2020 китайская машина для продольной резки, цены
US $30000-$50000
3-12x2200мм новейшая хорошая цена Обрезка рулонов до длины линия машина для резки алюминия отрезка
- Категория: Линия поперечной резки >>>
- Поставщик: Wuxi,Hai,Roll,Fone,Science,And,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 47600.30 $* | 49980.83 $* |
| Aug-15-2025 | 47200.54 $* | 49560.10 $* |
| Jul-15-2025 | 39600.50 $* | 41580.29 $* |
| Jun-15-2025 | 46400.68 $* | 48720.74 $* |
| May-15-2025 | 40400.64 $* | 42420.71 $* |
| Apr-15-2025 | 45600.15 $* | 47880.5 $* |
| Mar-15-2025 | 45200.14 $* | 47460.77 $* |
| Feb-15-2025 | 44800.82 $* | 47040.63 $* |
| Jan-15-2025 | 44400.49 $* | 46620.88 $* |
Характеристики
Company Profile
Products Description
1、What is Cut To Length Machine
The Cut To Length Machine also called cut to length line which are used for uncoiling,leveling and cutting the metal coil into the required length of flat sheet material and stacking.It suitable for processing cold rolled and hot rolled steel, coil,galvanized steel coil,silicon steel coil, stainless steel coil,aluminum coils etc into different width according to the user’s production demands and cut as well
2、Function
This equipment through the procedure of uncoiling, leveling, precision gauge cutting, processing the strip steel coil into required steel pate. It mainly composed of uncoiler, pincher and leveler, gauge, cutting machine , stacker, etc, with assists of feeder, side guiding device, transition, and conveyor, etc.
3、Category
According to the metal materials there are stainless steel cut to length machine,silicone steel cut to length machine,cold or hot rolled plate cut to length machine and so on.
According to its electronic control mode there are pneumatic cut to length line,NC cut to length line and etc..
The Cut To Length Machine also called cut to length line which are used for uncoiling,leveling and cutting the metal coil into the required length of flat sheet material and stacking.It suitable for processing cold rolled and hot rolled steel, coil,galvanized steel coil,silicon steel coil, stainless steel coil,aluminum coils etc into different width according to the user’s production demands and cut as well
2、Function
This equipment through the procedure of uncoiling, leveling, precision gauge cutting, processing the strip steel coil into required steel pate. It mainly composed of uncoiler, pincher and leveler, gauge, cutting machine , stacker, etc, with assists of feeder, side guiding device, transition, and conveyor, etc.
3、Category
According to the metal materials there are stainless steel cut to length machine,silicone steel cut to length machine,cold or hot rolled plate cut to length machine and so on.
According to its electronic control mode there are pneumatic cut to length line,NC cut to length line and etc..
Product Paramenters
item | specifications | ||
Raw materials | Materials feature | Carbon steel(Hot rolled steel,SS400) | |
thickness | 3.0mm—12.0mm | ||
width | 800mm—1600(2200mm ) | ||
O.D | Φ1000mm—φ2100mm | ||
I.D | φ500mm—φ800mm | ||
Coil weight | Max 35T | ||
Finished product | Cutting length | 6000mm—12000mm | |
Cutting tolerance： | ±1.0mm( length tolerance) ±2.0mm( diagonal tolerance) Match the standard GB/T709-88 | ||
Leveling speed | 0—26m/min | ||
Center line of the line ( to the ground) | 1000mm | ||
Total power consumption | About 245kw | ||
The whole line dimension requirement | About 34mx10m | ||
