | 20kva | |
Rated power | 4kw | 4.8kw | 5.6kw | 6.4kw | 7.2kw | 8kw | 9.6kw | 12kw | 16kw | |
Instant power | Three times | |||||||||
DC Input | DC voltage | 12V/24V/48V/72V | 72V/96V/192V | 96V/192V/240V | ||||||
Battery No. | 12V battery: 1pcs/2pcs/4pcs/6pcs | |||||||||
Battery type | Maintenance-free lead-acid batteries | |||||||||
AC Input | Phase | Single Phase | ||||||||
Frequency | 50Hz ± 10% | |||||||||
AC input | 110V(75-140V)/220V(145-275V) (L+N+G) | |||||||||
AC AVR output | 110/220VAC (L+N+G)±10% | |||||||||
AC Charger (option) | Floating charge voltage | DC12V:14.5V/DC24V:29V/DC48V:58V/DC72V:87V DC96V:116V/DC192V:232/DC240V:290V | ||||||||
Overcharge protect voltage | DC12V:15.5V/ DC24V:31V/ DC48V:62V/ DC72V:93V DC96V:124V/ DC192V:248V/ DC240V:310V | |||||||||
Charge current | 10-20A adjustable (Charging current can be customized ) | |||||||||
Solar Controller (option) | rated voltage | DC12V/DC24V/DC48V/DC72V/DC96V/192V/240V | ||||||||
maximum input voltage | 50V/100V/200V/450V | |||||||||
Max. charge current | 30A/40A/50A/60A/100A | |||||||||
Protection function | Overcharging, overloading, overloading, low-voltage, short-circuit, back-to-back | |||||||||
Invert output | Output voltage | 110V/220VAC (L+N+G)±1% | ||||||||
Frequency | 50Hz ± 0.1% | |||||||||
THD | ≤ 3% (Linear load) | |||||||||
Dynamic response | 5% (0%~100% load) | |||||||||
Crest factor | 3:1 | |||||||||
Invert efficiency | 97% | |||||||||
Man-machine interface | LCD display panel | |||||||||
Alarm | Buzzing and LCD screen flicker | |||||||||
Protection function | Ac overvoltage, under voltage, DC overvoltage, under voltage, Overload, Output short circuit | |||||||||
Overload capacity | >100-120% alarm 60s then shutdown; >100-120%, back to normal working when cut down loads during alarm 60s; >150% Instant shutdown | |||||||||
Communication interface | USB/RS232/SNMP/Wifi(option) | |||||||||
Protection class | IP21 | |||||||||
Surge handling capability | 10/700US,5KVA;8/20US,20KA | |||||||||
Noise dB | ≤45db | |||||||||
Cooling mode | Forced ventilation | |||||||||
Ambient Temperature | Temperature 0-40℃, relative humidity 10%-90%, elevation<1000m | |||||||||
Photos
Factory Show
Customer Visting
Certificates
Trade Information
FAQ
Q: Are you a factory?
A: Yes, we are a manufacturer of pure sine wave inverter, solar controller and UPS, AVR.
Q: Are you inverter pure sine wave output?
A: Yes, All are true pure sine wave.
Q: What kind of output you can do?
A: Normally single phase 110V 120V 220V 230V 240V 50/60Hz
Q: How long is your factory?
A: It's over 17 years. Before we focused on domestic market. From 2013, we set up our oversea sales department.
Q: What’s the delivery time?
A: 3 - 7 days for sample; 10 to 25 days for bulk order.
Q: What’s the payment term?
A: T/T, Alibaba Trade Assurance, Western Union, Paypal, L/C, D/P.
