Должны бренд PV2000 Pro вне сеточной солнечной панели инвертора со встроенными 50A ШИМ контроллер зарядного устройства 1kva/700W 1.5kva/900W 2kva
- Категория: Solar Inverter >>>
- Поставщик: Must,Energy,(guangdong),Tech,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 12922.25 $* | 13180.43 $* |
| Jul-20-2025 | 10480.11 $* | 10690.8 $* |
| Jun-20-2025 | 12719.32 $* | 12973.28 $* |
| May-20-2025 | 12617.8 $* | 12869.87 $* |
| Apr-20-2025 | 10073.48 $* | 10274.13 $* |
| Mar-20-2025 | 12414.16 $* | 12662.63 $* |
| Feb-20-2025 | 12312.20 $* | 12558.73 $* |
| Jan-20-2025 | 12210.90 $* | 12454.4 $* |
Характеристики
MUST Brand PV2000 Pro off grid solar panel inverter with inbuilt 50A PWM charger controller 1kva/700W 1.5kva/900W 2kva 1200W
Product Description
Low Frequency Off Grid Solar Inverter
PV2000 PK Series (1-2KVA)
PV2000 PK built-in high efficiency solar controller. AC input voltage range for 140VAC-280VAC with regulated output (AVR) features, PV, AC function, A tracking feature such as power frequency. The output frequency can be set using the keys, AC /PV charging voltage, charge current, AC or PV priority mode, Battery under voltage shut-down point, and so many other functions.
Product Performance
- Pure sine wave output
- Built-in 50A PWM solar charge controller
- Smart LCD setting ( frequency , charge voltage, charge current, etc).
- Overload and short-circuit protection
- Deep discharge protection
- Cold start function
- Support USB/RS232 monitoring function
Spec
| MODEL | PV20-1012 PK | PV20-1512 PK | PV20-2024 PK |
| Battery Input Voltage Rating | 12VDC | 24VDC | |
| INVERTER OUTPUT | |||
| Rated Power | 1000VA | 1500VA | 2000VA |
| 700W | 900W | 1200W | |
| Instantaneou s Power Drawn (20ms) | 2100W | 2700W | 3600W |
| Output Waveform | Pure sine wave | ||
| Output Voltage | Inverter mode: 230VAC(±5% RMS), AVR mode: 200VAC-240VAC 220VAC(±5% RMS) | ||
| Output Power Factor | 0.7 | 0.6 | |
| Output Frequency | 50Hz/60Hz ±0.2 Hz | ||
| Inverting Efficiency (peak) | >85% | ||
| Mains Mode Efficiency | > 95% | ||
| Transfer Time | Typical 2~6ms 10ms(max) | ||
| AC INPUT | |||
| Input Voltage | 220/230VAC | ||
| Input Voltage Range | 140~280VAC±5% | ||
| Low Pressure Shutdown | 140VAC±5% | ||
| High Pressure Shutdown | 280VAC±5% | ||
| Low Frequency Shutdown | 45±0.2Hz(50Hz) | ||
| 55±0.2Hz(60Hz) | |||
| High Frequency Shutdown | 55±0.2Hz(50Hz) | ||
| 65±0.2Hz(60Hz) | |||
| Frequency Range | 50Hz/60Hz ±0.2HZ | ||
| BATTERY | |||
| Minimum Start Voltage | Battery under voltage shut-down point +0.5V | Battery under voltage shut-down point +1.0V | |
| Low Battery Alarm | Battery under voltage shut-down point +0.5V | Battery under voltage shut-down point +1.0V | |
| Low Battery Shutdown | (0.1V 1 10-12.0VDC mode) User set | (0.2V 1 20.0-24.0VDC mode) User set | |
| Battery High Voltage Alarm | Average Charge Voltage+1V | Average Charge Voltage +2V | |
| AC CHARGER | |||
| Float Voltage | 13.5 / 13.6 / 13.7VDC to set | 27.0 27.2 27.4VDC to set | |
| Average Charge Voltage | (0.1V each click ,13.8~14.5V mode) User set | (0.2V each click , 27.6~29V mode) User set | |
| Maximum Charge Current | 20A±2A | 25A±2A | 15A±2A |
| BYPASS & PROTECTION | |||
| Input Frequency | 50Hz / 60Hz | ||
| Low Frequency Switching | 45+/-1Hz | ||
| High Frequency Switching | 65+/-1Hz | ||
| Overload Protection | 110%~125%R load fault after 60s 125% ~150%R load fault after 3s >150%R load fault after 500ms | ||
| Output Short Circuit Protection | Yes | ||
| Bypass Circuit Breaker Insurance | 10A | ||
| Maximum Current Bypass | 7A | 10A | |
| SOLAR CHARGER | |||
| Maximum PV Charge Current | 50A±5A | ||
| Battery Voltage | 12VDC | 24VDC | |
| Maximum PV Array Power | 150W*5 solar panels | 150W*10 solar panels | |
| Maximum PV Array Open Circuit Voltage | 55Vdc | 72Vdc | |
| Maximum Efficiency | > 95% | ||
| Standby Consumption | <2W | ||
| MECHANICAL SPECIFICATIONS | |||
| Assembly | Wall mount | ||
| Dimension (W*H*D) (mm) | 320*300*135 | ||
| Net Weight KG | 9 | 10 | 10.5 |
| Shipping Dimensions (mm) | 400*335*195 | ||
| Transport Weight KG | 10 | 11 | 11.5 |
| OTHER | |||
| Working Environment | 0°C~40°C 0~90% Relative humidity (non-condensing) | ||
| Noise | Less than 60db | ||
| Display | LED + LCD | ||
Company Information
1. MUST Factory located in Huanan Chuanggu Science and Technology Park, Chancheng District, Foshan City. We are a high-tech manufacturer specializing in R&D, production, sales and service of industrial automation, new energy and power electronics related products.
2. MUST main products include: (UPS), Inverter, Photovoltaic Controller, Photovoltaic Inverter, Photovoltaic control inverter integrated machine, photovoltaic energy storage inverter, photovoltaic grid-connected inverter, Photovoltaic power generation system, photovoltaic pump system, microcomputer room system, dedicated loss converter, servo drive, servo motor, servo system
3. MUST's products have passed CE, SAA, SONCAP, SGS, Tell certification and other safety certifications, ISO: 9001, ISO: 14000 and other quality management system certification,
4. MUST products are exported to Spain, Italy, Russia, Australia, the Middle East, Ukraine, South Africa, Nigeria, Pakistan and other countries to provide customers with quality and efficient services.
Our Services
5kw 6kw 7kw 8kw Hybrid solar power Inverter for solar power system MPPT built inside
5kw 6kw 7kw 8kw Hybrid solar power Inverter for solar power system MPPT built inside
Packaging & Shipping
5kw 6kw 7kw 8kw Hybrid solar power Inverter for solar power system MPPT built inside
Certifications
5kw 6kw 7kw 8kw Hybrid solar power Inverter for solar power system MPPT built inside
FAQ
Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.
Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.
Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.
Q4: What is the warranty of inverter?
A4: One year warranty on Must-Solar product.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
