5kw Vertical wind generator high efficiency vertical axis wind turbine for sale
Parameters
Model
YC-3k
YC-5k
YC-10k
YC-20k
Rated power
3kw
5kw
10kw
20k
Maximun power
4kw
6kw
13kw
25kw
Rated voltage
96/120/220V
120/220/240v
220/240/380v
240/380v
Start-up wind turbine
3m/s
3m/s
3m/s
3m/s
Rated wind speed
10m/s
10m/s
10m/s
10m/s
Survival wind turbine
45m/s
45m/s
45m/s
45m/s
Top net weight
205kg
285kg
400kg
685kg
Wheel diameter
5.6m
6.3m
8.2m
10m
Number of blades
3
Blades material
Reinforced glass fiber
generator
Three phase permanent magnet ac synchronous generator
magnet
NdFeB
Generator case
Carbon steel
Control system
Electromagnet/wind wheel yaw
Speed regulation
Tail furling
Working temperature
-40°C - 80°C
Design life
20 y
product feature
1.Low start-up speed,high wind power utilization, light,cute, low vibration.
2.Human-friendly design,easy to install and maintain.
3.Blades using reinforced glass fiber, helped with optimized structure and aerodynamic shape, it enhanced wind power coefficient and power generating capacity.
4.Using patented permanent magnet generator and special stator, it effectively reduces torque resistance and guarantees the stability
