Product Description

If you want 400kva agriculture or commercial use genset, you can consider this kind of generator, ecu engine is low fuel consumption and convenient.



Technical Specification

Model	Voltage	HZ	P.F (COS)	Standby power	Prime power	Net Weight
WP-P320GF	400V/230V-3P	50	0.8	352 KW	320 KW	3300 kg

Prime power

This rating is for the supply of continuous electrical power (at variable load). There is no limit on the annual hours of operation and 10% overload power can be supplied for 1 hour in 12.

Standby power

This rating is for the supply of continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted.

General features:

n Every generator set is subjected to a comprehensive test program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;

n 24V DC start motor;

n Equipped 24V high performance maintenance-free lead-acid starting batteries and connecting with cables;

n Equipped with industrial silencer and flexible exhaust hose;

n Designed to Comply with ISO8528/GB2820;

n Powered by Perkins engine, Stamford alternator and DeepSea control panel

Engine Spec

Engine model	2206D-E13TAG3
Engine manufacturer	Perkins
Current	576 A
Number of Cylinder	6 cylinders in line
Cycle	4 stroke
Aspiration	Turbocharged and air to air charge cooled
Bore×Stroke	130mm x 157mm
Displacement	12.5 L
Comression ratio	16.3 : 1
Steady speed droop	≤1%
Combustion system	Direct injection
Total system capacity	40 L
Total coolant capacity	51.4 L
Fuel consumption	206 g/kw.h
Cooling system	Water cooled
Starter Motor	DC24V,
Alternator	DC24V

Alternator Spec

Alternator model	S4L1S-F
Prime power	320 KW
Frequency/Speed	50Hz/1500rpm
Exciter type	Single bearing, Brushless, Self-excited
Power factor	0.8
Voltage adjust range	≥5%
Voltage regulation NL-FL	≤±1%
Insulation Grade	H
Protection Grade	IP23
Phase	Three phases

Control Panel

Model	DSE6020
The control module gives digital readouts of:	Generator voltage; Output frequency; Engine speed; Battery voltage; Engine hours run.
The control module has indicators for failure information:	Over speed / under speed, Emergency stop Low oil pressure; High water temperature Failure to start Battery charger failure
Automatic shutdown occurs under:	Low engine oil pressure; High engine water temperature; Over speed/ under speed; Failure to start after three attempts

Standard Accessories

Standard Accessories	Open type	Silent type
Sound-proof & Weather-proof Canopy	N/A	√
Daily base fuel tank. 8 hours capacity	N/A	√
Single-bearing generator again drops	√	√
Intelligent LED display control panel	√	√
Speed governor	√	√
Electric start and 24v charger	√	√
Standard air filter, oil filter, fuel filter	√	√
High-efficient silencer.	√	√
Cooling water tank	√	√
Exhaust elbow	√	√
Storage battery	√	√
Steel base-frame against vibration	√	√
Soft pipe for fuel and handle for lube going-out	√	√
Operation& Maintenance manual.	√	√
