Product Description
20000l high pressure gas station storage tank
* Vertical and horizontal gas storage tanks, liquid storage, and vacuum tanks, etc.
* The medium is air, hydrogen, nitrogen, oxygen, natural gas, water, liquefied gas, oil, refrigerant, etc.
* The product meets the requirements of various standards such as ASME, PED, GB150.
* Material: CS; SS; Nickel alloy material; Titanium; Hastelloy C276 cladding.
At alloy engineering, we have the expertise to customize pressure vessels to your specifications. We can assist with critical issues such as material selection and design optimization. We also offer specialized design and welding techniques for these demanding high temperature and corrosive Applications.
Model | HNS |
Norminal volume | 1Liters-200 m3 |
Material | CS, SS, other alloy lined |
Max pressure | 200 bar |
Design temp. | -196~350℃ |
Product Features
* Large scale industrial scale production;
* GB, ASME design and manufacture certificate.
* Max pressure: 200 bar; Max temperature up to 350 ℃;
* We offer carbon steel, stainless steel, or most exotic alloys such as Hastelloy, Monel, or Inconel;
* When the pressure is large, cladding plates could be considered, including base material for strength and clad material for anti-corrosion. Reduce costs for you!
* Internal cooling coil, vent port, liquid / powder charging, dip tube, thermowell, safety rupture disc, pressure safety valve, flush bottom outlet, baffles, light & sight glass, handhole / manhole etc.
* GB, ASME design and manufacture certificate.
* Max pressure: 200 bar; Max temperature up to 350 ℃;
* We offer carbon steel, stainless steel, or most exotic alloys such as Hastelloy, Monel, or Inconel;
* When the pressure is large, cladding plates could be considered, including base material for strength and clad material for anti-corrosion. Reduce costs for you!
* Internal cooling coil, vent port, liquid / powder charging, dip tube, thermowell, safety rupture disc, pressure safety valve, flush bottom outlet, baffles, light & sight glass, handhole / manhole etc.
* We offer various internal and external finishes for our products.
* Lugs or floor stand leg support.
* Lugs or floor stand leg support.
Product Paramenters
Norminal volume | 100L-200 m3 | 0.6 | ||||
Material | CS, SS, other alloy lined | 4 | ||||
Design pressure | -1~200 bar | |||||
Design temp. | -40~350℃ | |||||
Base Thickness | 6~160mm | |||||
Clad Thickness | 3~10mm | |||||
Max Length | 16 m | |||||
Max Diameter | 6 m | |||||
Max weight | 200 tons | |||||
Shape | Vertical or horizontal | |||||
Head type | Semi-elliptical, Dished type, Hemispherical, Flat type | |||||
Jacket | Dimpled, Half-pipe, Std. | |||||
Heating type | Oil electric heating; Oil heating; Steam heating | |||||
Note: If the diameter exceeds 6,000mm, it need to be fabricated on the site. If the unit weight exceeds 200tons or the total length exceeds40m, segmented transport and field welding will be required. | ||||||
Customization
Customized Specifications
If there has special process requires,HXHCEM will also customize for you!
Pls list your basis process parameters like follows:
1. Vessel volume
2. Operating Temperature
3. Operating Pressure
4. Vessel Material / contacting components material
5. With heating device or not.
6. Internal cooling coil or not, exchange area?
If there has special process requires,HXHCEM will also customize for you!
Pls list your basis process parameters like follows:
1. Vessel volume
2. Operating Temperature
3. Operating Pressure
4. Vessel Material / contacting components material
5. With heating device or not.
6. Internal cooling coil or not, exchange area?
7. Support method
8. Your other requests
......Contact us
We'd like to help you to accomplish your plans.
8. Your other requests
......Contact us
We'd like to help you to accomplish your plans.
